BATCH WASHER CONTINUOUS WASHING SYSTEM TBS-50

CONTINUOUS WASHING SYSTEM EFFICIENCY FOR LARGE-SCALE PRODUCTIONS Automatic continuous washing is the linen washing and drying system that is most efficient for large-scale production requirements. It consists of a loading system, a batch washer, an extraction press and a drying system. Girbau’s TBS-50 washing system includes all the equipment required for continuous washing, with the advantages of synchronisation, programming and management that comes with working with equipment from a single supplie. PARTNERS IN YOUR BUSINESS, FROM THE OUTSET Girbau does not simply manufacture equipment. It...

Proportional load: The dosage of chemicals and water is automatically adjusted depending on the load, which can range from 30 to 55 kg. CONSUMPTION The TBS-50 batch washer features integrated recirculation and recycling of the water, allowing it to be used up to three times. In addition to reducing water consumption, it also reduces energy consumption. The mechanical action is achieved with a programmable inversion angle of 270° and a drum designed specifically for this purpose, thereby obtaining an optimum quality wash. S BLOCKAGES Transferring the load through a large central opening by rotating the...

A USER-FRIENDLY AND INTUITIVE ENVIRONMENT The information is displayed in an easy and intuitive way, making it easy to control, manage and program the batch washer. The colour graphics, illustrations and multiple language options help the user to understand and manage the software. All data is exportable in spreadsheet format for later treatment as desired. REAL TIME INFORMATION AND TRACKING The BMT can control all the parameters associated with each load, such as the number of programs and customers, the weight of the load and the processing time. All the parameters involved can be controlled...

The batch washer that demonstrates that simplicity can mean effectiveness. It has all the necessary features, with excellent performance, high production and minimal maintenance. A PROFESSIONAL SOLUTION FOR A WIDE RANGE OF PURPOSES • Independent pre-wash, washing, rinsing and neutralising phases. • Two recovery tanks: the main tank and another in the extraction press area. • An electronic flow control system for water inputs. • Vapor en todos los modulos de lavado.Steam in all the washing modules. • De-sanding and thermostop function. • Suitable for general washing applications, industrial laundering,...

The Hygien-Tunnel carries out intensive washing processes for laundry with a high level of soiling or those that require disinfection. It is especially suitable for the health sector. MAXIMUM GUARANTEE OF HYGIENE • Intensive washing applications. • An intermediate tank, with a built-in filter that allows water to be recovered at a high temperature. The filter allows the water to be cleansed of fibres and coloured particles to prevent them from being transferred to subsequent loads. • An electronic flow control system for water inputs.. • An option for keeping the soaking phase separate from the...

The batch washer that allows absolute flexibility and versatility in the design of the bath diagram. THE MOST VERSATILE OPTION IN BATCH WASHERS • The batch washer allows each module to be configured independently. Each module operates completely autonomously from the rest. • Halted baths: the flexibility is such that it can be configured in a variety of ways, ranging from a pre-wash on flow, a wash on or counter flow, a rinse counter flow, and even a wash through individual chambers with processes that are completely separate from each other. The option allows the user to work with loads with...

A COMPLETE SOLUTION IN INDUSTRIAL LAUNDERING GIRBAU BATCH WASHING SYSTEM BAG SYSTEM Girbau offers made to measure solutions for bag loading systems. Our engineering sales team can create a project tailored to the needs of each client. Bag loading systems allow the linen to be selected, stored and loaded into one or several batch washers existing in the laundry. LOADING CONVEYOR A sloping conveyor with 3 or 4 compartments of 50kg each allow the batch washer. It incorporates automatic weighing and moves forward automatically at the batch washer’s work pace. BATCH WASHER The TBS-50 batch washer’s...

EXTRACTION PRESS The SPR-50 press extracts the water from the loads coming from the batch washer. In under two minutes, the pressure extracts the water from the load, thereby aiding the drying and ironing operations, and reducing the cost of these processes. UNLOADING CONVEYOR The CED+ movable elevating conveyor makes it possible to distribute the linen loads coming from the extractor press. Fitted with one or two loading tables, it automatically distributes the loads to the dryers depending on their availability. DRYERS The ST2700 and ST1302 dryers, with up to 135kg and 63kg capacities respectively,...

MORE CONTROL, LESS CONSUMPTION ECO + is a key option for clients who value energy efficiency and good cost management in the laundry, without having to give up the best washing quality. The ECO + option incorporates an electronic flow control system into the batch washer in all water inputs, both those from the mains supply and inputs of re-circulated water. WATER CONSUMPTION Washing machines -60% Other batch washers ENERGY CONSUMPTION Washing machines -40% Other batch washers SAVINGS: 80% water consumption, 70% energy, 40% detergents, 100% labour. ← Cold water Re-circulated water WATER-WATER...

TBS-50 Batch washer MODEL
