Product Overview

The document details the specifications and variants of the Perceval LED lighting series by Milan Iluminación, featuring designs by Flemming Bjorn and Jordi Jané. The products are LED-based luminaires with consistent technical parameters across models.

Technical Specifications

• LED Configuration: Models include 3 or 6 LEDs, each rated at 4 W power consumption.
• Color Temperature: Fixed at 3,000 K, providing warm white light.
• Color Rendering Index (Ra): 80, ensuring good color fidelity.
• Voltage: 230 V operation.
• Light Distribution: Gamma angle options of 180° and 120° are specified, indicating beam spread.
• Photometric Data: Various luminous intensity values are provided per model, with maximum intensities ranging from approximately 503 to 1,734 cd depending on the variant.

Model Variants and Designers

Models are identified by codes such as MLN Perceval Led / 6337, 6338, 6340, etc., with two main designers:

• Flemming Bjorn: Associated with models like 6337, 6338, 6139, 6140, 6141.
• Jordi Jané: Associated with models such as 6336, 6339, 6340, 6341, 6342, 6343, 6344, 6345, 6346, 6347, 6348, 6349, 6350, 6359, 6360.

Physical Dimensions and Finishes

• Dimensions are given in millimeters, including diameter, height, and projection.
• Finishes include White Lacquering (BL) and Chrome Plating (CR).

Electrical and Safety Features

• Protection classes I and II against electric shock are indicated.
• Mounting is suitable for normally inflammable surfaces.
• Switch options include cord switches and integrated switches.

Photometric and Angular Data

The document includes angular intensity distributions at various angles (30°, 45°, 60°, 75°, 90°, 105°, 150°, 300°, 450°, 600°) and luminous intensity values for different models, indicating detailed light distribution characteristics.

Additional Information

• Each product includes a model ID label on packaging and a technical specification sticker.
• Assembly and maintenance instructions are provided with all products.
• Contact details for Milan Iluminación are provided for support and inquiries.

Summary of Critical Parameters

This structured summary captures the essential technical and design features of the Perceval LED lighting series, facilitating product selection, installation, and maintenance.
