MITSUBISHI ELECTRIC
Product Range 2008-2009

Product Range 2008-2009

Product catalog summary

Contact Information: Mitsubishi Electric Europe B.V., Air Conditioning Division, Gothaer Str. 8, D-40880 Ratingen, Germany. Phone: +492102-4861892, Fax: +492102-4867910, Email: [email protected]

Overview: This document provides a comprehensive overview of Mitsubishi Electric's air conditioning solutions, including single and multi-split systems, heat pumps, VRF, close control systems, and ventilation systems. The focus is on providing first-class service and innovative, energy-efficient products.

Service and Support: Mitsubishi Electric offers extensive documentation, technical manuals, planning software, training, and on-site technical support to ensure successful cooperation and customer satisfaction.

Product Range: The catalogue includes various systems such as M-Series room air conditioners, Mr. Slim split and multi-split systems, Zubadan heat pump systems, air curtain systems, City Multi VRF systems, and Lossnay ventilation systems.

Technology and Innovation: Mitsubishi Electric emphasizes future-oriented air conditioning technology with sophisticated inverter technology and environment-friendly refrigerant R410A for optimal energy efficiency and climate comfort. The systems offer flexibility with tailored solutions and easy installation options.

Training and Technical Support: Training centers provide practice-oriented training for air conditioning system constructors and planners. Technical consulting services are available through regional offices across Germany.

Product Documentation and Tools: Planning and service manuals, design software like Easy-Klimaplan and Piping-Design-Tool, and a CD Toolbox with catalogues and calculating programs are provided to assist in design and installation.

Environmental Commitment: The catalogue is printed on environmentally-friendly paper, and Mitsubishi Electric is committed to sustainable practices.

Product Features: Key features include remote control, air filters, pre-filled refrigerant, low temperature cooling, automatic restart, energy-saving functions, and modern design. The systems are designed for noiseless operation and top energy efficiency.

Installation and Maintenance: The systems are designed for easy installation and maintenance, with features like Quick Clean Set and Plasma Duo Filter technology for effective air cleaning and odour neutralizing.

Compatibility and Flexibility: The M-Series and Mr. Slim systems offer flexible air conditioning solutions with open combining options and simplified installation and retrofitting capabilities.

Specifications: The document lists multiple models such as MXZ, MUX, MSC, MSZ, and MSH series, detailing their cooling and heating capacities, energy efficiency classes, air volume, noise levels, dimensions, and power supply requirements. It also specifies the maximum number of indoor units that can be connected to each system.

Key Features: The units are equipped with energy-saving technologies like DC-Inverter and use environmentally friendly refrigerant R410A. They offer features such as automatic restart after power loss, infra-red remote control with Fuzzy-Logic-Control, programmable 24-hour timers, and multiple fan levels with swing mode for efficient air distribution.

Installation and Maintenance: The units are designed for easy installation with compact indoor units and pre-filled outdoor units. They include long-lasting, washable filters and optional parts like fine dust filters and anti-allergy enzyme filters. Specific models also offer a winter kit for cooling operations down to -10°C.

Performance and Efficiency: The document highlights the energy efficiency of the units, with most models achieving high energy efficiency classes (A/A) for both cooling and heating. Noise levels are minimized, with some models operating as low as 20 dB(A) in night mode.

Optional Features: Optional features include anti-allergy enzyme filters, Quick Clean Kits, and silver design front panels for deluxe models. The document also mentions the availability of a winter kit for certain models.

Conclusion: The document provides comprehensive information on the technical specifications, features, and installation guidelines for a range of air conditioning units, emphasizing energy efficiency, ease of installation, and user-friendly operation.

1-Way Ceiling Cassettes: These units are designed for multi-split operation, offering low noise levels and adjustable airflow for ceiling heights up to 2.7 meters. They come in three models with varying cooling and heating capacities, all requiring a power supply of 220-240V, 1 phase, 50Hz.

4-Way Ceiling Cassettes: These units are optimized for European ceiling grid dimensions, featuring noise-optimized casing and easy installation. They include a remote control with a timer, long-lasting filters, and a winter kit for cooling operations in low temperatures.

Floor Standing Units: These units provide year-round comfort with silent operation starting at 22 dB(A). They feature a DC-Inverter technology for energy savings and come with a remote control and washable filters. The design allows for flexible positioning and automatic restart after power loss.

Ceiling Concealed Units: Compact in design, these units offer low noise operation and energy savings. They include a self-diagnosis unit for easy service and a high-quality remote control. The units are pre-filled with refrigerant R410A and have adjustable static pressure.

Multi Split Outdoor Units: These units support individual cooling solutions for multiple rooms, with the ability to connect up to four wall-mounted units. They feature energy-saving compressors and automatic restart capabilities. The units are designed for easy expansion and improved energy utilization.

Technical Specifications: Each unit type includes detailed specifications such as cooling and heating capacities, noise levels, dimensions, power supply requirements, and refrigerant details. The document also provides information on optional parts and installation requirements.

Specifications: The document provides detailed specifications for various connection kits and outdoor units used in HVAC systems. It includes information on refrigerant pipe diameters, power supply requirements, maximum power consumption, and current ratings for different models. The refrigerant used is R410A, and the power supply is typically 380-415V, 50Hz, 3-phase.

Connection Kits: Two main connection kits, PAC-AH63-140M-G and PAC-AH125-250M-H, are discussed. These kits cover a cooling capacity range of 5.6 to 28 kW and can be connected to City Multi outdoor units. The kits include a controller box, temperature sensors, and linear expansion valves for connecting external heat exchangers.

Y-Series and R2-Series: The Y-Series offers flexibility and comfort, supporting up to 50 indoor units in a single cooling circuit. It features high energy efficiency with a COP of 4.32 in cooling operation. The R2-Series is designed for energy-saving and environment-friendly applications, allowing simultaneous cooling and heating with energy recovery capabilities.

BC-Controller: The BC-Controller is a key component of the R2-Series, enabling efficient refrigerant distribution and heat recovery. It supports up to 50 indoor units and eliminates the need for a refrigerant distributor, simplifying installation and reducing potential leaks.

Performance and Efficiency: The document highlights the high performance and cost-effectiveness of the systems, with potential energy cost reductions of up to 50% through heat recovery. The systems are designed for optimal energy efficiency, with a system-COP of up to 8 possible in well-designed setups.

Outdoor Units: Various outdoor units are detailed, including their cooling and heating capacities, EER, COP, air volume, noise levels, and dimensions. The units are designed for high efficiency and flexibility, supporting a wide range of indoor unit configurations.

Integrated Software and Security Features: The G(B)-50A-PRO central remote control by Mitsubishi Electric features an integrated, multilingual user interface that is not based on Windows, ensuring no unauthorized external access. It includes safe password levels for protection against unauthorized interference and offers optional remote access via ISDN or LAN, secured by a password.

Remote Access and Notifications: With the optional BTR-232B Router, the air conditioning system can be operated remotely via a local intranet or telephone connection. The system can send automatic notifications via email or SMS in case of errors, requiring the Mitsubishi Electric Router BTR-232B.

PLC-Control and External Applications: The system can integrate with external applications through a Mitsubishi Electric PLC, allowing for access control, intrusion monitoring, and control of illumination and ventilation systems.

Technical Specifications: The G/GB-50A models can control up to 50 indoor units. The G-50A measures 120 x 300 x 79 mm and weighs 1.0 kg, while the GB-50A measures 130 x 250 x 38 mm and weighs 1.1 kg. They require a DC 12V or DC 24V power supply and operate in temperatures from 0° to 40°C with 30-90% relative humidity.

Control and Monitoring Capabilities: The TG-2000 software allows for the control and monitoring of up to 2,000 indoor units, offering features like virtual remote control, energy-saving functions, and BACnet connection. It integrates with PLC controls for additional functionalities.

Accessories and Modules: The system supports various inlet and outlet modules for recording energy consumption, controlling external units, and monitoring environmental conditions. These modules require a 24V DC power supply and are designed for dry indoor installations.

Design and Maintenance Tools: Mitsubishi Electric provides software tools for pipeline dimensioning and electric diagram development, facilitating safe planning and installation. The Maintenance Tool offers cost-effective monitoring and operation of City Multi units.

Ventilation Systems: The Lossnay ventilation systems offer high-performance heat recovery, reducing installation costs and energy consumption by up to 70%. They are suitable for modern buildings, providing a healthy environment with air volume flows ranging from 150 to 2,000 m³/h.
