Unit Features: The Integrity Wood Ultrex Sliding Patio Door is constructed with an exterior frame of Ultrex, a fiber-reinforced material that resists thermal conductance, and an interior of kiln-dried clear pine. Available colors for the frame and panel include stone white, pebble gray, and bronze. The hardware features a single-point non-keyed handle/lock in various finishes.

NFRC Values: Certified NFRC unit values are provided for different glazing types, detailing U-Factor, R-Value, Solar Heat Gain Coefficient, and Visible Light Transmission. These metrics are essential for assessing the thermal performance and energy efficiency of the doors.

Egress, Lite, and Vent Measurements: The document includes detailed measurements for daylight opening, lite, vent, and egress for various door configurations, such as 2-panel and 3-panel doors, with explanations of abbreviations used.

Sizing Guidelines: Guidelines for rough opening measurements and unit conversions between imperial and metric systems are included, along with recommendations for factory and field mulling of multiple assemblies.

Section Details: Detailed section drawings are provided for different jamb sizes and configurations, including direct glaze transoms and mullions, which are crucial for installation and understanding the structural components.

Divided Lite Options: Descriptions of options for simulated divided lites (SDL), removable wood grilles, and grilles between glass (GBG) are included, with patterns and alignment guidelines.

Installation Suggestions: Recommendations include using factory-applied folding nailing fins and drip cap systems for installation, with optional brackets for masonry applications. Field mulling kits are available for standard assemblies.

Performance Rating: The sliding patio door meets ANSI/AAMA/WDMA 101/I.S. 2-97 SGD-R30 standards, ensuring reliability and performance.
