Unit Features: The Integrity Wood Ultrex Sliding French Door is designed with an exterior frame made of Ultrex, a durable, fiber-reinforced material that resists thermal conductance, paired with a clear pine interior. The frame includes a water-repellent, preservative-treated sill and is available in multiple colors. The panel construction also utilizes Ultrex and clear pine, with specified dimensions for sash, stiles, and rails.

NFRC Values: Certified NFRC unit values are provided for various glazing types, detailing U-Factor, R-Value, Solar Heat Gain Coefficient, and Visible Light Transmission, which reflect the door's thermal performance and energy efficiency.

Egress, Lite, and Vent Measurements: The document includes detailed measurements for daylight opening, vent, and egress across different door models, ensuring compliance with building codes.

Sizing Guidelines: It offers guidelines for rough opening measurements and conversions for two and three-panel doors, with specific instructions for both factory and field mulling.

Section Details: Detailed diagrams and measurements for jambs, transoms, and mullions are provided, with options for various jamb sizes.

Divided Lite Options: Options for simulated divided lites, removable interior grilles, and grilles-between-the-glass are outlined, with specified patterns and dimensions.

Installation Suggestions: Recommendations include the use of factory-applied nailing fins, optional installation brackets for masonry, and field mulling kits for standard assemblies.

Performance Rating: The door meets ANSI/AAMA/WDMA standards, ensuring reliability and performance.

Overview: The document provides technical specifications and installation suggestions for sliding French doors, focusing on construction types such as brick veneer with steel frame, wood siding with 2x6 frame, and stucco with 2x4 frame. It emphasizes that the wall sections depicted are typical conditions and not installation instructions.

Specifications: Sliding French doors are available with divided lite patterns. Dimensions for masonry and rough openings, as well as frame sizes, are provided for each construction type.

Installation Suggestions:

• Brick Veneer with Steel Frame Construction: Includes head, jamb, and sill details with specific measurements for masonry and rough openings.
• Wood Siding with 2x6 Frame Construction: Similar details as above, with emphasis on frame size and rough opening dimensions.
• Stucco with 2x4 Frame Construction: Provides head, jamb, and sill details, focusing on frame size and rough opening dimensions.

Important Note: The document stresses that the wall sections are not intended as installation instructions. Users should refer to the specific installation instructions provided with the purchased units.
