Product catalog summary
Product Overview:
The document provides technical specifications and mounting options for various models of flex lamps, including TROLL FLEX 230, TROLL KLEMM FLEX, and DESSAU KLEMM FLEX. These lamps are designed for versatile mounting on tables, shelves, walls, and ceilings.

Specifications:
  • Mounting Options: The lamps can be clamped onto surfaces up to 35mm thick or mounted using a canopy for ceiling or wall installation.
  • Control Options: Available with a switch (-S) or a dimmer (-D), although the dimmer version is not available in the US.
  • Design: Designed by Stefanie Hering and Peter Steng, featuring flexible stems and porcelain shades.
  • Dimensions: Various dimensions are provided for different components, such as stem lengths and clamp mounts.

Technical Details:
  • Lamp Types: Compatible with E27, bi-pin, MR11/MR16, and other specified lamps.
  • Voltage and Power: Operates at 230V or 120V with a maximum power of 100W, depending on the model.
  • IP Rating: IP40, indicating protection against solid objects larger than 1mm.

Design and Aesthetics:
  • Stem Colors: Available in various colors and patterns.
  • Porcelain Shades: The TROLL FLEX 12 model features porcelain reflectors for aesthetic appeal.

Recommendations:
  • For optimal performance, use classic reflector or globe lamps with the E27 socket models.
See more

Catalog excerpts

TROLL FLEX-1

TROLL FLEX 230 / TROLL KLEMM FLEX DESSAU KLEMM FLEX / DESSAU FLEX 230 Flexleuchte zum Anklemmen an lische, Regale etc. bis zu einer Materialstarke Wand- und Deckenmontage. Klemmvariante inklusive Zuleitung mit Zwischendimmer = D, Der Flexschlauch wird durch Eindrehen im Steckkontakt gegen Herausziehen gesichert. Montageteile siehe Kapitel Basiselemente. Flexleuchte mit offener E27 Porzellanfassung zum Anklemmen an Tische, Regale etc. bis zu einer Materialstarke von 35 mm oder mit nklusive Zuleitung mit Zwischendimmer = D, mit Schalter = S. Betrieb am besten mit klassischer Reflektor- oder Globelampe E27. Flex lamp for mounting on tables, shelves etc. or with a canopy for mounting on the ceiling or wall. Flex lamp is available with switch (-S) or with Dimmer (-D). Dimmer version not available Flexible stem light with porcelain shade. The fixture is secured against unintentional dis- connection. For use with bi-pin or MR11/MR16 To mount the low-voltage lamp, one of the basic elements from page 150-190 is required. Flex lamp for mounting on tables, shelves etc. 35mm/1.37" or with a canopy for mounting on the ceiling or wall. Available with switch (-S) or with Dimmer (-D). Dimmer version not available Sockel / Clamp mount Sockel / Clamp mount Schirm Dekor / Patterns Gehàuse- und Schlauchfarben / Stem colors Schlauchlàngen / Stem lengths Leuchtmittel / Lamps Schirm Dekor / Patterns Schlauchfarben / Stem colors Schlauchlàngen / Stem lengths Leuchtmittel / Lamps Schlauchfarben / Stem colors Schlauchlàngen / Stem lengths Leuchtmittel / Lamps Design: Stefanie Hering Peter Steng Design: Stefanie Hering Peter Steng Design: Peter Steng

 Open the catalog to page 1
