MiniLoo

Product catalog summary

Product Overview: The document introduces the 'miniLoo,' a compact and environmentally-friendly toilet designed for small spaces. It features an off-the-floor design for easy cleaning and wheelchair accessibility.

Material and Design: The miniLoo is made from heavy gauge, recycled stainless steel, which helps reduce bacteria build-up. It offers three finish options: satin stainless steel, high-polish mirror, and White Gloss powder coating. The carrier and actuator panel are available in all finishes, and toilet seats are sold separately.

Water Efficiency: The miniLoo uses a dual flush European in-wall tank mechanism, allowing users to choose between a 1.0-gallon flush for liquids and a 1.6-gallon flush for solids, minimizing water consumption.

Specifications: The toilet is compatible with most standard round front toilet seats. It has a wall/floor baseline of 13 3/4” (349 mm) and 14 1/8” (359 mm), with a toilet rim to floor dimension of 15 3/4” (400 mm) for standard and 17” (432 mm) for ADA compliance. The Geberit™ Carrier can be adjusted to accommodate either height.

Manufacturing and Contact Information: The miniLoo is manufactured in the USA. For more information, contact Neo-Metro at their City of Industry, CA location, or visit their website.

Catalog excerpts

standard satin finish > G How would you a product that yo u The attractive min i allows for easy cleafrom heavy gauge, e n minimizing the bacteriaIn addition to the material b anism which minimizes wate r flush for liquids and a 1.6 gallo n Finish choices include satin stainless steel,The carrier and stainless steel actuator panel ar e separately. Manufactured in the USA. >

Open the catalog to page 2

shown in a high polish finishoptional chrome-plated plastic seatoptional white gloss powder coating Stainless SteelDual Flush - Actuator Panel > i Ҕ toilet is perfect for that small space. Its off the floor orientation ning and wheelchair accessibility. The 20 1/4Ҕ miniLoo is manufactured > (514 mm) n vironmentally-friendly recycled stainless steel that can help in build-up in your bathroom. 14 1/8 b ase, the miniLoo utilizes a dual flush European in-wall tank mech- > (359 mm) r consumption by allowing the user to choose between a 1.0 gallon n flush for solids. high-polish mirror and a White...

Open the catalog to page 3

P.O.Box 3527 15125 Proctor Ave.City of Industry Օ CA 91746 USA P [ 800.591.9050 ] P [ 626.855.4854 ] F [ 626.937.4725 ] Օ W [ www.neo-metro.com ] > L1001158printed on10% post-consumerrecycled paper stock size="-1">

Open the catalog to page 4
