Noviclay

Product catalog summary

Overview

The document presents the NOVICLAY® copolymer roofing system, a next-generation, high-performance roofing solution designed to replicate the authentic look of natural high-barrel clay tiles. Manufactured by Novik, this system emphasizes innovation, design, performance, and durability through advanced polymer technology.

Product Description and Features

Material Composition: Made from virgin copolymer polymers with specially formulated color pigments, additives, and superior UV inhibitor packages to ensure scratch resistance and maximum color retention.
Durability: Resistant to expansion, retraction, splitting, cracking, and rotting under extreme weather conditions and temperature fluctuations.
Maintenance: Virtually maintenance-free roofing solution.
Weight: Lightweight, eliminating the need for costly additional structural support.
Design: Panels feature an interlocking system with reinforced nail slots and hooks for secure installation. Extra-long Novi-Lock tabs facilitate faster and easier installation.
Structural Stability: A structural system on the back of each panel provides protection and stability, making tiles resistant to foot traffic.
Ventilation: Design allows air circulation underneath the panels.

Dimensions

Panel overall dimensions: 19 1/4” x 15 1/4” x 3” (48.9 cm x 38.7 cm x 7.6 cm)
Exposed surface dimensions: 18 1/2” x 14 1/4” x 3” (47 cm x 36.2 cm x 7.6 cm)
Starter strip dimensions: 11” x 3 3/4” x 9 3/4” (28 cm x 10 cm x 25 cm)

Color Options

Available colors include Red Brick (#184), Field Green (#183), Terracotta (#182), Country Red (#145), Rustic Green (#144), Carbon Gray (#138), Harvest Brown (#142), Terra Brown (#143), and Graphite Black (#152). Actual colors may vary due to printing processes, and Novik reserves the right to modify color offerings.

System Accessories

Starter strips matching panel colors for easy installation.
Ridge vent membering and weather blocks for ventilation.
Hip and ridge shingles designed to be flexible for various roof pitches.
Sealant tape for sealing components.
Membrane underlayment (self-sealing, self-adhesive, self-healing) meeting ASTM D 1970 standard, required for water and ice protection before tile installation.
Snow guards (retention brackets).
J-Channels (high and low).
Optional accessories such as flashing, junctions, caps, and ridge risers are available upon request.

Performance and Testing

The NOVICLAY® roofing system has undergone rigorous testing and certification by independent laboratories, meeting or exceeding industry standards:

Fire Rating: Class C fire resistance with optional Class A rating (tested per UL790 and ASTM E-108).
Hail Impact Resistance: Class 4 impact resistance (tested per UL2218).
Wind Resistance: Surpassed Miami-Dade County requirements for wind speeds over 110 mph (tested per Miami Dade County TAS 100-95).
UV Exposure: Virtually no fading after accelerated UV exposure (tested per ASTM G154).
Penetration Resistance: Passed penetration tests.
Load Capacity: Panels withstand loads up to 200.31 lb (90.86 kg).

Installation Notes and Recommendations

Underlayment protection with an ice and water shield membrane is mandatory across the entire roof surface prior to tile installation.
The starter strip clips on easily to the panels, facilitating quick installation.
Interlocking panel design and reinforced nail slots ensure secure and solid installation.
Ridge and hip shingles are flexible to accommodate various roof pitches.
Ventilation accessories are available to optimize roof airflow.

Important Notices

Novik reserves the right to modify or replace accessories without prior notice.
Actual product colors may differ from printed samples; customers should verify with store samples.
Contact Novik Customer Service for additional accessories and support.
