NIBE™ F2120

Product catalog summary

Overview
The NIBE F2120 series represents a significant advancement in air/water heat pump technology, boasting a Seasonal Coefficient of Performance (SCOP) value exceeding 5.0. This means the pumps can deliver over five times the heat compared to an electric heater using the same energy. The series is designed to operate efficiently even at low ambient temperatures, maintaining a supply temperature of up to 65°C and delivering up to 63°C at temperatures as low as -25°C, all while keeping noise levels minimal.

Specifications
The NIBE F2120 series includes models F2120-8, F2120-12, F2120-16, and F2120-20, each with varying capacities and SCOP values. The heat pumps are equipped with inverter-controlled EVI scroll compressors and use R410A refrigerant. They are designed for easy installation with a self-adjusting control system and do not require electrical system upgrades. The units are compatible with NIBE indoor modules (VVM series) and control modules (SMO series), allowing for flexible system configurations.

Performance and Efficiency
The heat pumps offer a wide range of heating capacities and are capable of providing cooling with flow temperatures down to +7°C. They are rated with an energy efficiency class of A+++ for package labels. The sound power level is kept low, with a nominal level of 53 dB(A) according to EN12102 standards.

Installation and Compatibility
The NIBE F2120 series is designed for compatibility with various indoor modules and control systems, allowing for customized heating and cooling solutions. Up to eight units can be connected to a single NIBE SMO40 control module, providing scalability for larger installations.

Dimensions and Physical Characteristics
The units vary in size and weight, with dimensions ranging from 1070 mm to 1165 mm in height, 1130 mm to 1280 mm in width, and a depth of 610 mm to 612 mm. The weight ranges from 150 kg to 183 kg, depending on the model.

Catalog excerpts

AIR/W ATER HEAT PUMP NIBE™ F2120 A breakthrough in efficiency A breakthrough in efficiency Air/water heat pump with a SCOP value better than 5.0!* Class leading working range Max 65 °C supply temperature and a up to sensational 63 °C at as low as –25 °C ambient Extremely installer-friendly Self-adjusting control system means true plug-and-play installation 3-phase connection for all available sizes No need to upgrade fuses or rebuild electrical system Less noise when it counts Silent fan with intelligent regulator keeps noise down to a minimum – even under full load. • nverter controlled compressor adapts power to meet the current I heat demand. • Provides cooling with flow temperature down to +7 °C. • IBE F2120 is intended to be combined with any of the indoor N modules VVM, or control modules NIBE SMO. NIBE F2120 Our new F2120-series of air/water heat pumps represent a real breakthrough in housewarming with a SCOP-value of more than 5.0. Or in other words; the pumps deliver more than five times as much heat, on an annual basis, as an electric heater using the same energy. And what’s more, they have a class leading working range with a supply temperature of max 65°C and deliver up to an amazing 63°C at ambient temperatures as low as –25°C. All this while keeping noise levels exceptionally low. That’s what we call a real breakthrough in house warming. We are well aware that this sounds a bit too good to be true, so talk to your NIBE dealer for a more in-depth explanation or have a look at www.nibe.eu * A +++ Energy efficiency class package label for NIBE F2120 * NIBE F2120-8, -12 SCOP 4,8. NIBE F2120-16, -20 SCOP 5,1 ** Our F2120-series air/water heat pumps deliver more than five times as much heat, on an annual basis, as an electric he

Open the catalog to page 1

7/35, Heat capacity range –7/45, Heat capacity range 7/35 Heat capacity / COP, EN14511, nominal 7/45 Heat capacity / COP, EN14511, nominal 2/35 Heat capacity / COP, EN14511, nominal Efficiency class 35/55°C product label Efficiency class 35/55°C Package Label Sound power level (LWA), according to EN12102 at 7 / 45, nominal Rated voltage Max operating current, heat pump Enclosure class Inverter controlled EVI scroll compressor CO2-equivalent (hermetically sealed refrigerant circuit) Max system pressure heating medium Heating temp continuous operation Weight (excl. packaging) NIBE F2120 – part...
