Slideways

Product catalog summary

Main Components:

Rail Endcap: Provides a finished look and protection for the rail ends.
Softclose: Ensures smooth and quiet closing of doors.
Anti-jump Protection: Prevents the door from jumping off the track.
Floor Guide: Keeps the door aligned and stable.
Universal Mounting Bracket + Wheels: Facilitates easy installation and movement.

Specifications:

Ceiling Height: Minimum advised is 85 cm.
Doorway Height: Various measurements provided for different configurations.
SAW Dimensions: Includes specific measurements for ceiling and wall mount possibilities.
Aluminium Profiles: Includes SAW-RAIL and SAW-ADKK (cover profile).

Procedures:

Softclose & Positioning: Easy to adjust the position for optimal functionality.
Door Height Adjustment: Loosen bolts to lower the door, tighten to maintain structure. Maximum lowering is 5 mm.

Recommendations:

Use lines to keep mounting bracket/wheels level for proper installation.
Ensure magnets are used to keep the cover profile in place.

Key Features:

'Smooth Comfort' Function: Allows doors weighing 60-120 kg to open with minimal force.
Clip-on Derail Protection: Provides additional safety by preventing derailment.

Catalog excerpts

Main components Universal mounting bracket + wheels Rail magnets Anti-jump protection Rail endcap Floor guide Rail endcap

Open the catalog to page 2

ceiling height Ceiling height Doorway height Doorway height Doorway height Doorway height Doorway height SAW dimensions Wall mount possibilities Ceiling mount possibilities Min. 120

Open the catalog to page 3

SAW-ADKK (cover profile)

Open the catalog to page 4

Overlap dimensions Rail endcap

Open the catalog to page 5

Softclose & positioning easy to adjust position 60-120 kg with 'smooth comfort' function: door opens with minimal force

Open the catalog to page 7

Rail end cover plate

Open the catalog to page 8

Rail & cover profile magnets Magnet retainer Magnets keep cover profile in place

Open the catalog to page 9

Derail protection Clip on derail protection Clip on derail protection

Open the catalog to page 10

Floor guide

Open the catalog to page 11

Door height adjustment loosen bolts to lower door Use lines to keep mounting bracket/wheels level Lower max 5 mm! = dashed line is lowest level! tighten bolts to recreate rigid structure

Open the catalog to page 12
