Recessed AVIO Surface AVIO > PAGE Trac > AVIO trac fixtures offer a clean, consistent appear- ance and the economy of a multi-lamp luminaire. surface fixtures have the same appearance as AVIO trac fixtures for situations where single mounting points exist or are desired. > TM recessed fixtures provide a low-profile aesthetic at the ceiling plane and are the perfect complement to other AVIO fixtures. >

with X16101 AirfoilTrim with X16201 AirfoilTrim TECHNICAL SPECIFICATIONS: One piece die-cast aluminum grid frameՕ Die-cast aluminum dual gimbal ring lampholders Dual gimbal ring design allows 45պ off-vertical adjustment in any direction Stainless steel suspension cablesՕ Integral electronictransformer (one per fixture) Dimmable Ֆ for bestresults use dimmer designed for use with electronic transformers Trac Super Adapter with on/off switchՕ Operates on all Juno line voltage trac includ- ing 2-circuit trac May be used with TW Series Extension Wands for high ceiling applicationsՕ Matching surface...

FINISHES : FINISHES : FINISHES : WHITE(WH)SILVER(SL) BLACK(BL)GRAPHITE(GP) WHITE(WH)SILVER(SL) BLACK(BL)GRAPHITE(GP) WHITE(WH)SILVER(SL)BLACK(BL)GRAPHITE(GP) CATALOG # LAMP CATALOG # LAMP CATALOG # LAMP XT16301 > THREE 20-50W MR16 XT16401 > FOUR 20-50W MR16 XT16404 > FOUR 20-50W MR16 > Integral 12-volt Electronic Transformer Integral 12-volt Electronic Transformer Integral 12-volt Electronic Transformer 8 1/8"13 1/4" 8 1/8" 8 1/4" 4 3/4" 4 3/4" 17 1/2" 9"9 1/2" CATALOG # CATALOG # CATALOG # X16301 > AIRFOILTRIM X16401 > AIRFOILTRIM X16404 > AIRFOILTRIM ( > ORDERSEPARATELY ) ( > ORDERSEPARATELY...

with X30101 AirfoilTrim TECHNICAL SPECIFICATIONS: One piece die-cast aluminum grid frameՕ Die-cast aluminum dualgimbal ring lampholders Dual gimbal ring design allows 45պ off-vertical adjustment in any direction Stainless steel suspension cables Օ Trac Super Adapter with on/off switch Operates on all Juno line voltage trac, including 2-circuit tracՕ May be used with TW Series ExtensionWands in high ceiling applications Matching surface mount and recessedversions available FINISHES : > WHITE(WH)SILVER(SL)BLACK(BL)GRAPHITE(GP) CATALOG # > LAMPFINISHES WH,BL,SL,GP > 9 1/4" 7"7" CATALOG # > FINISHES...

FINISHES : FINISHES : WHITE(WH)SILVER(SL) BLACK(BL)GRAPHITE(GP) WHITE(WH)SILVER(SL)BLACK(BL)GRAPHITE(GP) CATALOG # LAMPFINISHES CATALOG # LAMPFINISHES XT30201 > TWO 50-75W PAR30 > WH,BL,SL,GP XT30301 > THREE 50-75W PAR30 > WH,BL,SL,GP 9 1/4" 9 1/4" 7" 7" 19 1/2" 19 1/2" CATALOG # FINISHES CATALOG # FINISHES X30201 > AIRFOILTRIM WH,BL,SL,GP X30301 > AIRFOILTRIM WH,BL,SL,GP ( > ORDERSEPARATELY ) ( > ORDERSEPARATELY ) > 10 3/8" 10 3/8" 22 1/8" 22 1/8" Patent pending

FINISHES : FINISHES : WHITE(WH)SILVER(SL) BLACK(BL)GRAPHITE(GP) WHITE(WH)SILVER(SL)BLACK(BL)GRAPHITE(GP) CATALOG # LAMPFINISHES CATALOG # LAMPFINISHES XT30401 > FOUR 50-75W PAR30 > WH,BL,SL,GP XT30404 > FOUR 50-75W PAR30 > WH,BL,SL,GP 9 1/4"7" 25 7/8" 13 3/8"13 7/8"9 1/2" CATALOG # FINISHES CATALOG # FINISHES X30401 > AIRFOILTRIM WH,BL,SL,GP X30404 > AIRFOILTRIM WH,BL,SL,GP ( > ORDERSEPARATELY ) ( > ORDERSEPARATELY ) > 10 3/8" 28 3/8" 19"19"

The Framed Duo incorporates AVIO > TM aesthetics into a more traditional trac fixture format. Framed Duos can stand on their own in an application,or they can be used to complement other AVIO fixtures in a space. > 8 size="-1">

FINISHES : WHITE(WH)SILVER(SL) BLACK(BL) GRAPHITE(GP) TM CATALOG # LAMPDIMENSIONS CATALOG # LAMPDIMENSIONS T814 > TWO 20-50W MR16 T834 > TWO 50-75W PAR30 > Integral 12V Electronic Transformer 5 5/8" 5 3/4" FINISHES :WH,BL,SL,GP FINISHES :WH,BL,SL,GP 11 3/4" 16" WLH ACCESSORIESFOR T814: Color FiltersT551-5UV FilterT5522 Dichroic LensesT5501-18 Diffuse Spread LensT5520 Linear Spread LensT559 Prismatic Spread LensT557 Uniformity LensT5521 Hexcell LouverT5559BL T814T ( > ORDERSEPARATELYFOR T814) > 7 5/8"14 5/8"1 1/4"10 3/8"18 5/8"1 1/2" T834T ( > ORDERSEPARATELYFOR T834) > FINISHES :WH,BL,SL,GP H...

TECHNICAL SPECIFICATIONS: One-piece die-cast aluminum grid frameՕ Die-cast aluminumdual gimbal ring lampholders Dual gimbal ringdesign allows 45պ off-vertical adjust-ment in any direction Stainless steel suspension cablesՕ Integral electronictransformer (one per fixture) Dimmable Ֆ for best results use dimmer designed for use with electronic transformers Mounts over standard ceiling outlet boxesՕ 120V operating voltage Matching trac mount and recessed versions availableՕ Compatible with 1 with X16101 AirfoilTrim with X16201 AirfoilTrim 3 ⁄ 4 " dia. filters, lensesand louver Consult factory for...

FINISHES : FINISHES : FINISHES : WHITE(WH)SILVER(SL) BLACK(BL)GRAPHITE(GP) WHITE(WH)SILVER(SL) BLACK(BL)GRAPHITE(GP) WHITE(WH)SILVER(SL)BLACK(BL)GRAPHITE(GP) CATALOG # LAMP CATALOG # LAMP CATALOG # LAMP XS16301 > THREE 20-50W MR16 XS16401 > FOUR 20-50W MR16 XS16404 > FOUR 20-50W MR16 > Integral 12-volt Electronic Transformer Integral 12-volt Electronic Transformer Integral 12-volt Electronic Transformer 8 1/8"13 1/4" 8 1/8" 8 1/4" 4 3/4" 4 3/4" 9 1/2" 17 1/2" 9" CATALOG # CATALOG # CATALOG # X16301 > AIRFOILTRIM X16401 > AIRFOILTRIM X16404 > AIRFOILTRIM ( > ORDERSEPARATELY ) ( > ORDERSEPARATELY...

TECHNICAL SPECIFICATIONS: One-piece die-cast aluminum grid frameՕ Die-cast aluminumdual gimbal ring lampholders Dual gimbal ring design allows 45պ off-vertical adjust-ment in any direction Stainless steel suspension cables Օ Mounts over standard ceiling outlet boxes 120V operating voltageՕ Matching tracmount and recessed versions available with X30101 AirfoilTrim FINISHES : WHITE(WH)SILVER(SL)BLACK(BL)GRAPHITE(GP) CATALOG # LAMPFINISHES XS30101 > ONE 50-75W PAR30 > WH,BL,SL,GP 9 1/4" 7"7" CATALOG # FINISHES X30101 > AIRFOILTRIM WH,BL,SL,GP ( > ORDERSEPARATELY ) > 10 3/8"10 3/8"
