We shape the air Neither hot nor cold Zoning System

System Zoning System is the solution to the discomfort problems posed by ducted air-conditioning systems with a single centralised thermostat. Conventional systems do not provide true comfort, for the ideal temperature of each room is independent of the others and depends on their geographical orientation (whether or not the sun enters the room), the use to which it is put and, of course, the extent to which it is occupied.

Zoning System allows the temperature to be controlled independently in the various rooms within a house, commercial premises or office.

Heat? Zoning System includes a digital thermostat for each zone, connected via radio to an electronic control panel that controls the heating/air-conditioning system. The control centre opens or closes the motor-driven dampers in each zone, thereby maintaining the desired comfort temperature.

Personal comfort, saving, amortisation, ecology, freedom high reliability, adaptability, originality and design.

comfort, energy amortisation, of location, adaptability, design. Personal comfort Satisfies the comfort levels of the various occupants of the premises. Energy saving The use of a thermostat in each zone prevents wastage in unoccupied zones. Amortisation The energy saving achieved means that the Zoning System equipment will pay for itself within an average of two years. Ecology Rational use of energy Freedom of location As they are radio-operated, the thermostats can be placed wherever wished and relocated without difficulty by users themselves. High reliability The radio-operated...

Satisfaction, ease of installation, simplification, optimum diffusion, differentiating factor. Satisfaction For professionals and clients alike, who will be delighted with the product. Ease of installation As no wiring is needed, no additional building work is required, thus reducing installation time. Simplification Zoning System gets around the typical installation problems of conventional equipment (cold spots and hot spots, heating/cooling of unoccupied areas. Optimum diffusion MADEL diffusion elements offer greater aerodynamic performance that has been duly proven and documented by...

How the Zoning System works: temperature control by zones.

ZonE 3 23 ºC ZonE 2 24 ºC ZonE 4 OFF ZonE 1 22 ºC The system’s thermostats control the temperature in each zone and transmit the information by radio to the control centre. That centre then adjusts the motorised zone dampers and the air conditioning equipment. Air conditioner start-up from any zone Whenever a temperature-demand signal is received from any zone, the system opens the relevant damper. If that damper is the only one that is open, the system starts up the air conditioning equipment via the connection linking the Zoning System’s control centre and the air conditioner. Temperature...

Zoning System enables the temperature in various different zones in a particular building to be controlled. This is ideal in office buildings for selecting the desired temperature in the various offices and departments. And in the home the temperature of the various rooms can be adjusted to suit the tastes of the people in them, and the air conditioning in unoccupied zones turned off. The same goes for restaurants, shops and so on. This Zoning System offers various designs to suit all needs. Which system you choose depends on factors like the type of air conditioning to be controlled, the...

SI ZONE VALVES SR KRCPLUS HEATER OUTDOOR UNIT INDOOR UNIT ZONE 1 ZONE 2 BY-PASS DAMPER · · · · · · · KRC PLUS A modular zoning kit designed for independent temperature control in direct-expansion ducted air conditioning systems and, optionally, for controlling a single-zone or multi-zone heating system that uses radiators or under-floor heating. /MH/: Expansion module (optional) for controlling radiator or under-floor heating in 2 to 8 zones. /MC/: Expansion module (optional) with the MODBUS protocol for intelligent-building applications. Control over up to 16 separate air conditioning...

ON/OFF KSP Simplified zoning kit designed for independent temperature control in electronic direct-expansion ducted air conditioning equipment. Control over up to 6 independent zones Air conditioning ON/OFF control. The air conditioner’s original controller is to be retained. Summer/winter changeover in the conditioner’s controller and in the master thermostat. Radio-controlled digital thermostats with timing in 30 minute intervals. Coded radio-controlled transmission system (over 3000 combinations). Control board (receiver) Power supply 230 VAC ± 10%, 50/60 Hz Consumption: 4 VA 1...

NTC · · · · Without controlling the air conditioner Automatic summer/winter changeover Affordable Easy to install Sub-zone control KSP-SUB Sub-zone kit designed for independent temperature control in ducted air conditioning equipment, with which it acts only in certain zones of the installation, leaving others free. Particularly suitable for medium- and large-scale installations for avoiding occasional excessive heating or cooling in certain zones (meeting rooms, offices, etc.). Control over up to 6 independent zones. The system is independent of the air-conditioning equipment. Automatic...

FAN-COIL FAN-COIL 4 4 CHILLER KFC Zoning kit designed for independent temperature control in ducted fan-coil systems. The KFC equipment can be used in individual and multiple installations. Control over up to 6 independent zones. Control over fan speed to suit the number of zones in operation (optional). Control over back-up electric batteries. Sensor for detecting operating mode (winter/summer). KSS Zoning system designed to work with ducted electronic direct expansion units. Individualised temperature control over up to 4 zones with a single interior unit. Control over up to 4 independent...

Bisgràfic 12/08 MADEL Air Technical Diffusion P.O. Box nº 5 - E - 08540 Centelles (Barcelona) Tel. (34) 93 889 80 91 - Fax (34) 93 889 82 19 info@madel.com - www.madel.com MADEL has since 1965 been a company specialising in the air circulation of heating/air conditioning and ventilation systems. Constant investment in research and development has led MADEL products to achieve distinction as a provider of innovative solutions. Zoning is a trademark of Madel Air Technical Diffusion
