Arco Miniwitra Ceiling fixture

Product catalog summary

Overview: The document appears to be a technical specification sheet for architectural lighting fixtures, detailing various models, their features, and specifications.

Specifications: The fixtures are primarily ceiling or wall-mounted, with a glazed grey body and die-cast aluminium brackets. They are designed to accommodate different types of lamps, such as AR111 and PAR30 MH, with varying wattages and voltage requirements. The fixtures feature electronic transformers or electromagnetic control gear, depending on the model.

Models and Capacities: Several models are listed, including 22380, 22382, 22383, 22379, 22381, 22384, 22386, 22370, 22372, 22373, 22374, and 22376. Each model supports a specific number of lamps and wattage, ranging from 1x35W to 6x100W.

Materials and Finishes: The fixtures are adjustable in glass with options for acid-treated finishes in colors such as white, crystal, opal blue, aquamarine, and green. The document provides a color code for glass rings.

Accessories: A kit with safety glass for AR111 lamps is available, with specific order codes provided. Additional accessories include electronic transformers and electromagnetic control gear with detailed codes for ordering.

Additional Information: The document references photometric data available on another page, indicating detailed light distribution characteristics for the lamps.

Catalog excerpts

250 AR111, max 1x100W 230/12v featuring an electronic transformer > 46 120 Kg. 1.0 46 fixtureglazed grey bodyceiling or wall fixturedie-cast aluminium bracket > 214 325 AR111, max 2x100W 230/12v featuring an electronic transformer > 46 120 Kg. 1.8 46 fixtureglazed grey bodyceiling or wall fixturedie-cast aluminium bracket > 214 490 AR111, max 3x100W 230/12v featuring an electronic transformer > 46 120 Kg. 2.7 46 fixtureglazed grey bodyceiling or wall fixturedie-cast aluminium bracket > 214 500 PAR30 MH, 1x35W E27 230v electromagnetic control gear > 46 120 Kg. 1.4 46 fixtureglazed grey bodyceiling...

Open the catalog to page 2

AR111, max 4x100W 230/12v featuring an electronic transformer > Kg. 3.6 fixtureglazed grey bodyceiling or wall fixturedie-cast aluminium bracket > AR111, max 6x100W 230/12v featuring an electronic transformer > Kg. 5.4 fixtureglazed grey bodyceiling or wall fixturedie-cast aluminium bracket > glass rings colour code acid-treated white aquamarine green crystalopalblue >

Open the catalog to page 3

160 AR70 max 1x50W 230/12v featuring an electronic transformer > 46 80 Kg. 0.5 46 153 fixtureglazed grey bodyceiling or wall fixturedie-cast aluminium bracket > 240 AR70 max 2x50W 230/12v featuring an electronic transformer > 46 80 Kg. 0.8 46 153 fixtureglazed grey bodyceiling or wall fixturedie-cast aluminium bracket > 360 AR70 max 3x50W 230/12v featuring an electronic transformer > 46 80 Kg. 1.5 46 153 fixtureglazed grey bodyceiling or wall fixturedie-cast aluminium bracket > 480 AR70 max 4x50W 230/12v featuring an electronic transformer > 46 80 Kg. 2.0 46 153 fixtureglazed grey bodyceiling...

Open the catalog to page 5

AR70 max 6x50W 230/12v featuring an electronic transformer > Kg. 3.0 fixtureglazed grey bodyceiling or wall fixturedie-cast aluminium bracket > 720 80 46 46 153 glass rings colour code acid-treated white aquamarine green crystalopalblue > Kit with safety glass forAR111 lampsnot at lowpressure. >

Open the catalog to page 6

Arco Miniwitra Ceiling fixture

Arco Miniwitra Ceiling fixture
