SN0128CS
1 / 1Pages

Catalog excerpts

STAINLESS STEEL SANITARY WARE TOILETS SN0128CS Satin finish General description  Wall-mounted toilet made of bacteriostatic AISI 304 stainless steel, 1.5 mm thick, satin finish. Compatible with all standard frame systems available on the market. Elegant and simple design. One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene. WC bowl surface is polished with rounded edges for easy cleaning. Concealed perimetral flushing rim. Horizontal water inlet: Ø 55mm. Horizontal waste outlet: Ø 100mm. Water saving: works with 4L or more of water. Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid. Quick and easy to install from the front thanks to a stainless steel mounting frame. Supplied with fixing plate and 6 theft prevention TORX security screws. CE marked. Complies with European standard EN 997 for 4L flush. Technical specifications Max. dimensions Thickness Outlet Inlet Net weight Components and materials  BOWL: made of AISI 304 stainless steel, 1.5 mm thick, polished and designed with rounded edges to facilitate waste removal and cleaning.  BODY: made of AISI 304 stainless steel, 1.5 mm thick and anti-vandalism finishes. No sharp edges, corners, or surface welds that prevent accidental user injury.  WATER OUTLET: horizontal Ø100 mm.  WATER INLET: Ø55 mm. Mediclinics, S.A., reserves the right to make changes and/or modifications to the products and their specifications without prior notice. R

Open the catalog to page 1
