Product Overview

The document details the specifications for the 360º series of architectural panels by Marcal© (2011). These panels come in various sizes and finishes, designed for versatile applications.

Dimensions and Models

The 360º panels are available in multiple width (w), height (h), and depth (d) configurations, with measurements provided in both millimeters and inches for international reference.

• Widths range from 400 mm (15.74") to 3000 mm (118.11").
• Heights vary between 400 mm (15.75") and 2500 mm (98.43"), with some models extending up to 2000 mm (78.74") and 2500 mm (98.43").
• Depths are consistently 110 mm (4.33") for larger panels and 84 mm (3.30") for smaller panels.

Specific model examples include:

• 360° 643: 3000 x 600 x 110 mm
• 360° 613: 1500 x 600 x 110 mm
• 360° 443: 3000 x 400 x 84 mm
• 360° 415: 400 x 1000 x 84 mm

Material and Finishes

The panels are manufactured from raw aluminum (aluminium brut) and are available with epoxy powder coating according to the RAL color chart. This coating provides durability and aesthetic customization options. The finish is described in multiple languages, emphasizing the availability of epoxy paint in various RAL shades.

Key Specifications

• Material: Raw aluminum
• Finish: Epoxy powder coating (RAL chart customizable)
• Depth options: 110 mm or 84 mm depending on panel size
• Dimensions: Multiple width and height options to suit different architectural needs

Summary

The 360º series offers a comprehensive range of aluminum panels with customizable sizes and finishes, suitable for architectural applications requiring durable and visually adaptable materials. The detailed dimensional data and finish options facilitate precise selection for design and installation purposes.
