Vestas Cold Climate Solutions

Vestas Cold Climate Solutions
2Pages

Catalog excerpts

Availability of Vestas Low Temperature Option V90-2.0 MW™ V100-2.0 MW* V110-2.0 MW* V116-2.1 MW™ V120-2.2 MW™ V105-3.45 MW™ V112-3.45 MW* V117-3.45 MW* V117-4.2 MW™ V126-3.45 MW* V136-3.45 MW* V136-4.2 MW™ V150-4.2 MW™ V138-3.0 MW™ V150-5.6 MW™ V162-5.6 MW™ Availability of Vestas Ice Detection™ V105-3.45 MW™ V112-3.45 MW* V117-3.45 MW* V117-4.2 MW™ V126-3.45 MW* V136-3.45 MW* V136-4.2 MW™ V150-4.2 MW™ V138-3.0 MW™ V150-5.6 MW™ V162-5.6 MW™ Vestas Cold Climate Solutions Ensuring safe and efficient energy production in cold climate conditions The Vestas Cold Climate Solutions build on years of experience ensuring safe and efficient energy production in cold climate conditions. The Vestas Cold Climate Solutions include Vestas Low Temperature Option, Vestas Ice Detection™, Vestas De-Icing™ and Vestas Anti-Icing System™, which can be combined with additional options and solutions such as Vestas Ice Assessment™ and Vestas Ice Control to enhance the performance of the power plant. Vestas Low Temperature Option The Vestas Low Temperature Option enables wind turbine operation in ambient temperatures as low as -30°C and safe withstanding of an ambient temperature as low as -40°C in pause. By using heating elements, it ensures continued and safe operation of temperature-sensitive components. Installed on more than 5,000 turbines worldwide, Vestas Low Temperature Option is a proven high performer in cold climate conditions. Vestas Ice Detection™ The Vestas Ice Detection™ system assesses the ice conditions on the rotor, enabling operational strategies to increase safety. Through sensors installed on each blade, it monitors changes in the natural frequency flow oscillation produced by the turbine operation, enabling to evaluate the risk of ice throw. Vestas' solutions for ice detection also include nacelle-based ice detection, which monitors ice conditions on the nacelle, and power curve-based ice detection, which detects ice build-up through the degradation of the power curve performance.

Open the catalog to page 1

Vestas De-Icing™ Availability of Vestas De-Icing™ V112-3.45 MW® V117-3.45 MW® V117-4.2 MW™ V126-3.45 MW® The Vestas De-Icing™ system maximises the energy production of wind turbines in icy conditions by de-icing the blades. Activated by the Vestas SCADA system, the Vestas De-Icing™ system pauses the turbine operation in order to realise the de-icing action, heating and circulating air within the blades. The energy use of the system is optimised by concentrating the de-icing action on the outer third of a turbine blade full chord and the remaining outer two-thirds of the leading edge towards...

Open the catalog to page 2
