Light illuminates; but it does a lot more than this. Light is like a building material; it models shapes, it transforms space without moving it, it al- lows the space to be designed and it defines functions without changing the architectural structure. Light is a means of communication; the intensity, the colour, the shades, the transparencies, the movements, the effects and the reflections. It defines the ambience of the room, and in turn it influences the comfort of those who live in that environment. It directs attention to objects, to people, and to their movements. Skilful use of light...

Every light needs its own environment. >

Spotlight: an enthralling combination of technology and design. Light is an important element in the architectural design of space, it sets off details, it warms a room, it defines the edges of darkness, it creates and modifies shade, giving shape and a three-dimensional look to surfaces; it creates emotional situations for those who live in it. Following this philosophy, we have created the Spotlight Architectural range, comprising of a range of luminaires combining high technology with the purest lines of current design. Discharge lamp, with a colour temperature similar to daylight to...

Several beam light adjustment possibilities thanks to various optical lenses, from Cyclorama to Fresnel, to Plano-Convex, to Par.Profile light with precise focusing of the edges, thanks to the use of profile spots with various optics, fixed or adjustable. Suitable for Gobos and images projection. >

Fresnel spot for soft light edge with adjustable light beam. Halogen lamp. Plano-Convex spot with adjustable light beam for a more concentrated light spot. Halogen lamp. Profile spot, fixed-beam and interchangeable optics for different working projection distances. Focus adjustment, ideal for image projections through Gobos. Halogen lamp. Profile spot with variable zoom, for a wider and more flexible use. Halogen lamp. All models are available with discharge lamp for a Daylight type of lighting, with different Colour Temperature, depending on the lamp model. >

Spotlight ARC Video, the easiest and most flexible system to use a video projector as a powerful motorized fixture, for special effects and stage projections, also in non show-businessђ environment. The projections can be enhanced by special dedicated software and can be controlled by the traditional DMX con- soles with the possibility of having lar- ger projections on LED or LCD screens or Plasma panels. The Architectural luminaires, just as in the entertainment market, can be controlled by remote devices such as manual wall panels or memory panels or touch screens. Connected through...

All the Spotlight fixtures can be supplied with hanging yokes making it simple to attach them to, or suspend them from a surface or truss with the appropriate clamp. They can also be used with pre-wired tracks, both carrying mains or low-voltage power and control data signals (DALI or DMX). >

The Par Lucciola uses a lamp with an integral parabolic reflector (similar to a car headlight) where the light source placed at its focus, so that all reflected light rays are parallel. The design of the Lucciola has been successfully tried and tested over the last couple of decades of Spotlight and has been developed and enhanced to recall and highlight new-style fixtures. The Lucciola is ideal for illuminating objects that need to be lit with a concentrated spot or where the small parallel light beam itself has to be in eviden-ce for light design and ambience. The Par lamps are available...

4515 LUT Power (W) 30 - -Beam angle (Degr) 5а - - Lampholder base Screw terminals - - Candle-power (CD) 55.000 - - Avg. rated life (hh) 100 - - Colour Temperature (K) 3.200 - - Colour rendering index (Ra) n.a. - - > SUPERLUT Power (W) 75 75 75Beam angle (Degrа) 8 24а 45 Lampholder base G 53 G 53 G 53 Candle-power (CD) 30.000 5.300 2.000 Avg. rated life (hh) 3.000 3.000 3.000 Colour Temperature (аK) 3.000 3.000 3.000 Colour rendering index (Ra) n.a. n.a. n.a. > HASP/100 (8) HASP/100 (24) HASP/100 (45) SUPERLUT 100 Power (W) 100 100 100 Beam angle (Degr) 8а 24 45а Lampholder base G 53 G 53...

LUT - Lucciola PAR36 Halogen 30W Օ SUPERLUT - SuperLucciola R111 Halogen 75W SUPERLUT 100 HASP/100Օ LUN 100 - SuperLucciola ESD111 100W LUBS 35 - MaxiLucciola ES111 BS 35Օ LUBS 70 CDM - R111 70W/830 180 190 Kg 1,2 212 203 > 248 215 Kg 1,4 > LUT - PAR36 - Net weight Kg 1.4 - Gross weight Kg 1.6 SUPERLUT - Net weight Kg 2.0 - Gross weight Kg 2.1 SUPERLUT 100 - Net weight Kg 2.0 - Gross weight Kg 2.2 LUN 100 - Net weight Kg 0.8 - Gross weight Kg 1.0 LUBS 35 - Net weight Kg 1.3 - Gross weight Kg 1.5 SUPERLUT - Net weight Kg 1.0 - Gross weight Kg 1.2 size="-1">

The quality of light , the compact and the unique technological design on the Mini range allow lighting designers to express their creativity to the full by picking out details , creating soft shades, giving depth, contrast and chromatic atmosphere that would be impossible to obtain with more traditional architectural fixtures. The main models include: miniFresnel, miniPC, miniProfile, miniProfile zoom, miniPAR and miniLED. Each model is manufactured in different versions, depending on your choice of lamp. >

mini NO: Product code M 38 CP 81 CP 82 (*) > MI FN NOMI PC NO MI PR NO MI PR ZS NO (*) non-continuous use mini LW: Product code A1 216 A1 223 (*) JC 20H > MI FN LW MI FN LW/CT MI PC LW MI PC LW/CT MI PR LW MI PR LW/CT MI PR ZS LW MI PR ZS LW/CT Power (W) 150 250 150Beam angle (Degr) n.a. n.a. n.a. Lampholder base G 6.35 G 6.35 G 6.35 Luminous flux (Lm) 5.200 10.000 3.000 Avg. rated life (hh) 50 50 2.000 Colour Temperature (аK) 3.400 3.400 3.000 Colour rendering index (Ra) n.a. n.a. n.a. (*) non-continuous use mini MC: Product code CDM T 150/830 CDM SA/T CDM TD 150/942 > MI FN MCMI FN MC/SBA...

MI PAR T75 Power (W) 75 75 75Beam angle (Degr) 8а 24 45а Lampholder base G 53 G 53 G 53 Candle-power (CD) 30.000 5.300 2.000 Avg. rated life (hh) 3.000 3.000 3.000 Colour Temperature (K) 3.000 3.000 3.000 Colour rendering index (Ra) n.a. n.a. n.a. > ESD111 H 100/10 ESD111 H 100/24 MI PAR N100 Power (W) 100 100 - Beam angle (Degrа) 10 24а - Lampholder base GZ 10 GZ 10 - Candle-power (CD) 12.000 5.000 - Avg. rated life (hh) 2.000 2.000 - Colour Temperature (K) 2.900 2.900 - Colour rendering index (Ra) n.a. n.a. - > ES111 BS 35/8 ES111 BS 35/24 ES111 BS 35/45 MI PAR BS35 Power (W) 39 39 39Beam...
