ZIPABOX 2

Product catalog summary

Overview: The Zipabox 2 is a modular smart home server designed to integrate various smart home devices and systems. It serves as the central hub for connecting and managing different modules and sensors.

Main Unit and Modules: The main unit can connect up to four modules simultaneously. Available modules include Security, 433 MHz, Z-Wave, Zigbee, P1, Backup, Power, 4G, EnOcean, KNX, and Serial. Each module allows integration with specific devices or networks, such as hard-wired security sensors, 433 MHz devices, Z-Wave devices, Zigbee devices, P1 meters, and more.

System Specifications: The system is powered by an ARM Cortex-A7 Quad-Core 1.3GHz CPU with 256MB RAM and 4GB Flash memory. It supports Ethernet, WiFi, Bluetooth, and various radio modules. The operating system is Linux-based.

Power and Environmental Specifications: The device operates on 9-12VDC power input with an internal backup battery providing up to 20 hours of autonomy. It supports a temperature range of 0°C to 40°C for operation and -25°C to 70°C for storage, with humidity tolerance from 5% to 95% non-condensing.

Physical and Compliance: The dimensions are 86 x 86 x 47 mm. It includes USB 2.0, programmable buttons, and LEDs. It complies with safety and EMC standards (UL, FCC, CE) and is RoHS compliant.

Control Interface: The system can be controlled via iOS, Android, and web applications, providing flexibility in managing smart home devices.

Warranty: The product comes with a standard 1-year warranty.

Additional Features: The Zipabox 2 supports cloud server connectivity and 24/7 mobile app access. It is compatible with various sensors and controllers, including smoke sensors, valve controllers, door sensors, water sensors, light controllers, motor controllers, thermostats, and motion sensors.

Catalog excerpts

CONNECT EVERYTHING MODULAR SMART HOME SERVER SECURITY MODULE MAIN UNIT* Connect hard wired security sensors BACKUP MODULE POWER MODULE Provides up to 20h power autonomy Monitor up to 4 electrical circuits in a real time Z-WAVE MODULE ZIGBEE MODULE Connect Z-Wave devices Connect Zigbee devices ENOCEAN MODULE SERIAL MODULE Connect EnOcean devices Connect with KNX network Connect RS232/485 /Modbus devices *only 4 modules can be connected to the Main Unit at one time make your home smart

Open the catalog to page 1

ZIPABOX 2 CLOUD SERVER MOBILE APPs sOmfy. NEXA TECHNICAL SPECIFICATIONS SYSTEM ARM Cortex-A7 Quad-Core 1.3GHz CPU 256MB RAM 4GB FLASH NETWORK Ethernet 100BASE-TX WiFi 802.11 bgn Bluetooth 4.0 Radio module (Z-Wave, ZigBee HA, EnOcean, 433 MHz, etc...)* OPERATING SYSTEM Linux (4.x kernel) POWER Power input: 9-12VDC Internal backup battery (900mAh) Power supply input: 100-240VAC, 50/60Hz Power usage: Idle: 1.2W, Max: 2.4 Power over Ethernet* ENVIRONMENTAL Temperature Range: Operating: 0°C to 40°C (32°F to 104°F) Storage: -25°C to 70°C (-13°F to 158°F) Humidity: 5% to 95% non-condensing ACCESSORIES...

Open the catalog to page 2
