Uniclass JG30:L681 CI/SfB (27) Mh March 2010 YOUR ROOFING AND WATERPROOFING PARTNER PROFILED METAL DECK SYSTEMS

2 www.flag-soprema.co.uk High quality flexible systems for profiled metal roofing Sopracover warranties Flag-Soprema provides a range of comprehensive warranties from 10 to 20 years as standard on all our systems under the name of Sopracover. This insurance-backed warranty covers both product and workmanship, depending on the design life of the system. There is no minimum surface area treated or project value required to qualify for the warranty. Contents Performance and design flexibility 3 Product information 4 The range of Metadeck profiles 5 Steel unperforated decks 6 n FS32 6 n FS35 8...

Introduction Versatile metal roofing Flag-Soprema Metadeck is available in a range of profiles in galvanised steel or aluminium, with a choice of colours and finishes. Roll-forming of profiles provides both strength and visual character. Metadeck profiled metal offers structural and aesthetically pleasing solutions to modern industrial roofing. Profiles are available perforated or unperforated. Selecting a profile, material, deck thickness and acoustic performance will depend on the type of application, the required span, roof loading, required finish and aesthetic considerations. Our...

4 www.flag-soprema.co.uk High quality flexible systems for profiled metal roofing Product information A wide ranging choice of system components Metadeck profiled metal roofing systems are available in galvanised steel or aluminium. Galvanised steel to EN 10147 S320GD + Z275 in a range of gauges including 0.75mm, 0.88mm, 1.00mm, 1.13mm, 1.25mm and 1.50mm. Aluminium 3004 grade in 1.25mm and 1.5mm thicknesses. Standard internal finish is off-white 15-micron RAL 9002 polyester. 25-micron polyester is available for external applications or more aggressive internal atmospheres. Other colours and...

40 www.flag-soprema.co.uk High quality flexible systems for profiled metal roofing FS137AL system design and performance Aluminium, unperforated Ultimate section properties Load tables – working loads aluminium decking Single span – imposed loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 4.32 3.53 2.91 2.43 2.05 1.74 1.49 1.29 1.12 0.97 1.50 5.21 4.25 3.52 2.94 2.47 2.10 1.80 1.55 1.35 1.17 1.03 0.90 Single span – suction loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 6.76 5.95 5.28 4.71 4.24 3.83 3.48 3.17 2.80...

YOUR ROOFING AND WATERPROOFING PARTNER T: 0845 1948727 41 FS153AL system design and performance Aluminium, unperforated Ultimate section properties Load tables – working loads aluminium decking Single span – imposed loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 5.68 4.64 3.84 3.20 2.70 2.30 1.97 1.70 1.48 1.29 1.13 0.99 1.50 6.86 5.60 4.63 3.87 3.26 2.78 2.38 2.05 1.78 1.55 1.36 1.20 1.06 0.94 Single span – suction loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 8.37 7.37 6.53 5.83 5.24 4.74 4.30 3.93 3.60 3.23...

42 www.flag-soprema.co.uk High quality flexible systems for profiled metal roofing Load tables – working loads aluminium decking Single span – imposed loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 6.80 5.55 4.59 3.84 3.24 2.75 2.36 2.04 1.77 1.54 1.35 1.19 1.06 0.94 1.50 8.20 6.70 5.54 4.63 3.90 3.32 2.85 2.46 2.13 1.86 1.63 1.44 1.27 1.13 1.01 Single span – suction loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 9.70 8.53 7.57 6.76 6.07 5.49 4.98 4.55 4.17 3.83 3.42 3.05 2.73 2.45 1.50 11.70 10.30 9.14 8.16 7.33...

YOUR ROOFING AND WATERPROOFING PARTNER T: 0845 1948727 43 Ultimate section properties Load tables – working loads aluminium decking Single span – imposed loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 4.14 3.38 2.79 2.33 1.97 1.67 1.43 1.23 1.07 0.93 1.50 5.00 4.08 3.37 2.82 2.37 2.02 1.73 1.49 1.29 1.13 0.99 Single span – suction loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 6.19 5.44 4.83 4.31 3.88 3.50 3.18 2.90 2.66 2.36 1.50 7.70 6.77 6.00 5.36 4.82 4.36 3.96 3.61 3.23 2.85 2.53 Double span – imposed loads –...

44 www.flag-soprema.co.uk High quality flexible systems for profiled metal roofing Ultimate section properties Load tables – working loads aluminium decking Single span – imposed loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 5.55 4.53 3.74 3.13 2.64 2.25 1.92 1.66 1.44 1.26 1.10 0.97 1.50 6.69 5.47 4.52 3.78 3.19 2.71 2.32 2.00 1.74 1.52 1.33 1.17 1.04 0.9 Single span – suction loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 7.98 7.02 6.22 5.56 4.99 4.51 4.10 3.74 3.43 3.15 2.79 2.49 1.50 9.66 8.50 7.54 6.73 6.05...

YOUR ROOFING AND WATERPROOFING PARTNER T: 0845 1948727 45 Ultimate section properties Load tables – working loads aluminium decking Single span – imposed loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 6.64 5.42 4.48 3.75 3.16 2.69 2.31 1.99 1.73 1.51 1.32 1.17 1.03 0.92 1.50 8.01 6.54 5.41 4.52 3.82 3.25 2.78 2.40 2.09 1.82 1.60 1.41 1.25 1.11 0.99 Single span – suction loads – kN/m2 Span m 3.0 3.2 3.4 3.6 3.8 4.0 4.2 4.4 4.6 4.8 5.0 5.2 5.4 5.6 5.8 1.25 9.23 8.12 7.20 6.43 5.78 5.22 4.74 4.33 3.96 3.65 3.33 2.66 2.39 1.50 11.20 9.83 8.71 7.78 6.99...

46 www.flag-soprema.co.uk High quality flexible systems for profiled metal roofing n Decks should be fixed with at least one fixing in each trough of the profile to every support. Side laps of decking sheets must be fixed at 450mm maximum centres. n Main fixings are normally 5.5mm diameter self-drilling and tapping screws with washers – eg, Hilti DX76 shot-fired fasteners, or self-tapping screws when the thickness of the steel support is greater than 12mm. Power-driven fasteners can be faster and more economical for steelwork over 6mm thick. With aluminium decks use stainless steel...
