BRIDGE

Product catalog summary

Overview: This document provides technical specifications for the MLN Bridge lighting series designed by Jordi Jané, produced by Milan Iluminación, based in Barcelona. The document includes details on various models, their specifications, and installation instructions.

Specifications:

All models use LED light sources with a power of 10 W, producing 820 lumens at 700 mA.
The color temperature is 3,000K with a color rendering index (Ra) of 82.
Beam angle is consistently 50º across models.
Models vary in dimensions and configurations, with some using 1 LED and others using 2 LEDs.

Models:

MLN Bridge / 6353: Dimensions 280 x 26 x 156 mm, 2 LEDs.
MLN Bridge / 6351: Dimensions 100 x 26 x 156 mm, 1 LED.
MLN Bridge / 6358: Dimensions 120 x 3 mm, 1 LED.
MLN Bridge / 6357: Dimensions 120 x Max. 60 mm, 1 LED.
MLN Bridge / 6352: Dimensions 100 x 142 mm, 1 LED.
MLN Bridge / 6354: Dimensions 205 x 310 mm, 2 LEDs.
MLN Bridge / 6356: Dimensions 120 x 275 mm, 2 LEDs.
MLN Bridge / 6355: Dimensions 100 x 146 mm, 1 LED with 14 W and 930 lumens at 900 mA.
MLN Bridge / 6363: Dimensions 130 x Max. 127 mm, 1 LED.
MLN Bridge / 6364: Dimensions 300 x 160 x Max. 129 mm, 2 LEDs.
MLN Bridge / 6362: Dimensions 100 x 1,750 mm, 2 LEDs.

Installation and Maintenance:

Products are designed for mounting on normally inflammable surfaces.
Each product includes assembly and maintenance instructions.
Drivers are either incorporated or external, depending on the model.

Additional Information:

All products are finished with white lacquering.
Protection class III against electric shock is provided.
Technical specifications are labeled on each product and packaging.

Contact Information: Milan Iluminación, Arquimedes, 24, 08907 L’Hospitalet de Llobregat, Barcelona, Spain. Tel: +34 93 336 99 66, Fax: 93 336 99 60, Email: [email protected], Website: www.milan-iluminacion.com
