Ground-breaking comfort modules that provide the highest degree of comfort > PARASOL is the generic name of a family of products consisting of ground-breaking comfort modules with ventilation, heating and cooling functions and with unique comfort features. The PARASOL can be utilized in most types of buildings regardless of type of activities conducted inside them and regardless of the season. The comfort modules operate on a basic principle that is closely akin to that of chilled beams. The differ- ence is mainly that comfort modules distribute air in four directions instead of two. This...

High capacity and optimal comfort qualities achieved by four-way air diffusion that maximises the area for intermixture of supplied air into the room air. Timeless design for use in various environments. Standard variants held in stock enable short terms of delivery. Low sound level. The compact size of the products and packaging makes them easier to transport, handle and install. Great fl exibility for positioning the modules because the air volume and direction of air fl ow can be individu-ally adjusted on each side. The Parasol modules with heating function are ideal for replacing...

4 4 > Registered design. The company reserves the right to make design changes without prior notice. size="-1">

Various room environ- ments are constructed for full-scale tests in Swegons high-tech laboratory. ҰC m/s Swegons full-scale tests of the moduleҒs cool- ing function (above) and its heating function (below) illustrate uniform temperature and low air velocities in the occupied zone. Greatest comfort > C m/s > Registered design. The company reserves the right to make design changes without prior notice. 5 >

A number of ADC > II sections with four air defl ectors per section are arranged on each side of the unit. Each section is adjustable from a straight setting to 40 air defl ection to the right or left in incre- ments of 10а. In that each side of the Parasol is individually adjustable per side to provide the appropriate airfl ow, the comfort modules fi t in well anywhere in the room. Whether they are located at the front edge, centre, rear edge or symmetrically in the room is of no importance. Circular air distributionIrregular air distribution > High fl ow Low fl owLow fl owClosed Several...

PARASOL WITH COOLING AND SUPPLY AIR > Primary air (1) is supplied by the air handling unit. If cooling is required, the cooling circuit in the cooling coil is opened to chill the induced air from the room (2). The primary air and the induced air are then mixed and are distributed to the premises (3). Functional variants > PARASOL WITH COOLING, HEATING AND SUPPLY AIR > Primary air (1) is supplied by the air handling unit. If cooling is required, the cooling circuit in the cooling coil is opened to chill the induced air from the room (2, left-hand image). If heating is required, the heating...

Adjustment to load-carrying T-grid systems Nozzle pressure > Water flow Nozzle pressure > STANDARD > Circular holes arranged in triangular pattern. i Water flow Flow temperature > Flow temperature Cooling and heating capacity > PE > Circular holes arranged in a square pattern with a graduated border. Cooling and heating capacity Capacity - Airflows > PD > Square holes arranged in a square pattern with a graduated border. 8 > Registered design. The company reserves the right to make design changes without prior notice. size="-3">

The LUNA is Swegons latest indoor environmental control equipment for water-based indoor climate systems. It is built around a digital room controller that operates with a PI function in combination with pulse width modulation to provide a healthy climate in the room with small variations in temperature. Digital processors make it possible to change the settings, so that the function can be adapted as required after changes in the nature of the business or refurbishment work. The actuators are thermoelectric and are fitted with an easy-to- interpret operational status indicator. The LUNA...

Recommended types of ceiling > Typical installation of a PARASOL mounted in plaster board ceiling. Typical installation of a PARASOL EX mounted in a suspended ceil-ing with T-grid sections.Example showing a Parasol sus-pended from hangers consisting of SYST MS (assembly piece) acces- sories and threaded rods with nuts and washers. To connect the air > To connect the indoor environment control equipment > 12 > Registered design. The company reserves the right to make design changes without prior notice. size="-2">

Example showing the installation of a PARASOL EX mounted directly against the ceiling. Example showing the installation of a Para-sol EX suspended from hangers consisting of SYST MS (assembly piece) accessories and threaded rods with nuts and washers. The illustration also shows the installation of the connection casing, LUNA control valves and adjustment damper. Condensation-free cooling > To connect the indoor environment control equipment > Registered design. The company reserves the right to make design changes without prior notice. 13 >

C = Cooling water supply and return 12x1.0 mm (Cu)H = Heating water supply and return 12x1.0 mm (Cu) RC = Cooling water return 踸12x1.0 mm (Cu)* SC = Cooling water supply 12x1.0 mm (Cu)* B = Connection piece for primary air 125 mmD = Capped alternative air connection *) For the single-module unit, it is important that the cooling water is connected correctly to the connection pipe. The direction of flow is essential to obtain full capacity. > Parasol L W Parasol Functional Weight Weight variant without with Single-module unit 592; 617; 667 592; 617; 667Double-module unit 1192; 1242; 1342...

RC = Cooling water return 12x1.0 mm (Cu)RC = Heating water return 12x1.0 mm (Cu) RC = Cooling water supply 踸12x1.0 mm (Cu) RC = Heating water supply 12x1.0 mm (Cu) C = Connection piece for primary air 125 mm > Parasol EX Functional Weight Weight variant without with water, kg water, kg Single-module unit Cooling 19.6 20.8 Cooling+heating 19.7 21.2 Supply air 16.9 踖 Double-module unit Cooling 30.2 31.6 Cooling+heating 33.8 36.2 Supply air 28.0 > Registered design. The company reserves the right to make design changes without prior notice.
