Overview: The Swegon Ceiling Collection offers a range of air diffusers designed for modular ceilings, providing flexibility in air distribution with options for low installation heights. The collection includes various models such as LOCKZONE, EAGLE, COLIBRI, and HAWK, each with unique features and capabilities.

Specifications: The document provides airflow and sound level data for different models at varying decibel levels (25 dB(A), 30 dB(A), 35 dB(A)). For example, the LOCKZONE model offers airflow rates ranging from 23 l/s to 146 l/s depending on size and sound level.

Product Features:

• LOCKZONE C: Features a swirl terminal with a flush design, suitable for variable airflows and discharging air below room temperature.
• EAGLE C: Equipped with high-capacity discs, allowing substantial cooling capacities without draught risks.
• COLIBRI CC/CR: Offers small discs in circular or square patterns, providing flexibility in spread patterns without affecting airflow or sound levels.
• HAWK C: Combines modern design with high capacity, managing substantial airflows quietly.

Installation and Maintenance: All models fit standard modular ceilings and offer a 'Quick Access' feature for easy opening and maintenance. This feature simplifies installation and commissioning, allowing easy access to measurement hoses and damper controls.

Applications: The collection is suitable for various environments based on ceiling height:

• <3 m: Ideal for hotel rooms, dining halls, classrooms, conference rooms, and offices.
• 3–5 m: Suitable for auditoriums, shopping malls, and lecture halls.

Design and Functionality: The air diffusers are designed for optimal performance with features like adjustable spread patterns, swirl air diffusion, and provision for vertical air discharge. They are tailored for both heating and cooling applications with VAV (Variable Air Volume) systems.
