UNDERCABINET LIGHTING Standard length fixtures for linear lighting applications >

Pro-Halogen2-3 > The choice of professionals. Uses efficient 12-volt halogen lamps for precise white lightand long life. Premium construction provides maximum installation flexibility and low mounting surface contact temperatures. Line Voltage Halogen4 > Provides economical, attractive halogen lighting using 120-volt halogen lamps. Pro-Xenon5 > Professional grade 12-volt xenon fixtures. Premium construction provides maximuminstallation flexibility with long-life xenon lamps. Economy Xenon6 > Provides economical illumination using long-life 12-volt xenon lamps. Fluorescent7 > Creates bright,...

Step 2 Connect supply wires to fixture leads using push-in connectors. Step 1 Attach supply wiresto rear access cover. Step 3 Mount fixture to cabinet bottom using cap- tive mounting screws. >

ULH109 JC3-8 JC3-17 JC3-26 > 9" 1-Lamp Pro-Halogen Supplied with joiner connector, mounting hardware and (1) T3 12V 20W bi-pin halogen lamp. 9-1/2"L x 4-1/2"D x 1"H > 8", 17 & 26Ԕ Jumper Cords 3-wire Jumper Cord to electrically join fixtures when spaced apart, turning corners, or spanning cabinet frames. > Finish: BL-Black, BZ-Brushed Bronze, SL-Brushed Silver, WH-Designer White > Finish: BL-Black, WH-Designer White ULH214 ULH-CP > 14" 2-Lamp Pro-Halogen 6 Cord and Plug 3-wire grounded cord and plug accessory for portable plug-in installation. Supplied with joiner connector, mounting...

UH106-WH DWM1-WH > 6" 1-Lamp Line Voltage Halogen Direct Wire Module Required for permanentwiring of Line Voltage Halogen fixtures. Includes wiring enclosure and 36Ք field-shortenable jumper cord to bring power to right or left side of the fixture 3"L x 3"D x 1"H Supplied with field-shortenable 6 cord and plug, joinerconnector, (1) G8 120V 25W bi-pin halogen lamp, and mounting hardware. 6-1/8"L x 3"D x 1-5/16"H (Add 2" to length for side entry of power cord.) > Finish: Designer White UH212-WH > Finish: Designer White > 12" 2-Lamp Line Voltage Halogen JC2-8-WH JC2-17-WH JC2-26-WH Supplied...

UPX109 JC3-8 JC3-17 JC3-26 > 9" 1-Lamp Pro-Xenon Supplied with joiner connector, mounting hardware and (1) 12V 20W bi-pin high output xenon lamp. 9-1/2"L x 4-1/2"D x 1"H > 8", 17Ք & 26 Jumper Cords 3-wire Jumper Cord to electrically join fixtures when spaced apart, turning corners, or spanning cabinet frames. > Finish: BZ-Brushed Bronze, SL-Brushed Silver, WH-Designer White > Finish: BL-Black, WH-Designer White UPX214 ULH-CP > 14" 2-Lamp Pro-Xenon 6Ԓ Cord and Plug 3-wire grounded cord and plug accessory for portable plug-in installation. Supplied with joiner connector, mounting hardware and...

Finish: Appliance White ULX109-WH 9" Direct Wire 1-Lamp Xenon Finish: Finish: Finish: Supplied with 4-18W T5 wedge base xenon lamps, mounting hardware and 3/8 miniature die-cast electrical connector.24"L x 3-1/2"D x 1 3/16"H Appliance White Appliance White Appliance White Supplied with 2-18W T5 wedge base xenon lamps, mounting hardware and 3/8Ԕ miniaturedie-cast electrical connector.12"L x 3-1/2"D x 1 3/16"H > 6 Cord and Plug ULX212-WH 12" Direct Wire 2-Lamp Xenon ULX318-WH 18" Direct Wire 3-Lamp Xenon ULX424-WH 24" Direct Wire 4-Lamp Xenon 3-wire grounded cord and plug accessory for...

UFL12 UFL46 > 12" 8W T5 Direct Wire Fluorescent 46" 28W T5 Direct Wire Fluorescent Supplied with 8W T5 3000K tri-phosphor lamp, mounting hardware and 3/8Ք miniature die-cast electrical connector. 12-7/16"L x 2 5/8"D x 1-1/16"H Supplied with 28W T5 HE 3000K tri-phosphor lamp, mounting hardware and 3/8 miniature die- cast electrical connector. 46-5/16"L x 2 5/8"D x 1-1/16"H > Finish: WH-Appliance White, SL-Silver UFL22 > Finish: WH-Appliance White, SL-Silver > 22" 14W T5 Direct Wire Fluorescent Supplied with 14W T5 HE 3000K tri-phosphor lamp, mounting hardware and 3/8Ԕ miniature die- cast...

With its small size and ability to configure onthe job site, Trac 12 offers a unique capability to create a multitude of custom lighting effects. Miniature xenon lampholders can be spaced as required for undercabinet task lighting, undershelf accent lighting, toe-kick lighting, internally illuminating glass-front cabinets, and indirect lighting over cabinetry and in architectural coves. Trac 12 installations are powered from a remotely located 12 or 24- volt transformer. > Easy-to-conceal, ultra-miniature profileՕ10,000+ hour xenon lamps approximate thecolor of halogen...

6' Trac Section, 68-5/8". WH-White, BL-Black TL6 TL8 4' Trac Section, 44-5/8". WH-White, BL-Black 8' Trac Section, 92-5/8". WH-White, BL-Black TL4 > Trac 2' Trac Section, 20-5/8". WH-White, BL-Black TL201 (Single Lamp)TL202 (Double Lamp) Each trac section contains two solid copper 12 AWG conductors and is supplied with an endfeed connector,dead end, and mounting hardware. TL2 > Xenon Lampholder Resettable circuit breaker and dual tap primary to adjust for voltage drop. Vertical mount only. With polished aluminum reflector. WH-White, BL-Black Height: 3/8" 12-Volt Transformers Height: 5/8" >...

Recommended Illuminance Levels > Recommended Illuminance Levels Accent lighting usually requires 20 footcandles or less. > Indirectly lighting over cabinets or in architectural coves can increase the sense of spaciousness and add drama and pleasing warmth to an interior. > Incorrect Age As age increases, so does our need forlight. A typical 65-year-old needs 10 to15 times more light than a teenager to experience equal visual acuity. Recommended Illuminance Levels Cove lighting usually requires 20 footcandles or less. High Ambient Light Levels The apparentbrightness of a lighted countertop,...
