CATALOGUE GENERALE 2010
96Pages

2 WITH EN COMPLYING automatismi per cancelli automatic entry systems We declare that Operators and Accessories are conform to the following Norms:* You can also install according to the following Norms:* As provided by the following Directives:* Each product can not work alone and was designed to be fitted into a system made up of various other elements. Hence, it falls within Article 6, Paragraph 2 of the EC Directive 2006/42 (Machines) and following modifications. *The Norms and Directives presented do not belong to any single product. For each type of product there are one or more...

3 WITH EN COMPLYING NEWS WI-FI 4 BOSS 6 THE MISSION 8 AUTOMATIONS FOR SLIDING GATES K500 10 K 12 SUPER 14 AUTOMATIONS FOR SWING GATES PRINCE 16 KING 18 PREMIER 20 MAGIC REV 22 DUKE 24 IDRO 26 R 28 RAISING BOLLARDS STOPPER T 30 AUTOMATIC BARRIERS PRESIDENT 35 RAPID PARK - RAPID S - RAPID N 36 NORMAL 40 INDUSTRIAL 42 CHAIN BARRIERS STOPPER 44 AUTOMATIONS FOR ROLLING SHUTTERS AND AWNINGS JACK 46 AUTOMATIONS FOR SPRING BALANCED ROLLING SHUTTERS JOLLY 48 JOLLY ONE 49 JOLLY BIG ONE - JOLLY BIG TWO 50 AUTOMATIONS FOR UP-AND-OVER GARAGE DOORS BOSS 24V IP44 - BOSS 230V IP44 52 AUTOMATIONS FOR...

4 Wi-Fi Save time and money with the new RIB Wi-Fi system. The accessories require no cables, wiring or conduits because the MASTER WIFI manages, beside from the remote control, all the accessories specifically designed in Wi-Fi mode. MASTER Wi-Fi looks like a standard radio receiver, but it does more than just command the MOON and SUN remote controls. It simultaneously and remotely manages the BLOCK Wi-Fi key selector switch, the NOVA Wi-Fi photocells, the TOUCH Wi-Fi strip and the SPARK Wi-Fi blinker. It is the ideal solution for bringing existing systems up to the Standards, as well as...

5 WITH EN COMPLYING NEWS 2010 news 2010 The NOVA Wi-Fi photo sensors are the first to have battery operated transmitters and receivers, which work in remote mode. They operate with 2 sets of standard AA alkaline batteries that last up to 3 years. The product is fully certified and is derived from the RED radio-relay system, the first to obtain EN13849-2 (2008) certification, with class 2 validation. The posts provided with the system make it easy to add extra photo sensors to existing systems in order to bring it up to the Standards. The TOUCH WI-FI sensitive edge is the first strip in the...

6 BOSS pag. 52 ALL THE BEST OF TECHNOLOGY BOSS is a very up-to-date operator. It contains the state of the art of mechanics, power and long-lasting concept, beside an advanced electronics, all complying with EN norms. Among its most important features: • led lighting instead of tungsten bulb: first in the world; • automatic self-adjusting of the torque in every cycle, in order to allow for frictions arising during the time and reversing the travel also in case of impact during slowing down, according to Norms specifications; • complying with EN12453 and EN12445 impact norms, it allows you...

7 WITH EN COMPLYING news 2010 NEWS 2010 PATENTED MECHANICS Internal gearings are made of C40 steel, aluminium and bronze, no plastic, nylon or Teflon. In addition, in order to eliminate internal gap and to get more elasticity for protecting mechanics from shocks, BOSS operator is endowed with a special internal belt (patent n. BS 2001 U 000003) that makes the travel always very quiet, safe and stable. UNLOCKING SYSTEM Standard version comes out with right hand side release. Left hand side release can be useful to improve the look of installations when 2 operators are fitted on big garage...

8 automatismi per cancelli automatic entry systems ALMOST 40 YEARS OF EXPERIENCE Since 1971 RIB has been dedicating to the design and production of long lasting automatic entry systems suitable for an intensive use. Great power for heavy industrial gates. From its set up, RIB produces its operators facing the most competitive market, standing out where others are hardly trying to begin. With such requirements RIB has been developing its technology through the years up to now, both in the civil and in the industrial business sector. The high quality standard of the goods made RIB known...

9 MADE IN ITALY The mission In over thirty-seven years’ activity, RIB has been expanding to its current dimensions and capability and it is now a highly specialised company. But an ambitious company like RIB is always seeking new and better solutions. FROM DESIGN . . . Gate control mechanisms, principally used outdoors, must guarantee reliability and durability at all levels. And this is why RIB has its own fully equipped departments where engineers design, develop and build the electronic and mechanical parts and perform rigorous final tests using very advanced methods and equipment. It is...

10 274 245 42,5 267 K500 K500 FAST kg 500 m/s 0,160 0,35 N 400 520 V 230 A 1,21 1,87 4 kg 8 IP 54 °C -10 ÷ +55 300 200 60% 25/5m K500 WITH EN COMPLYING AA33694 AA33753 AA33753W AA33695 AA33750 TECHNICAL DATA Max. gate weight Operating speed Max. thrust force Power supply Power absorbed Rack module Actuator weight Protection grade Operating temperature Daily cycles suggested Service Nr of consecutive cycles guar. IRREVERSIBLE OPERATOR FOR RESIDENTIAL SLIDING GATES K500 without control board K500 complete with K2007 control board K500 complete with K2007 Wi-Fi control board K500 complete with...

11 KITK500 See page 57 for sliding gates ACS9000 Module 4 RACK (sect. 25 x 22 mm) in Nylon with right-angle (up to 1000 kg) in 1 m bars per m ACS9001 Set 10 m ACS9040 Module 4 RACK in iron (sect. 22 x 22 mm) with right-angle member (up to 2200 kg) recommended for K500 FAST in 2 m bars per m ACS9050 Module 4 RACK in iron (sect. 22 x 22 mm) with CATAPHORESIS treatment, right-angle (up to 2200 kg) recommended for K500 FAST - in 2 m bars per m ACG8672 RELEASE LOCK WITH ALLEN KEY ACG4665 PROBE for K2007-CRX to keep the motor warm (for prompt start at low temperatures) ACG8108 BASE PLATE for K500...
