Product Catalogue

Product Catalogue
1 / 16 PagesView full catalog

Product Catalogue

Product catalog summary
Overview: This document outlines the specifications and features of various auditorium seating solutions provided by Hamari. Each seating model is tailored with specific materials, ergonomic designs, and customization options to suit different spatial and functional needs.
Seating Solutions:
1. Drama Chair: Features a curved plywood backrest, steel tube frame, and counterweight seat mechanism. Options include steel legs, upholstered side panels, writing tablets, and various armrest materials. Complies with fire safety standards NF D 60-013, BS5852 Crib 5, and AM 18.
2. Edu and EduWall: Designed for compact spaces with a depth of less than 30 cm. Constructed with steel tubing and molded plywood seats and backs. Offers upholstery and writing tablet options. Fire safety compliant.
3. Form Chair: Fully upholstered seat and back designed by Jukka Setälä, with a steel tube frame and counterweight seat mechanism. Includes armrest and writing table options. Fire safety compliant.
4. HLA-Wall: Wall-mounted design for high step rises, developed with Henning Larsen Architects. Offers ergonomic seating with armrest and writing tablet options. Fire safety compliant.
5. Mono Chair: Compact design with integrated armrests and a spring-loaded folding mechanism. Designed by Philip Kronqvist. Fire safety compliant.
6. Odeon: Ergonomically designed with writing tablet options within armrests. Constructed with wooden side panels and a counterweight seat mechanism. Fire safety compliant.
7. Pori: Suitable for steep staircases with molded back and U-form armrests. Offers writing tablet options. Fire safety compliant.
8. Primo Series: Includes basic, telescopic, and moveable bench solutions with ergonomic features. Constructed with steel tubing and counterweight seat mechanisms. Offers armrest and writing tablet options. Fire safety compliant.
9. Slim Chair: Features a form-pressed back and solid wood armrests, designed by Timo Ripatti. Focuses on elegance and functionality. Fire safety compliant.
10. Tablet Solutions: Includes slide, semi-folding, and fixed tables designed for various spatial constraints. Constructed with steel frames and birch plywood surfaces.
Furniture Solutions:
1. Deep Step Table: Designed for curved rows with a 19 mm MDF surface and solid wood lipping. Assembled to the chair back with a powder-coated steel bracket.
2. Armrest Table: Folds under the armrest with a gas spring-driven "anti-panic" function. Made of 12 mm birch plywood, integrated into the chair's leg structure.
3. Hinge Table: Suitable for limited step depth with a silent folding mechanism. Made of 19 mm MDF with veneer or laminate and solid wood lipping.
4. Box Table: Folds into a wooden case, ideal for limited step depth. Made of solid wood or veneered plywood, with a 12 mm birch plywood table.
5. NoteWB: For situations where tables cannot be mounted to chair backrests. Features a powder-coated steel frame with power socket and LAN options, and a 12 mm birch plywood table.
6. Speaker Stand Lassard: A wooden podium with a shelf and accessories, made of veneered LDF-board. Options for LED lights, tempered glass logos, and wheels. Available in various wood types and finishes.
7. Telescopic Seats: Typically available with the Primo chair, adaptable to other models based on auditorium structure.
See more

Catalog excerpts

Product Catalogue-1

Drama is a comfortable chair with a curved plywood backrest. The theatre model comes with steel legs or upholstered side panels. Construc on: Steel tube 40 x 30 mm. The seat works with a counterweight placed above seat inside the upholstery. Seat upholstered, with veneered plywood/perforated seat bo om or fully upholstered. Front of the form-pressed curved and veneered backrest upholstered. Wri ng tablet: NoteWB Armrests: Steel armrest with solid wood or 9 mm plywood upholstered with fabric or leather. Foams: Seat 10 cm CMHR50, back 5 cm shaped CMHR35 Angle of back: 16 degree Wooden parts: Birch, beech, ash, maple, oak etc. lacquered, stained or painted with the desired color Metal parts: Epoxy painted with the desired RAL color Fabric demand: 1.2 m / pcs Meets fire safety requirements: NF D 60-013 BS5852 Crib 5 AM 18 HAMARI auditorium furniture solu ons oy Runeberginkatu 34 e FI-06100 Porvoo www.hamari.pro +358 50 464 1375

 Open the catalog to page 1
Product Catalogue-2

EDU Edu auditorium seats have molded plywood seat and back. Edu takes up less than 30 cm of depth and so it is especially suitable for smaller spaces. Construc on: Steel tube 30 x 40 mm. The seat works with the counterweight placed under the seat. 12 - 15 mm plywood or laminate surface seat and back. Upholstered or without upholstery. Foams: 3 cm in the seat and 2 cm in the back Angle of back: 11 degrees Armrests: Wooden armrest L shaped or without armrest Wri ng tablet: Fixed table on the back of the chair. Foldable tablet under the armrest. Wooden parts: Birch, beech, ash, maple, oak etc. lacquered,...

 Open the catalog to page 2
Product Catalogue-3

EduWall auditorium seat has molded plywood seat and back. EduWall takes up less than 30 cm of depth and so it is especially suitable for smaller spaces and where open floor area is needed. Construc on: Steel plate 5 mm. The seat works with the counterweight placed under the seat. 12 - 15 mm plywood or laminate surfaced seat and back. Upholstered or without upholstery. Armrests: Wooden armrest L shaped or without armrest Foams: 3 cm in the seat and 1 cm in the back Angle of back: 11 degrees Wri ng tablet: No table EduWall and Edu Wooden parts: Birch, beech, ash, maple, oak etc. lacquered, stained...

 Open the catalog to page 3
Product Catalogue-4

FORM Form is designed by Jukka Setälä. It has a completely upholstered seat and back. Construc on: Steel tube 30 x 40 mm. The seat works with counterweight placed above seat inside the upholstery. Form-pressed seat and backrest, both sides upholstered. Wri ng table: NoteWB Armrests: Steel armrest. Op on armrest with solid wood, fabric or leather surface. Foams: Seat 5 cm CMHR50, back 4 cm CMHR35 Angle of back: 15/24 degrees Wooden parts: No visible wooden parts Metal parts: Epoxy painted with the desired RAL color Fabric demand: 1.2 m / chair Meets fire safety requirements: NF D 60-013 BS5852...

 Open the catalog to page 4
Product Catalogue-5

HLA-WALL HLA-Wall lecture room chair is designed in co-opera on with Henning Larsen Architects. HLA-Wall is a solu on especially designed for high step rises. It has good ergonomic proper es, and it is suitable with almost all types of desktop and armrests solu ons. High panel plates are included in the delivery. Construc on: Steel frame wall mounted without separate legs. The seat works with counterweight placed above seat inside the upholstery. The underside of the seat can be upholstered or in plywood/perforated. The backrest upholstered, foam is shaped to give good sea ng comfort. The back...

 Open the catalog to page 5
Product Catalogue-6

MONO MONO chair appears as a rectangular case and opens up into a back, a seat and armrests in one movement of the hand. When closed, the chair is only 12 cm deep. The seat is spring-loaded, and returns to the casing simultaneously with the backrest and armrests. MONO is designed by Philip Kronqvist. Construc on: Covered metal plate frame. The underside of the seat and backplate of the backrest veneered or laminated. The seat and backrest upholstered, foam shaped to give good sea ng comfort. Wri ng tablet: Separate table e.g. NoteWB Armrests: Integrated armrest Foams: Seat 7 / 3 cm, back 2 /...

 Open the catalog to page 6
Product Catalogue-7

ODEON Odeon is a seat designed by Jouko Järvisalo. It has good ergonomics and can accommodate a wri ng top inside the armrests. Construc on: Wooden side panels 60 mm. The seat works with counterweight placed above seat inside the upholstery. Seat upholstered, with veneered plywood/perforated seat bo om or fully upholstered. Back upholstered, background 9 mm veneered plywood with solid wood lists around. Wri ng tablet: Armrest tablet in the side panel or several op ons on the back of the chair. Armrests: On the side panel. Foams: Seat 5 cm shaped CMHR50, back 8 / 5 cm shaped CMHR35 Angle of back:...

 Open the catalog to page 7
Product Catalogue-8

PORI Pori auditorium seat has a molded back and U-form armrests. It is especially suited for premises where the staircase rises steeply. Construc on: Steel tube 30 x 40 mm. The seat works with counterweight placed above seat inside the upholstery. Seat upholstered, with veneered plywood/perforated seat bo om or fully upholstered. Back upholstered, background 15 mm form-pressed veneered plywood. Wri ng tablet: All types available Armrests: U or L shaped or without Foams: Seat 5 cm CMHR50, back 3 cm CMHR35 Angle of back: 21 degrees Wooden parts: Birch, beech, ash, maple, oak etc. lacquered, stained...

 Open the catalog to page 8
Product Catalogue-9

PRIMO Primo is a well-formed basic seat with good ergonomic proper es. Primo has been delivered in various versions for different types of applica ons, from schools to theatres. It can be used with all types of desktop solu ons, such as armrests that fold down or tables a ached to the back of the seat. The ergonomic Primo family also includes PriMove, moveable bench solu on, and Primo telescopic chair. Construc on: Steel tube 30 x 40 mm. The seat works with counterweight placed above seat inside the upholstery. The underside of the seat can be upholstered or veneered plywood/perforated. The backrest...

 Open the catalog to page 9
Product Catalogue-10

PRIMOVE Layout can easily be modified with PriMove auditorium seat by stamping the benches either up and down. PriMove is very effec ve to store and it has possibility to standard armrest table or all other tables behind the backrest. The ergonomic Primo family also includes Primo auditorium chair and telescopic chair. Construc on: Steel tube 30 x 40 mm. The seat works with counterweight placed above seat inside the upholstery. The underside of the seat can be upholstered or veneered plywood/perforated. The backrest is upholstered, foam shaped to give good sea ng comfort. Background is 9 mm veneered...

 Open the catalog to page 10
