This 2010 product catalog from Milan Iluminación, based in Barcelona, Spain, presents a comprehensive range of lighting fixtures including wall lights, ceiling lights, table lamps, floor lamps, hanging lights, and outdoor lighting solutions.

Product Categories and Sections

Wall Lights (Apliques): LED, fluorescent, and halogen models with detailed product lines such as MLN Dau LED, MLN T-Led, MLN Mini Signal LED, and others, including technical specs.
Ceiling Lights (Plafones): LED, fluorescent, and halogen ceiling fixtures like MLN Inoxx, MLN Polifemo LED, MLN Rimbo, with wattage, light source types, and dimensions.
Table Lamps (Sobremesa): Fluorescent table lamps including MLN Rimbo and MLN Kupp, specifying power and light temperature.
Floor Lamps (Pies Salón): Fluorescent and other floor lamps such as MLN Tod and MLN Rimbo, with power ratings and IP protection levels.
Hanging Lights (Colgantes): Models like MLN Rimbo and MLN Kupp, detailing maximum wattage and color temperature.
Outdoor Lighting (Luminarias de Exterior): IP65 rated products designed for exterior use, including MLN Rimbo and MLN Tod, with wattage and light temperature specifications.

Technical Specifications and Features

Light Sources: Variety includes LED modules (1 to 5 LEDs), fluorescent tubes (G5, 2G10), halogen bulbs (G9, E14, E27), and dichroic lamps (GZ10).
Power Ratings: LEDs typically consume 4 W per LED; halogen and fluorescent lamps range from 9 W to 80 W depending on model.
Color Temperature & Rendering: Standard warm white (3000K) with CRI (Ra) of 80 for quality light output.
Dimensions: Precise measurements (height, width, depth) provided in millimeters for each product.
IP Ratings: IP44 and IP65 ratings for dust and water protection, especially for outdoor and floor lamps.
Materials & Finishes: Use of PMMA diffusers, chrome, black, aluminum, painted black finishes, and various glass types.
Photometric Data: Angular light distribution and luminous intensity curves included to illustrate light dispersion and intensity.

Designers and Product Lines

Collaboration with designers such as Flemming Bjorn, Stefan Kährs, Jordi Jané, and R.& S. Corneliessen is highlighted, with multiple product series identified by codes for easy reference.

Recommendations and Usage Guidelines

Warm white light (3000K) is recommended for indoor residential and commercial environments.
IP44 and IP65 rated products are suitable for outdoor or damp locations.
LED options provide energy efficiency, long lifespan, and consistent color rendering.
Halogen and fluorescent lamps offer traditional lighting alternatives with varied power and light quality.

Finishes and Materials

Chrome plating, brushed nickel, polished silver, stainless steel, white and black lacquering.
Glass types include white opal, satin, optical flat sanded, transparent polycarbonate.
Polyethylene shades produced by roto-molding and polymethyl-methacrylate shades.

Light Sources Detailed

G9 Bi-pin halogen 230 V
GZ10 Dichroic halogen 230 V
G5 Fluorescent tubes
LED modules: 4 W, 230 V, 3000 K, CRI 80
CFL types: E27 30 W (3000 K), E14 9 W (2700 K), G9 11 W (3000 K)

Technical Specifications and Symbols

Glass manufacturing methods: hand-blown, hand-stamped, heat-curved optical glass, flat optical and opal glass.
Dimensions: diameter, height, projection in millimeters.
Electrical protection classes I, II, III for shock protection.
Mounting suitability on flammable and non-flammable surfaces.
IP protection ratings for dust and water resistance.
Electronic components: electronic ballast, transformer, and equipment.
Control options: touch dimmer, cord switch, integrated switch.
Installation requirements: minimum recess depths for round and rectangular openings.
Product identification: model labels on packaging and technical plates on products.
Assembly and maintenance instructions included.

Multilingual Presentation

All technical data, finishes, light sources, and symbols are presented in Spanish, English, French, German, Italian, and Dutch to support international users.

Manufacturer Information

Company: MILAN ILUMINACIÓN, S.A.
Address: Arquimedes, 24, 08907 L’Hospitalet de Llobregat, Barcelona, Spain
Contact: +34 93 336 99 66, Fax +34 93 336 99 60
Email: [email protected]
Website: www.milan-iluminacion.com

Summary of Critical Information

Multiple finish options enable aesthetic and functional customization.
Wide compatibility with halogen, fluorescent, LED, and CFL light sources with specified wattages and color temperatures.
Clear technical guidelines ensure safe installation, electrical protection, and maintenance compliance.
Comprehensive symbology and labeling facilitate correct product identification and usage.
Multilingual documentation enhances accessibility for international markets.

Conclusion

This catalog serves as a detailed technical and design reference for architects, designers, and lighting professionals seeking diverse, high-quality lighting solutions with clear specifications, photometric data, and installation guidance.
