Elegant, low-profile linear floor drain

•        Install at walls or intermediate locations •        Ensure a simple, waterproof drain connection •        Slope floor on single plane and incorporate large-format tile •        Choose from two brushed stainless steel grate designs for a modern look or tileable covering support for virtually invisible drainage •        Choose from a range of lengths •        Accommodate any thickness of ceramic tile or stone covering •        Create barrier-free, open-concept spaces

As bathrooms break away from boring, comfort and beauty have become must-haves, instead of nice-to-haves. Bathrooms are now areas of retreat—an oasis, really, in the comfort of home. Design freedom Schluter®-KERDI-LINE is an elegant, low profile linear floor drain specifically designed for bonded waterproofing assemblies in showers, steam rooms, wet rooms, and other applications that require waterproofing and drainage. Shower bases must be sloped from all directions to point drains, therefore limiting tile selection to mosaics or other relatively small-format tiles. However, shower bases can...

Grate options Brushed stainless steel frame and closed-design grate Available in three elegant grate designs: brushed stainless steel frame with closed or perforated grates for a striking modern look, or frameless tileable covering support to seamlessly blend in with the surrounding tiles. The grate assembly can be adjusted to a wide range of ceramic tile or stone covering thicknesses, while the covering support is placed flush with the channel body and can therefore accommodate any thickness covering. Drain placement Brushed stainless steel frame and perforated grate Install KERDI-LINE adjacent...

KERDI-LINE components 1 Channel body and support • • Formed stainless steel channel body with 2" no-hub outlet (coupling included) • Channel body is available with either center or off-set drain outlet • Foam channel support sets the drain flush with shower tray • Integrated bonding flange with Schluter®-KERDI collar ensures a simple and secure connection to the bonded waterproofing assembly • Two brushed stainless steel design grate options: closed design or square perforations • Two grate frames accommodate 1/8" to 1"-thick tiles • Frameless tileable covering support provides virtually invisible...

A complete shower system Combine KERDI-LINE with the Schluter®-Shower System and KERDI-BOARD building panels to create an integrated moisture management solution for the tiled bathroom of your dreams. Moisture Management The KERDI bonded waterproofing membrane and vapor retarder provides superior moisture management as it does not permit moisture to penetrate into the mortar base or solid backing on walls, allowing the assembly to dry completely between uses, thus eliminating leaks and mold growth within the system. Prefabricated Shower Components Prefabricated polystyrene foam shower trays,...

All product names are registered trademarks of Schluter Systems K.G. and licensed to Schluter Systems L.P. Schluter Systems L.P. • 194 Pleasant Ridge Road, Plattsburgh, NY • 12901-5841 • Tel.: 800-472-4588 • Fax: 800-477-9783 Schluter Systems (Canada) Inc. • 21100 chemin Ste-Marie, Ste-Anne-de-Bellevue, QC H9X 3Y8 • Tel.: 800-667-8746 • Fax: 877-667-2410 [email protected] For further details and installation instructions, please refer to our product data sheet or visit www.kerdi-line.com.
