Performance meets convenience The right temperature at the right time. Quadra-Fire pellet inserts are trouble-free, fully automatic* heat sources for any size home. Whether you prefer traditional styling or a more modern design, these pellet inserts—like all Quadra-Fire hearth products—are the most proven and advanced heating appliances available. All Quadra-Fire pellet inserts are approved to burn wood pellets, or a mixture of wood pellets and shelled corn. The Mt. Vernon AE Insert is approved for additional fuels. Cover: Mt. Vernon AE Insert shown in sienna bronze with standard black...

Mt. Vernon AE INSERT With its exclusive Advanced Energy technology, the Mt. Vernon AE Insert delivers bold performance with ease. Featuring exceptionally quiet operation, a large hopper and flexible fuel options, the Mt. Vernon AE Insert is the best pellet insert available. Simply choose the desired fuel from the intelligent wall control and the Mt. Vernon AE Insert does the rest, automatically adjusting to deliver the right heat at the right time. Mt. Vernon AE Insert shown above in sienna bronze with standard black panel, optional cast iron trim in sienna bronze and optional log set....

Step 2 Choose your insert There are two main factors to consider when selecting an insert. First, consider the height of your existing fireplace opening. You’ll want to choose the tallest insert that will fit into your existing fireplace. Second, consider how the insert will be used. Do you have a large room, do you want a lot of heat or a little, and how long do you plan to run the fireplace? These answers will direct you to the insert that is ideal for you and your home. Distance from Firebox to Mantel Back Width Depth from front to back Front Width Height from hearth to top of the...

Pellet Inserts Features • 8,000 to 30,000 Btu/Hour Input* • Three heat settings • Herringbone brick interior • Thermostat control • Aluminum tube heat exchanger Options • Choose from classic black finish, mahogany porcelain finish, or sienna bronze or willow baked enamel finish • Panel sets with or without cast iron trim • Four-piece log set • Extra top log • Programmable thermostat • Remote controls Features • 14,000 to 40,000 Btu/Hour Input* • Three heat settings • Large bay door • Thermostat control • Adjustable hopper height • 24" aluminum tube heat exchanger Options • Door in black,...

Pellet Inserts Step 3 Choose your surround To bring a finished and polished look to your new insert you need a matching metal surround to cover the gap between the insert and your existing fireplace opening. Offered in three standard sizes and two color options including, Black and Sienna Bronze, you’re sure to find the perfect fit for your space. Step 4 Customize your insert A wide range of options are available to create a truly customized insert. Choose from unit specific log sets, stunning finish options and decorative details along with distinct surrounds and controls. A Quadra-Fire...

PELLET INSERT SPECIFICATIONS Technical Data Performance Width Outside Fireplace Width Inside Fireplace Height Outside Fireplace Height Inside Fireplace Depth Inside Fireplace Weight (lbs) Heating Capacity* (sq. ft.) Btu/hour Input** Burn Rate (lbs/hour) Hopper Capacity (lbs) Particulate Emissions (g/hour) Mt. Vernon Insert 36-5/8" 32" 29-3/4" 23-7/8" 15" 425 up to 3,100 14,620 to 60,200 1.7 - 7† 56 EPA Compliant Castile Insert 32-5/16" 28-1/16" 24-3/4" 19" 13-1/16" 260 up to 1,500 8,000 to 30,000 1.5 - 4 45 .7 Classic Bay 1200i 28-1/2" 29-1/4" 25-1/2" 22" 13" 243 up to 2,500 14,000 to...

QDF-1015U-0810 IMPORTANT - READ BEFORE YOU INSTALL! Refer to the Owner/Installation Manual for complete clearance requirements and specifications. The images and descriptions in this brochure are provided to assist you in product selection only. Quadra-Fire is a registered trademark of Hearth & Home Technologies. Product specifications and pricing subject to change without notice. A brand of Hearth & Home Technologies® 1445 North Highway, Colville, WA 99114 www.quadrafire.com | 800-926-4356 Limited Lifetime Warranty** The strongest in the industry, Quadra-Fire provides a limited lifetime...
