RACK CONVEYOR DISHWASHER SRC-2200

RACK CONVEYOR DISHWASHER SRC-2200
2Pages

Catalog excerpts

Sales Description Washing + rinsing. 2 speed. RACK CONVEYOR DISHWASHER SRC-2200 85/126 baskets per hour (up to 2.200 plates/hour) Features and Benefits 9 Fully stainless steel jacket. 9 Inlet and outlet splash guards are standard. 9 Stainless steel central rack feed system. 9 Process cycles are divided by rubber curtains. 9 Automatic cycle start. Economy 9 Energy saving rinse supply switch. 9 Pressure controller in the rinse section to limit consumption. 9 Programmed automatic stops if there is no loading. 9 Stop and freezing of timer when the limit switch actuates. Cleaning and maintenance 9 Wide pivoting door allowing access for cleaning or inspection purpose. 9 Detachable arms and dispersers for easier cleaning. 9 Sloped removable stainless steel filters with independent removable basket. 9 Easy boiler emptying by loosening a hose. 9 Failures are easily detected thanks to the warning lights. 9 Easy to repair without moving the machine. Washing 9 Stainless steel wash arms and deep-drawn dispersers. 9 Efficient and durable wash arm dispersers. 9 Powerful, self-draining vertical wash pump. 9 Easy to install detergent dispenser intake in washing tank. Rinsing Rinsing 9 Stainless steel rinse arms and powerful, stainless steel, deep-drawn dispersers. 9 Automatic boiler filling with no failure risk for heating elements. 9 Temperature control with high precision probes. 9 Visualisation and adjustment of washing and rinsing temperatures in the digital display by pressing a button. 9 Easy to install rinse aid dispenser intake in boiler. Includes 9 Inlet and outlet splash guards Accessories □ Drying units □ Manual water softeners □ Automatic water softeners □ 500 x 500 mm. baskets □ Inserts, supplements & similar □ Loading table for corner situation for rack conveyor dishwashers □ Central sorting tables □ Double connection central sorting table □ Single exit tables □ Roller conveyor and corner roller conveyor □ Machined curve □ CA Extraction hood □ EV Extraction hood with motor □ CV Extraction hood with steam condensation □ Connecting tables for Pass-Through dishwashers and rack conveyors □ Drying unit for corner situation ♦ SammiC | www.sammic.com Food Service Equiment Manufacturer Poligono Basarte, 1. 20720 Azkoitia, Spain

Open the catalog to page 1

Specifications Production 9 Production baskets/hour: 85 / 126 9 Production plates/hour: 1530 / 2200 Wash 9 Temperature: 55 °C - 65 °C 9 Wash tank capacity: 100 l 9 Pump: 3 Hp / 2250 W 9 Wash heating element: 9000 W Rinse 9 Temperature: 80 °C - 90 °C 9 Water consumption: 300 l/h 9 Rinse heating element: 18000 W 9 Boiler capacity: 20 l Drag 9 Drag motor power: 0.25 Hp / 180 W Loading 9 Central module total power : 29580 W External dimensions (WxDxH) 9 Width: 1700 mm 9 Depth: 829 mm 9 Height: 1520 mm Net weight: 250 Kg RACK CONVEYOR DISHWASHER SRC-2200 $ 85/126 baskets per hour (up to 2.200...

Open the catalog to page 2
