Solatube Idea Book
14Pages

Residential 8 > Multi-Family Housing 10 > Education 12 > Offi ce 14 > Retail 16 > Warehouse/Industrial 18 > 24 > Flashings and Accessories 26 p. 2 > SOLATUBE.COM SOLATUBE.COM p. 3 >

Patented daylight-capturing dome lens Օ Redirects low-angle sunlight > CAPTURE zone Rejects overpowering summer midday sunlight > Sunlight is captured by the domeand directed down into the tube. Օ Consistent lighting throughout the day > ٕ Patented in-dome refl ector Redirects low-angle winter sunlight Օ Increases light input for increased light output Unsurpassed year-round performance > TRANSFER zone WorldՒs most refl ective tubing > Sunlight is directed downward through the attic. 99.7% spectral refl ectivity > Օ Purest color rendition possible At the heart and soul of every Solatube...

ANGLE ADAPTERS > Standard on all Solatube Daylighting Systems, angle adapters are simple to install and make navigating around attic obstructions a breeze. With the amazing refl ective qualities of Spectralight Infi nity inside the tube, you wonΒt have to compromise light transfer performance, even when using the optional 0-90 degree extension tubes. We didnt just design our Solatube > Ү products with natural lighting in mind. After all, theres more to creating a Daylighting System than meets the eye. Our engineers thought through even the smallest nu-ances and came up with products that...

SOLATUBE.COM Use Light Add-On Kit in hallways. Օ Add visual interest with multiple unit designs. For cleaner ceilings, combine the Solatube > ծ Light Add-On Kit with the Ventilation Add-On Kit. Shea Homes > SOLATUBE.COM

SOLATUBE.COM Use Solatube > ծ 290 DS for stunning stairwells. Bring natural light to the fi rst fl oor by using a chase and running it down a closet. Օ Use larger Daylighting Systems when specifying darker fi nishes. Carter Reese and AssociatesGreen Design Bigelow Homes > SOLATUBE.COM

Tucker Sadler Noble Castro ArchitectsTucker Sadler Noble Castro ArchitectsTucker Sadler Noble Castro Architects Nacht Lewis Architects > SOLATUBE.COM ҕ Use daylight chases with Solatube > 21-C to provide daylight on multiple fl oors. Ε Use the Solatube > 21-O for gyms. Ε Incorporate the Daylight Dimmer in all classrooms for lighting control. > SOLATUBE.COM

Architect: Environmental Dynamics, Inc. Architectural Concepts > SOLATUBE.COM Use Daylight Dimmers in conference rooms. Օ Consider daylight controls for energy effi ciency. The Solatube > ծ Daylighting System can easily accommodate future space reconfi gurations. > SOLATUBE.COM

Lighting Designer: Benya Lighting Design Lighting Designer: Color Lume > SOLATUBE.COM Apply daylight for perfect color rendition of products Օ Dont be limited by lighting power density requirements, use the Solatube > Ү Daylighting System to create illumination Use the Solatube > ծ 21-C and 21-O for powerful, visual excitement. > SOLATUBE.COM

SOLATUBE.COM Use photo controls to eliminate use of electric lighting during daylight hours. Օ Use the Solatube > 21-O for easy retrofi t installations from the roof. Ε Place Solatube > Daylighting Systems over aisles and between pallet racking. > SOLATUBE.COM

Model Tube Size EDCS* Light Coverage Area Potential Tube Length For outstanding light diff usion that artfully blends to the ceiling plane, select the Vusion diff user. e fresh design harmonizes with most d٩cors, yet provides the radiance of natural light. > (residential)(diameter) Bathrooms Օ Hallways/Corridors Utility Rooms Օ Dens/Home Offices > Ε Kitchens Dining Rooms Considered the ultimate in diff user design, this technologically superior diff user uses a Fresnel lens to deliver crystal clear daylight and a unique view of the sky. Օ Closets > Eliminate unwanted glare or reduce light...

Ventilation Roof Vent Cap is for use with the Ventilation Add-On Kit (if no vent exists). Comes with gravity damper to prevent back fl ow. > 0-90 Degree Extension TubeExtension Tube *Patent 7,082,726 Flashing Insulator Ventilation Booster Motor Kit. Use with Ventilation Add-On Kit when extended duct requires additional air velocity. Add a Daylight Dimmer to control light output to any desired light level, making it ideal for bedrooms and offi ces. (Switch kit sold separately.)Daylight Dimmer Switch Kit (sold separately) includes DPDT switch, wall plate and 15 ft/4.5 m of cable. Multiple...

e innovative design of our OptiView > ή diff user delivers the cleanest, purest natural daylight imaginable. A matrix of individual Fresnel lenses off ers a unique view of the sky above and also provides unrivaled and highly engineered diff usion. > Tube Diameter - 21 in/530 mm The Solatube 21-C features a patented transition box that seamlessly converts the round tubing to a square diffuser. This transition box easily fi ts into standard commercial ceiling grids. The Solatube modular design offers the ability to be reconfi gured when spaces need to change. For hard ceilings, the transition...

A full selection of durable fl ashings ensures leak-proof, hassle-free installations on virtually any roof type and pitch. e Solatube self mounted fl ashings eliminate the need for expensive curbs and can be integrated into the roofi ng system for a worry-free installation. Daylight Dimmer Open Ceiling Trim Ring > Use the Daylight Dimmer* to control light output to any desired light level. Accepts power supplies ranging from 90 to 277 volts AC. It is ideal for conference rooms, classrooms and offi ces. For use with the Solatube 21-O, the trim ring provides a fi nished appearance to the...
