Opening doors to the future
15Pages

Opening doors to the future

Quality, service & experience Created in 1966, Manusa is a leading company in the market of automatic doors thanks to the development of its own technology and a professional team that works to achieve full customer satisfaction. More than 50 years of experience We leave nothing to chance Exclusive solutions for every customer International presence Introduction

Doors / Entrances Our experience of more than 50 years means we can offer a wide range of access solutions adapted to specific needs. Not only do we offer the most suitable features for every architectonic project, but we are also capable of customising the finish and colours to integrate our automatic doors in the environment in which they are located. Bi-parting and single sliding doors Telescopic sliding doors Curved and semicircular sliding doors Panic break-out sliding doors Fire-resistant sliding doors Hermetic doors

– Possibility of assembly with or without fixed leaves. – Full customisation in measurements, finish options and colours. – Wide range of accessories. – Compatible leaves: transparent / full framed Sliding doors The bi-parting and single sliding doors are the most popular and functional automatic doors, as well as to achieve a touch of distinction and elegance in any environment in a friendly way. Single sliding door. Museum sector. In a bi-parting sliding door, two sliding leaves move in opposite directions leaving a wide clear opening. For its part, the sliding leaf of a single sliding...

– Possibility of assembly with or without fixed leaves. – Full customisation in measurements, finish options and colours. – Wide range of accessories. Sliding doors – Compatible leaves: transparent / full framed Telescopic sliding door. Hotel sector. They offer the widest opening: up to 2/3 of the space occupied by the door. It achieves the maximum opening in the minimum space. Bi-part telescopic doors: Sliding door with 4 sliding leaves that move in pairs in opposite directions.The sliding leaves retract one behind the other to leave the maximum possible opening at the centre of the door....

– Full customisation in finish options. – Wide range of accessories. – Comptible leaves: transparent / full framed Sliding doors Manusa curved and semicircular doors create exceptional and elegant entrances without renouncing the features of a sliding door. Circular automatic door. Library. A curved door consists of a single slide or bi-part automatic door with one or two sliding leaves that move radially. The door may be concave or convex and with different radius and degrees of curvature. The combination of two curved doors creates circular doors, ideal for entrances that are both...

Panic break-out system – Full customisation in measurements, finish options and colours. – Wide range of accessories. Sliding doors with Panic break-out door without vertical stiles. Shopping centre. The door functions in normal mode (sliding and automatic). In an emergency, the leaves can be pushed outwards by hand, and automatically retract to the sides to create a large opening for evacuation. A panic break-out door is recommended for public buildings such as airports, stations or large shopping centres or in installations where a larger access opening than normal may sometimes be...

Fire-resistant Sliding doors Fire-resistant door separating kitchen and restaurant. Hotel sector. Combining the functionality and aesthetics of an automatic door with the properties of integrity and insulation. Manusa’s fire-resistant door consists of a bi-parting or single sliding automatic door with fireresistant properties. – Available with classification: E30, EI30, EI60 – Specific fire-resistant leaves. Tempered glass with intumescent gel. Can be customised with a wide range of accessories. Recommended for delimiting sectors with greater fire risk and avoiding fires spreading outside...

Clear View glass hermetic doors. Hospital ICU room. The whole door assembly is designed to guarantee hygiene: recessed vision panel, door handle, easy cleaning materials. Hermetic swing or sliding doors: equipped to hermetically seal the opening. Clear View glass hermetic doors: allow observation rooms to be insulated without losing visibility from inside. For moments in which a certain degree of privacy is required, there is the option of self-dimming glass or glass equipped with integrated Venetian blind. Lead lined doors: for radiology rooms, with option of a lead lined vision panel, to...

Leaves, accessories & motorizations Manusa automatic doors can be adapted to all needs. It is not only possible to choose the most suitable door for each case, but also to combine a wide range of leaves covering all needs. In addition, we offer customised finish options in a wide variety of colours for all the leaves and accessories with specific purposes to give our automatic doors the maximum performance. Transparent leaves Framed leaves

Transparent Leaves Leaves with a unique aluminium rail at the top of the glass Option of bottom rail High level of transparency without renouncing to security. The leaf is made of glass with two aluminium rails, one at the top and one at the bottom, leaving the sides without vertical stiles. The leaf is transparent, with a unique aluminium rail fixed at the top of the glass, with the rest of the perimeter left bare (without a frame). This type of leaf offers the most transparency possible, and total transparency is even possible with the Manusa Visio Hidden Rail / Full Glass operator....

Framed Leaves Full framed leaves Leaves with reinforced full frame The whole perimeter of the glass is framed in 20 mm extruded aluminium. The whole perimeter of the glass is framed in 45 mm wide extruded aluminium profiles through rubber gasket, thus achieving extraordinary robustness for the door assembly. Recommended for high traffic entrances, as they offer a high level of resistance as the glass is fully framed and protected by the aluminium profiles. They have an interlocking profile for better thermal and acoustic insulation from the exterior. Option of double-glazing or...
