OK 4940 PAR90
OK 4940 PAR90
Product Specifications
This document details technical specifications for a lighting product line, including electrical, photometric, mechanical, and normative data.
Electrical and Photometric Data
- Power supply: 220-240V AC, 50-60 Hz
- Light source characteristics: Color Rendering Index (CRI) > 90, color tolerance within 3 Step MacAdam ellipse
- Lifetime: 80,000 hours (L80B20 standard)
- Protection rating: IP20
- Unified Glare Rating (UGR) < 19 compliant with EN 12464-1
- Photobiological safety: Exempt risk (Group 0) according to EN 62471 and IEC/TR 62778
Mechanical and Optical Features
- Mounting options: Ceiling or suspended installation using accessories 4417SP1 + 4406
- Body: Iron sheet construction with solvent-free epoxy polyester powder coating, thermoset at 180°C after phosphate treatment
- Light emission: Direct and symmetric
- Optical device: Louver Darklight with double parabolic blades, satin anodized aluminum, top-closed blades for glare limitation and anti-iridescence
Performance Data and Variants
| Line | Current (mA) | Luminous Flux IN (lm) | Luminous Flux OUT (lm) | Power (W) | Dimensions (D x L, mm) | Weight (Kg) | Volume (m³) | Code |
|---|---|---|---|---|---|---|---|---|
| 3000 | 1 350 | 2568 | 1812 | 16.4 | 170 x 1245 | 6.5 | 0.020 | 49403WW1245E0B |
| 4000 | 1 350 | 2708 | 1911 | 49403NW1245E0B | ||||
| 3000 | 2 350 | 5136 | 3625 | 32.8 | 250 x 1230 | 6.0 | 0.029 | 49403WW1230E0B |
| 4000 | 2 350 | 5416 | 3822 | 49403NW1230E0B | ||||
| 3000 | 2 350 | 6420 | 4531 | 41.0 | 250 x 1530 | 8.0 | 0.036 | 49403WW1530E0B |
| 4000 | 2 350 | 6770 | 4778 | 49403NW1530E0B | ||||
| 3000 | 4 350 | 5136 | 3625 | 32.8 | 530 x 615 | 6.0 | 0.030 | 49403WW0615E0B |
| 4000 | 4 350 | 5416 | 3822 | 49403NW0615E0B |
Normative Compliance
- EN 60598-1 (General requirements for luminaires)
- EN 60598-2-1 (Particular requirements for fixed general-purpose luminaires)
- Photobiological safety standards EN 62471 and IEC/TR 62778
- European Directives: 2014/35/EU (Low Voltage Directive), 2014/30/EU (EMC Directive)
Additional Features and Options
- Available on request: DALI dimmable electronic ballast
- Emergency unit option: 1-hour duration
Important Notes
All technical specifications and data are subject to change without prior notice.
Manufacturer contact: METALMEK ILLUMINAZIONE S.r.l., Via Ramazzotti 10, 20020 Lainate (MI), Italy. Tel: +39 029373157, Fax: +39 02 93710176, Email: [email protected], Website: www.metalmek.it
Catalog excerpts
Body in iron’s sheet, painted with SOLVENT FREE, epoxy polyester powders, thermosetting at 180°C, after phosphate treatment. Light emission Direct Symmetric Optical device Louver Darklight, double pararabolic, with top-closed parabolic blades in satin, anodized, antiglare and anti-iridescent aluminium. Glare limitation. Light source Color tollerance: 3 Step MacAdam Perfomance data Protection rate: IP20 UGR < 19 (EN 12464-1) Normatives EN 60598-1 EN 60598-2-1 Photobiological safety EN 62471 IEC/TR 62778 Exempt risk – GR 0 Directives 2014/35/UE 2014/30/UE UPON REQUEST VERSION DALI dimmable electronic ballast Emergency unit: 1h Tutte le specifiche tecniche e i dati sono soggetti a modifica in qualsiasi momento e senza preavviso. All technical specifications and datas are subject to modification at any time and without notice. METALMEK ILLUMINAZIONE S.r.l. Via Ramazzotti, 10 - 20020 Lainate (MI) Italy tel. +39 029373157 - fax +39 02 93710176 - [email protected] - www.metalmek.
