LA CREU NEWS ADVANCE 2010

LA CREU NEWS ADVANCE 2010

Product catalog summary

Company and Contact Information

LEDS-C4, S.A., headquartered in Torà (Lleida), Spain, specializes in lighting products with a global presence. The company provides dedicated regional contacts for Europe, France-Portugal, Asia-Pacific-Africa, USA-Canada-Ireland, Latin America, and Middle East, including telephone, fax, and email details to facilitate communication and support.

Product Range and Categories

The catalog features a diverse range of lighting fixtures including Pendants, Ceiling Fixtures, Wall Fixtures, Floor Lamps, and Table Lamps. Product lines include models such as Trama, Soft, Conic, Austin, Nock, Zam, Audrey, Estudio, Georgia, Alsacia, Virginia, and Kitchen, among others, catering to various design and functional needs.

Technical Specifications and Features

Light Sources: Products utilize various lamp holders including E-27, G9, GU-10, and E-14, with maximum wattages ranging from 15W to 100W. Some models incorporate LED technology, for example, 1 LED x 3W CREE 3000K.
Energy Efficiency: Many fixtures are marked as ENERGY SAVING, indicating compatibility with energy-efficient bulbs to reduce power consumption.
Materials: Components include acrylic diffusers, aluminum, cotton, silicone, opal glass, transparent glass, steel, and plasticized cotton, ensuring a variety of finishes and durability.
Dimensions: Sizes vary widely, with diameters from 80 mm up to 505 mm and heights reaching 1600 mm depending on the model.
Finish Codes: Products are identified by finish codes (e.g., 05 for Black, 14 for White, 21 for Chrome, Z6 for Rusty Brown, N3 for Grey Texture) to specify surface treatments and colors for ordering.

Ordering Instructions

Orders must include the model reference number followed by two digits for the finish code and two digits for supplementary codes. This structured coding ensures accurate identification of product variants and finishes.

Safety and Compliance

All products comply with European CE safety and electromagnetic compatibility standards.
Electrical safety classifications include Class I and Class II, indicating suitability for installation on normally inflammable surfaces or otherwise.
Certain products are resistant to incandescent wire at 850ºC, enhancing fire safety.
Catalog symbols indicate installation suitability and safety class for user guidance.

Maintenance and Usage Recommendations

Use bulbs that do not exceed the recommended maximum wattage to maintain safety and prolong product life.
Clean lamps only with a dry cloth; avoid metal polishes or abrasive cleaners that could damage finishes.
Product descriptions and dimensions are indicative and may be updated without prior notice for technical or design improvements.

Additional Notes

The catalog is multilingual, offering product descriptions and instructions in Spanish, English, French, German, Italian, and Portuguese to serve diverse international markets. Finishes and technical specifications primarily target the European market and may vary elsewhere.

Copyright and Reproduction Restrictions

All rights are reserved by the publisher and copyright owners. No part of the catalog may be reproduced or transmitted in any form, paper or electronic, without prior written permission. This restriction is stated in multiple languages to ensure compliance.

Cleaning Instructions

For maintenance, only a dry cloth should be used to clean products to preserve finish durability.

Document Identification and Updates

The document is identified by code "L-1299-2009" and references "NEWS ADVANCE 2010," suggesting a product update or newsletter related to the year 2010.

Catalog excerpts

LA CREU NEWS AVANCE 2010 NEWS ADVANCE 2010

Open the catalog to page 1

2 La Creu News 10 ST ® ENERGY SAVING Negro Black Noir Schwartz Nero Preto 05 Trama Blanco White Blanc Weiß Bianco Branco 14 RF 850ºc 2 4 25-4343-05-05 25-4343-14-14 1 x PL Elec. E-27 Max.23W 1 x E-27 Max. 100W Recommended Globe 20W 05-4343-05-05 05-4343-14-14 2 x PL Elec. E-27 Max.16W 2 x E-27 Max. 60W Ø 365 Ø 315 285 1600 190 mm 161 mm ACR DIF

Open the catalog to page 3

4 La Creu News 10 RF 850ºc 2 00-4343-05-05 00-4343-14-14 1 x PL Elec. E-27 Max.23W 1 x E-27 Max. 100W Recommended Globe 20W Trama Ø 365 H max. 1500

Open the catalog to page 5

212 220 285 Ø 500 6 La Creu News 10 6 2 05-4339-21-05 1 x PL Elec. E-27 Max.21W 00-4339-21-05 3 x PL Elec. E-27 Max.21W Recommended 16W ® ENERGY SAVING Negro Black Noir Schwartz Nero Preto 05 Cromo Chrome Chrome Chrom Cromo Cromo 21 Virginia ST COT ACR DIF H max. 900 H min. 670

Open the catalog to page 7

100 215 8 10-4337-N3-N3 1 x G9 Max.40W Estudio ® RF 850ºc ENERGY SAVING Gris textura Grey texture Gris à effet de texture Grau rauh-matt Grigio Cinzento textura N3 ST 400

Open the catalog to page 8

8 La Creu News 10 ® ENERGY SAVING Georgia 4 2 05-4340-21-20 2 x PL Elec. E-27 Max.23W 00-4340-21-20 3 x PL Elec. E-27 Max.23W Pantalla beige incluida Beige fabric shade included Âbat-jour beige compris Beige stoffschirm inklusiv Schermo beige compresa Âbat-jour bege inclusa 20 Cromo Chrome Chrome Chrom Cromo Cromo 21 ST PLA COT ACR DIF 290 H max. 850 H min. 640 248 Ø 505 125

Open the catalog to page 9

Ø 450 Ø 300 Ø 180 10 La Creu News 10 ® ENERGY SAVING Alsacia Pantalla beige incluida Beige fabric shade included Âbat-jour beige compris Beige stoffschirm inklusiv Schermo beige compresa Âbat-jour bege inclusa 20 Marrón óxido Rusty brown Marrón rouillé Braunrost Marrone ossido Marrom óxido Z6 2 2 10-4341-Z6-20 1 x PL Elec. E-27 Max.23W 1 x E-27 Max. 100W Recommended Globe 20W 00-4341-Z6-20 3 x PL Elec. E-27 Max.23W 3 x E-27 Max. 60W ST COT H max. 830 440 H min. 570

Open the catalog to page 11

600 12 La Creu News 10 Soft ® ENERGY SAVING Negro Black Noir Schwartz Nero Preto 05 Gris textura Grey texture Gris à effet de texture Grau rauh-matt Grigio Cinzento textura N3 6 10-4338-N3-05 1 LED x 3W CREE 3000 ºK INCLUDED ST AL SIL 120

Open the catalog to page 13

14 La Creu News 10 Austin 6 05-4334-14-F9 1 x G9 Max.40W ® RF 850ºc Cristal opal mate Matt opal glass Verre opalin mat Matt opales Glas Vetro ottico satinato Vidro opalini mate F9 Blanco White Blanc Weiß Bianco Branco 14 ST OP GLA 76 140

Open the catalog to page 15

2 00-4335-14-M1 3 x PL Elec. E-27 Max.20W Konic ® ENERGY SAVING Blanco mate Matt white Blanc mate Weiß mat Bianco matt Branco satinado M1 Blanco White Blanc Weiß Bianco Branco 14 AL ACR DIF Ø 442 H max. 1500

Open the catalog to page 16

16 La Creu News 10 Kitchen 2 00-4344-05-05 1 x PL Elec. E-27 Max.23W 1 x E-27 Max. 100W Recommended Globe 20W ® RF 850ºc ENERGY SAVING Negro Black Noir Schwartz Nero Preto 05 AL Ø 450 H max. 1500 229

Open the catalog to page 17

Audrey ® ENERGY SAVING Blanco White Blanc Weiß Bianco Branco 14 2 15-4336-14-M1 3 x PL Elec. E-27 Max.23W 3 x E-27 Max.25W ST ACR DIF Ø480 115

Open the catalog to page 18

18 La Creu News 10 Nok ® RF 850ºc Transparente Transparent Transparent Durchsichtig Trasparente Transparente 37 Cromo Chrome Chrome Chrom Cromo Cromo 21 6 05-4351-21-37 1 x GU-10 Max. 50W AL TRANS GLA Ø 88 145 108

Open the catalog to page 19

20 La Creu News 10 Zam 4 12 05-4345-14-N3 1 x E-14 Max. 15W Recommended Megaman MU115 i 1 x 15W 05-4346-14-N3 2 x E-14 Max. 15W Recommended Megaman MU115 i 2 x 15W ® RF 850ºc ENERGY SAVING Gris textura Grey texture Gris à effet de texture Grau rauh-matt Grigio Cinzento textura N3 Blanco White Blanc Weiß Bianco Branco 14 AL ST Ø 80 360 93 93 145 145 145 45 45 145

Open the catalog to page 21

Bajo consumo • Energy saving • Économie d’énergie • Energiesparlampe Risparmio energetico • Poupança de energia 22 La Creu News 10 Materiales • Materials Simbología • Symbols Codifi cación • Codifi cation • Codifi cation • Bestell-Nummer • Codifi ca • Codifi cação DIFUSOR ACRÍLICO ACRYLIC DIFFUSER DIFFUSEUR ACRYLIQUE ACRYLDIFFUSOR DIFFUSORE ACRILICO DIFUSOR ACRILICO ALUMINIO ALUMINUM ALUMINIUM ALUMINIUM ALLUMINIO ALUMINIO ALGODÓN COTTON COTON BAUMWOLLE COTONE ALGODAO SILICONA SILICONE SILICONE SILIKON SILICONE SILICONE CRISTAL OPAL OPAL GLASS VERRE OPAL OPTISHES GLAS VETRO OTTICO VIDRO OPALINO...

Open the catalog to page 23

• Las descripciones y medidas de los aparatos del presente catálogo son orientativas, pudiendo por tanto ser modifi cadas, a fi n de mejorar las características técnicas o de diseño. • La empresa se reserva el derecho de anular o modifi car cualquier modelo sin previo aviso. • Todos los modelos presentados cumplen las normas exigidas por la C.E. para aparatos de iluminación de uso doméstico y sus características vienen determinadas por las clases I y II. • Los acabados y las especifi caciones técnicas corresponden a los productos que se suministran en Europa, pudiendo éstos variar en otros mercados....
