ANDHO midi

ANDHO midi

Product catalog summary

Product Overview: The ANDHO midi spotlight is a surface-mounted LED projector designed for ceiling, pedestal, and wall mounting. It features a timeless design with a die-cast aluminium housing that is seawater resistant and powder-coated in a silver, matt finish (approx. RAL 9006). The spotlight includes an integral membrane valve for pressure compensation and condensation avoidance.

Specifications:

Dimensions: Length 199 mm, Width 154 mm, Height 192 mm
Weight: 3.4 kg
Light Source: LED with a colour temperature of 3000 K
Luminous Flux: 3750 lm
System Power: 41 W with an efficiency of 91 lm/W
Glare Evaluation: UGR (4H 8H) 20
Beam Angle: 9°
Rated Life: 50000 hours (L80/B10)
Colour Rendering Index (CRI): 80
Colour Tolerance: 3
Photobiological Safety: EN 62471 Risk group 1
Driver: Integrated, dimmable with DALI control
Voltage: 220 - 240 V / 50 - 60 Hz
Protection: IP 65, Protection class II
Impact Resistance: IK08
Ambient Temperature: -20 °C to +30 °C
Conformity: CE mark

Performance and Safety: The spotlight offers a horizontal rotation range of 360° and a vertical swivel range of 90°, with lockable orientation. It is equipped with MIRO-SILVER® reflectors for efficiency or polycarbonate lenses for uniform light distribution. The cover is made of clear single-pane toughened glass.

Electrical and Installation Details: The spotlight can be connected to various fuses, with specific luminaire counts for B10A, B16A, C10A, and C16A fuses. It has an inrush current of 5 A with a duration of 50 µs. The filament test is rated at 960°C for 30 seconds.

Accessories: Available accessories include a snap-on hood, barn door shutter, louvres, and reeded glass.

Catalog excerpts

ANDHO midi 722179.004.76 | Spotlights Spotlights 4051859759492 L 199, B 154, H 192 Ceiling mounting, pedestal mount, Wall (surface) silver, matt (approx. RAL 9006) Surface-mounted LED projector in a timeless design. Housing: die-cast aluminium, seawater resistant powder-coated. Integral membrane valve for pressure compensation and avoidance of condensation. MIRO-SILVER® reflectors for outstanding efficiency or polycarbonate lenses for the best uniformity of the light cone. Cover clear single-pane toughened glass, edge printed. COB LED with socket for easy replacement. Projector: horizontal rotation range: 360°, vertical swivel range: 90°. Lockable projector orientation. Driver integrated. Product specifications Length L Width B Height H Weight Light source Colour temperature Rated luminous flux System power System efficiency Glare evaluation UGR (4H 8H) Beam angle Rated life Colour rendering index (CRI) Colour tolerance Photobiological safety according to EN 62471 Driver Control Voltage Luminaires on B10A fuse Luminaires on B16A fuse Luminaires on C10A fuse Luminaires on C16A fuse Inrush current / Inrush current duration CIE Flux Code / CEN Flux Code Type of protection Protection class Filament test Impact resistance Ambient temperature Conformity mark © RZB Rudolf Zimmermann, Bamberg GmbH | www.rzb-lighting.com | Specifications subject to alteration | as at 10.07.202

Open the catalog to page 1

ANDHO midi 722179.004.76 | Spotlights Accessories 982166.003 Snap-on hood 982169.003 Barn door shutter © RZB Rudolf Zimmermann, Bamberg GmbH | www.rzb-lighting.com | Specifications subject to alteration | as at 10.07.2024

Open the catalog to page 2
