Overview

The document is a technical manual for the OPTEX SX-360Z, a 360° ceiling mount passive infrared (PIR) detector designed for security applications. It details the product's features, specifications, detection patterns, installation guidelines, and operational functions.

Key Features

• 360° Detection Coverage: Provides full circular coverage when mounted on the ceiling.
• Highly Dense Detection Zones: The sensor uses a patented multi-focus lens to create a dense pattern of detection zones, enhancing sensitivity and reducing blind spots.
• Zoom Function / Pattern Adjustment: Allows adjustment of detection range and pattern to suit different installation environments.
• False Alarm Protection: Incorporates technology to minimize false alarms caused by environmental factors.
• Other Features: Includes various operational modes and settings to optimize performance.

Specifications

• Detection Range: Adjustable with zoom positions (A, C, E) providing ranges from approximately 2.4m (8ft) up to 9m (30ft).
• Mounting: Ceiling mount installation with a compact design.
• Detection Pattern: Detailed detection zones arranged in a circular pattern with overlapping coverage for high sensitivity.

Detection Patterns and Zoom Settings

The detector features multiple zoom settings that adjust the detection range and pattern density:

• Zoom "A" Position: Shorter detection range (~2.4m to 3.6m).
• Zoom "C" Position: Medium detection range (~3.0m to 4.2m).
• Zoom "E" Position: Maximum detection range (~4.8m to 9m).

The detection zones are highly dense, ensuring reliable motion detection within the specified range.

Installation and Adjustment Procedures

The manual emphasizes proper ceiling mounting and alignment to maximize coverage. The zoom function allows installers to tailor the detection pattern to the room size and layout, reducing false alarms and blind spots.

False Alarm Protection

The device incorporates patented technology to reduce false alarms caused by environmental disturbances such as temperature fluctuations or small animals. This enhances reliability in various installation environments.

Versions and Compatibility

The document references different versions of the SX-360Z detector, indicating compatibility with various security systems and optional settings for customization.

Summary

The OPTEX SX-360Z is a sophisticated PIR detector designed for comprehensive 360° ceiling coverage with adjustable detection ranges and advanced false alarm protection. Its patented multi-focus lens and zoom function provide flexibility and high sensitivity, making it suitable for diverse security applications.
