Air Handling Units with that little extra! >

Open the catalog to page 1

COMPACT Heat COMPACT Air S i m p l e i n s t a l l a > The COMPACT Air and COMPACT Heat are complete room air handling units that are installed directly in the room to be ventilated. The air handling units are well-suited for use in classrooms, day nurseries, conference halls, work- rooms, shops, restaurants and similar public premises. The ducts for outdoor air and exhaust air are connected to the top of the unit and arranged to lead out through the wall. Other than that, you need only connect the unit to the mains power supply. The installation work can be done very quickly and easily and...

Open the catalog to page 2

COMPACT Unit COMPACT Top G r e a t fl e x i b i l i t y The COMPACT Unit and COMPACT Top are complete air handling units. The air handling units can be utilised in smaller premises such as shops, offices, day nurseries and residential buildings.The COMPACT Unit air handling units have duct con-nection spigots on their end panels, the traditional way, whereas the COMPACT Top units have them at the top. The type of unit can therefore be selected according to the amount of space available for installation and for arranging the ducts.The COMPACT Unit and COMPACT Top are also well suited for...

Open the catalog to page 3

COMPACTsizeWeightkgDimensions mmDuct connectionmmPower supplyAirflow, l/sAvailable pressure Pafor ≤ SFP > v 2,0LengthWidthHeightMin. ≤ SFP > v 2,0Max. Unit 021601246792782 2501x230V, 10A80200230200Unit 031601246792782ؘ 2501x230V, 10A80250360200Top 0220011077881318 2501x230V, 10A80200230200Top 0320011077881318ؘ 2501x230V, 10A80230360200 > COMPACTsizeWeightkgDimensions mmDuct connectionmmPower supplyAirflowl/sSound Level ≤ 30 dB(A) at l/sMin.Max./SFP WidthHeightDepth > v Air 02335 11022114792 2501x230V, 10A80230/1.1230 > 1 Air 03335 11022114792ؘ 2501x230V, 10A80330/1.8250 > 1 Heat...

Open the catalog to page 4
