V-GROOVE BLADE

Product catalog summary

Overview
The V-Groove routing blade is designed for efficient, on-site routing of Multipanel composites, offering significant time and cost savings by eliminating the need to return materials to a workshop for CNC routing. This tool is 100% portable, allowing staff to fabricate panels directly on-site.

General Safety

Read and retain safety warnings before operating the saw blade.
Incorrect use can lead to serious or fatal injuries.

Machine Safety

Isolate the machine at the power source before inspecting or changing the saw blade.
Follow the machine manufacturer's instructions for installation and use.
Ensure machine guards and safety features are functional and compliant with regulations.
Verify that machine specifications, speed, and cutting direction are appropriate for the saw blade.

Cutting Tool Safety

Exercise caution when unpacking and transporting sharp-edged tools.
Do not use damaged, cracked, or fractured saw blades.
Ensure the saw blade is the correct type for the material being cut.
Installation should be performed by trained and qualified personnel.

Personal Safety

Assess the entire task for personal and others' safety before using the cutting tool.
Use personal safety protection, including respiratory protection if necessary.

Technical Details

Size: 170mm diameter
Skin Thickness: 0.21mm
Tips: Carbide
Angle: 90 degrees
Bore: 16mm or 30mm
Blade Teeth: 18
Speed: 11,000 rpm

The blade is used for straight V-Grooving a range of Multipanel UK products. It is recommended to leave a minimum of 0.30mm Polyethylene to ensure suitable strength and performance. The blade facilitates 900 folding on-site to produce boxes and trays quickly and cost-effectively.

Catalog excerpts

Sign & Display Solutions V-GROOVE BLADE The new V-Groove routing blade is the perfect solution for time saving, on-site routing. Staff can now route and fold a range of Multipanel composites on-site without the need to return the the need to return the material to the workshop for CNC routing. The ability to fabricate panels on site offers significant time and cost savings.

Open the catalog to page 1

V-GROOVE BLADE General Safety - Before operating saw blade you must read and retain safety warnings. - Incorrect use may cause serious or fatal injury Machine Safety - Isolate machine at power source before inspecting or changing saw blade. - Read machine manufacturer’s instructions before installing or using saw blade. - Machine guards and safety features must be functional and according to regulations. - Machine specifications, speed and cutting direction must be correct and fit-for-purpose for saw blade. Cutting Tool Safety - Caution must be used when unpacking and transporting sharp edged...

Open the catalog to page 2
