Introduction
Thermador introduces a new line of built-in refrigerators, complementing their kitchen appliance range. These refrigerators feature sleek stainless steel designs with options for curved or Professional handles and custom paneling to match kitchen aesthetics.

Key Features

Elegant, adjustable frameless glass shelves for increased storage capacity.
Filtered water for pure ice production.
Rapid chill freezer shelf available in side-by-side models with internal ice makers.
Adjustable temperature meat storage drawer in side-by-side models.
Humidity-sealed crispers and integrated gallon door storage.
Roller glides for easy drawer access.

Product Variants

36" Bottom-Mount Models: Available with curved or Professional handles, right or left-hand door swing, and custom panel options. Features include an automatic internal ice maker, pull-out freezer drawer, and electronic controls.
42" Side-by-Side Models: Options for internal ice maker or external dispenser, with curved or Professional handles, and custom paneling. Includes adjustable temperature meat storage drawer and rapid chill freezer shelf.
48" Side-by-Side Models: Similar features to the 42" models, with larger capacity and external water and ice dispenser options.

Specifications

36" Bottom-Mount: Total capacity of 20.3 cu. ft. (15.0 cu. ft. refrigerator, 5.3 cu. ft. freezer), shipping weight of 508-548 lbs.
42" Side-by-Side: Total capacity of 25.3 cu. ft. (16.0 cu. ft. refrigerator, 9.3 cu. ft. freezer), shipping weight of 563-613 lbs.
48" Side-by-Side: Total capacity of 29.2 cu. ft. (18.8 cu. ft. refrigerator, 10.4 cu. ft. freezer), shipping weight of 605-659 lbs.

Installation and Requirements

Water line pressure must be between 15-100 psi.
Floor must support over 600 pounds.
Refrigerators can be installed recessed or at the end of cabinets with a side panel.

Warranty

Full parts and labor warranty for the first two years.
Limited parts and labor warranty for the sealed refrigeration system from the 3rd to 6th year.
Parts-only warranty for the sealed refrigeration system from the 7th to 12th year.

Catalog excerpts

Roller glides foreasy drawer access Humidity-sealed crispers Elegant, adjustable frameless glass shelvesoffer increased storage capacityFiltered water provides refreshingly pure iceRapid chill freezer shelf(side-by-side internal ice maker model only) Adjustable temperature meat storage drawer (side-by-side models only) Integrated gallon door storage >

Open the catalog to page 2

> Automatic internal ice maker with convenient,easy-to-change water filter > Elegant, adjustable frameless glass shelves offer increased storage capacity > Integrated gallon door storage > Humidity-sealed crispers > Roller glides for easy drawer access > Pull-out freezer drawer with two largepull-out baskets > Electronic controls > Each refrigerator is individually run-tested and quality-confirmed > Available in right-hand or left-hand door swing > Available in stainless steel with curved or Professional handles, or models which will accept custom paneling > KBURT3651A 36"Bottom-mount stainless...

Open the catalog to page 3

> Available with full-filtered internal ice maker; also available with full-filtered external ice and water dispenser > Elegant, adjustable frameless glass shelves offerincreased storage capacity > Integrated gallon door storage > Adjustable temperature meat storage drawer > Humidity-sealed crispers > Roller glides for easy drawer access > Portable, removable ice storage bucket > Rapid chill freezer shelf (internal ice maker model only) > Convenient, easy-to-change water filter > Electronic controls > Each refrigerator is individually run-tested and quality-confirmed > Available in stainless...

Open the catalog to page 5

> Available with full-filtered external water and icedispenser; also available with full-filtered internal ice maker > Elegant, adjustable frameless glass shelves offerincreased storage capacity > Integrated gallon door storage > Adjustable temperature meat storage drawer > Humidity-sealed crispers > Roller glides for easy drawer access > Portable, removable ice storage bucket > Rapid chill freezer shelf (internal ice maker model only) > Convenient, easy-to-change water filter > Electronic controls > Each refrigerator is individually run-tested and quality-confirmed > Available in stainless steel...

Open the catalog to page 6

** 1 / > 8 "23 > 1 / > 2 "*83 80"-90"Above Floor77" 83 > 1 / > 4 " min.84 > 3 / > 4 " max.to bottom ofsolid soffit > 1 / > 8 "24"PowerCord *3 AWidthHeight A 42" Model : 41 > 1 / > 2 "48" Model : 47 > 1 / > 2 " > 1 / > 2 " Required grounded electrical outlet location4" 6"6"6"11"3"23 > 1 1 / > 2 2 " > Ɔ / "hole for plumbing can be located anywhere within shaded area > *** CUSTOM PANELSTAINLESS STEEL Notes: 1) All height, width and depth dimensions are shown in inches. 2) Water line must provide 15-100 psi water pressure. Rough in water line before installing refrigerator.3) Floor must support refrigerator...

Open the catalog to page 7

FULLFULLLIMITED (PARTS AND LABOR)(PARTS AND LABOR)(PARTS ONLY) 1ST-2ND YEAR3RD-6TH YEAR7TH-12TH YEAR Entire ProductSealed Refrigeration System*Sealed Refrigeration System**Sealed refrigeration system includes compressor, evaporator, condenser, dryer/strainer, and connecting tubing.For complete Thermador warranty details, ask your dealer, refer to Care & Use guide, or visit thermador.com. BSH HOME APPLIANCESCORPORATION CORPORATE OFFICE5551 McFadden Avenue Huntington Beach, CA 92649 WWW.THERMADOR.COM 1 800 656 9226 > SAP# 2800000531 size="-2">
