Xpelair Inline Fans for Rectangular Ducting
1 / 10 PagesView full catalog
Xpelair Inline Fans for Rectangular Ducting
Product catalog summary
Overview: The document provides detailed information on Xpelair's range of inline fans designed for rectangular ducting, specifically the SwingR and CubeX models. These fans are suitable for applications with space restrictions and offer various configurations and control options.
Specifications:
- SwingR Range: Designed for compact inline applications with rectangular ducts. Features forward curved impellers, external rotor motors, and a robust inspection door. Available in seven sizes with standard 20mm flanges and flexible connectors.
- CubeX Range: Offers higher duty with backward curved impellers and sound attenuation. Suitable for general-purpose applications with interchangeable panels for flexible installation.
Key Features:
- Both ranges are precision manufactured using CNC techniques for high quality and finish.
- SwingR models are fully speed controllable and compatible with Xpelair controllers.
- CubeX models provide flexible installation options with interchangeable panels and sound attenuating insulation.
Performance Data:
- SwingR Models: Airflow ranges from 0.18 to 0.89 m3/s depending on the model and static pressure. Motor power ranges from 235W to 1200W.
- CubeX Models: Airflow ranges from 0.10 to 1.56 m3/s. Motor power ranges from 315W to 960W.
Sound Power Data: Sound levels are provided for various frequencies and configurations, indicating the noise levels at different operational settings.
Installation and Accessories: The document includes dimensions for each model and details on available controllers and accessories, such as flexible connectors and speed controllers.
Conclusion: Xpelair offers a comprehensive range of inline fans for rectangular ducting, catering to various industrial and commercial applications with customizable options and robust performance.
See more
Catalog excerpts
PageNumber96100 FantypeCompactVersatile inlineattenuated Models74 Maxductsize(mm)600x300400* Maxextractrate(m > 3 /s)0.891.56 PhaseSingleSingle*Fansize > InlineFansforRectangularDucting Xpelair|
