Product catalog summary

Overview of UNA Bathroom System

UNA is a modular architectural bathroom system designed by Romano Adolini, offering customizable solutions for both small and large wellness spaces. It combines structural modules with semi-inset sanitaryware, including back-to-wall and wall-hung units, and thick shelves for basins, enabling flexible and personalized bathroom designs.

Materials and Customization

The system supports a variety of materials such as wood, marble, mosaic, and pietraluce, available in multiple colors. This allows designers to create unique environments by balancing warm and cold tones. UNA supports both linear and angular configurations to enhance design versatility.

Sanitaryware and Functional Features

UNA includes semi-inset sanitaryware: washbasins in two sizes (75 cm and 90 cm), a toilet, and a bidet with wrapping seats and covers. The bidet features an innovative water delivery system with a mixer control on the shelf and a front-positioned spout. All sanitaryware comes with drainage connectors and fixing kits for installation.

Modular Furniture and Shelving

Furniture modules and shelves are customizable in length from 100 cm to 240 cm. Options include cases with one, two, or no compartments, finished in various Flaminia finishes or multilayer phenolic wood compatible with coverings up to 25 mm thick. These modules accommodate sanitaryware and provide storage, adapting to different spatial needs.

Installation and Accessories

All furniture and shelves include installation components. Optional chromed accessories are available, including a toilet paper holder, brush holder, soap holder, and bidet mixer, which can be integrated into the furniture.

Design Intent and Applications

UNA is designed for both residential and contract environments, aiming to maximize space efficiency in small bathrooms and address complex layouts in larger spaces. Its elegant linear elements provide practical and aesthetic solutions for diverse bathroom designs.

Technical Specifications and Dimensions

The document provides detailed technical drawings and dimensions for all components, including sectional, zenithal, frontal, and lateral views. Key features include removable inspection parts, water outlet tubes, floor drainage connectors, and customizable module lengths ranging from 75 cm to 240 cm depending on the element.

Product Types and Dimensions

Cases for semi-inset basins: lengths from 180 to 240 cm (for 75 cm basin) and 200 to 240 cm (for 90 cm basin).
Shelves for semi-inset basins: multiple size ranges (100–240 cm) depending on model and basin size.
Cases with double openings available in various configurations and lengths.

Materials and Finishes

Structure: multilayer phenolic wood.
Wood finishes: dark oak, light oak, zebrawood, pietraluce.
Colors: white, ultramarine blue, black, red, sand beige.

Measurement and Ordering Instructions

Measurements must be provided in millimeters.
Key dimensions to specify: left distance (a), right distance (b), total length (c), and for WC/bidet cases total length including all distances (d).
Verify that sums of distances match total lengths to avoid errors.
Select article type, material, and finish carefully.
Consult technical data sheets before filling measurements.

Ordering Procedure

Photocopy the provided A4 form.
Fill all fields accurately with measurements in millimeters.
Mark article number, material, color, and opening positions where applicable.
Send the completed form with the order.
Note that WC and bidet positions are indicative and can be inverted without specification.

Views and Visual References

Drawings include top (zenithal), frontal, and side views to assist dimensioning and configuration understanding.
Storage compartment openings are specified as right, left, or double opening.

Notes and Recommendations

Measurements must be precise and verified against official technical sheets.
The "Una" module is mandatory for customized furniture production for basins, WC, and bidet.
Ensure the sum of left and right distances equals total length to prevent errors.

Quality and Certifications

Certified under UNI EN ISO 9001:2000 (No. 3991-A) and UNI EN ISO 14001:2004 standards.

Company and Contact Information

Ceramica Flaminia S.p.A., Civita Castellana, Italy.
Phone: +39-0761-542030, Fax: +39-0761-540069.
Email: [email protected], Website: www.ceramicaflaminia.it.

Critical Points and Best Practices

Always verify measurements against the official catalog before ordering.
Complete all measurement fields accurately in millimeters.
Confirm that left and right distances sum correctly to total length.
Clearly mark all product details to ensure correct processing.

Conclusion

This document serves as a comprehensive technical and ordering guide for the UNA modular bathroom system, emphasizing precise measurement, material and finish selection, and proper form completion to ensure accurate production and installation. UNA offers a flexible, elegant, and highly customizable solution for diverse bathroom design needs.

Catalog excerpts

UNA, by Romano Adolini, is an architectural system for bathroom which, according to materialsand sizes, creates different solutions for both small and large spaces dedicated to wellness. UNA is a real system at designers disposal; infact they can customize each room matching the various structures and the semi-inset sanitaryware. Back to wall cases for wc and bidet can be mixed with wall hung cases or thick shelves for basin. UNA cases perfectly suit all furniture and accessories of Ceramica Flaminia collection. UNA, un sistema architettonico per la stanza da bagno disegnato da Romano Adolini...

Open the catalog to page 2

Legno, marmo, mosaico, pietraluce in diversi colori sono i materiali in cui si possonorealizzarei moduli UNA, conferendo forte personalizzazione allambiente bagno. UNA cases can be realized in wood, marble, mosaic and pietraluce in different colours,giving to bathroom a great customized aspect. > 0203 size="-1">

Open the catalog to page 3

Moduli a terra, moduli sospesi, grandi mensole personalizzabili nelle dimensioni, fanno diUNA un vero e proprio sistema di architettura per il bagno. UNA back to wall or wall hung cases and large shelves, customized in lenght, create a realarchitectural system for bathroom. > 0809 size="-1">

Open the catalog to page 6

Diverse dimensioni dei moduli UNA permettono di risolvere larredo sia di piccoli bagni chedi grandi stanze. Furnishing both small and large bathrooms is simple using UNA cases in various dimensions. > 2425 size="-1">

Open the catalog to page 14

red / white black bianco nero / rosso cuoio / marine blue sand / beige beige blu ultramarina / sabbia / light oak dark oak zebrano > rovere sbiancato / rovere moro / zebrano / >

Open the catalog to page 23

connessione di scarico apavimento (in dotazione) > tubo di risciacquo Ҙ40 conmorsetto in gomma (in dotazione) water outlet tube 40 with holdfast (included in the box) > wc floor drainage connector (included in the box) > 4827848374 140450 70 > 170260430 335 374 elemento rimovibile per lؒispezione 450 565 140450 removable part for inspection > erogatore bidet (in dotazione) > bidet spout (included in the box) gruppo sifone per bidet1"1/4 - 32 mm (in dotazione) > 1"1/4 - 32 mm siphon kit for bidet (included in the box) 48 > 160 160 170260420 400430 100160 225 120 elemento rimovibile per lispezione...

Open the catalog to page 24

vista laterale vista frontale >

Open the catalog to page 25

450590800 400830400 / zenital view 450 59040036040 400 / zenital view vista zenitale > / side view 360 / frontal view / side view 830400 800 800 / frontal view 40 > vista laterale vista frontale vista laterale vista frontale > 450590800 400830400 / zenital view 450 59040036040 / zenital view vista zenitale > / side view 360 400 / frontal view / side view 830400 / frontal view 40 > vista laterale vista frontale vista laterale vista frontale >

Open the catalog to page 26

450590800 400830400 450590800 400830400 / zenital view / zenital view vista zenitale vista zenitale > 50300450590800 400830400 / side view / side view / frontal view / frontal view 830400 50 830400 800 800 800 > vista laterale vista laterale vista frontale vista frontale > 450590800 400830400 / zenital view / zenital view vista zenitale vista zenitale > 50300 / side view / side view / frontal view / frontal view 830400 50 830400 800 > vista laterale vista laterale vista frontale vista frontale >

Open the catalog to page 27

min 900/max 1200750 min 500/max 1500750 750 min 500/max 1900 450590 450590 > 50300450590800 400830400 / side view / side view / frontal view / frontal view 830400 50 830600 450590800 200830600 800 800 50400 50400 50400 > vista laterale vista laterale vista frontale vista frontale min 1000/max 1200 min 1000/max 1200900 min 1000/max 1200 min 500/max 1900 min 500/max 1900 > / zenital view / zenital view vista zenitale vista zenitale min 1000/max 1200900 min 500/max 1900750 450590 450590 > 50300 / side view / side view / frontal view / frontal view 830400 50 830600 800 800 50400 > vista laterale...

Open the catalog to page 28

light oak wood finishes marine blue > pietraluce dark oak materials red zebrano sand white beige black / zenital view bianco - blu ultramarina - nero - rosso cuoio - sabbia - beige - rovere moro - rovere sbiancato - zebrano - struttura in legno multistratofenolico da rivestire multilayer wooden structure to be covered pietraluce - finiture legno / materiali / vista zenitale > / side view / frontal view 830600 800 vista laterale vista frontale > photocopy this A4 page, carefully fill in and send it with the order. notes: - fill in each blank with the length in millimiter. - a = left distance of...

Open the catalog to page 29

light oak wood finishes light oak marine blue wood finishes marine blue pietraluce dark oak pietraluce dark oak materials red materials red zebrano zebrano sand white beige sand white beige black black bianco - nero - rosso cuoio - sabbia - beige - rovere moro - zebrano - blu ultramarina - rovere sbiancato - struttura in legno multistratofenolico da rivestire multilayer wooden structure to be covered pietraluce - finiture legno / bianco - nero - rosso cuoio - sabbia - beige - rovere moro - zebrano - blu ultramarina - rovere sbiancato - struttura in legno multistratofenolico da rivestire multilayer...

Open the catalog to page 30

light oak wood finishes marine blue light oak wood finishes marine blue art. UNA75/90V1 pietraluce dark oak pietraluce materials red dark oak for materials art. UNA75/90V1 red zebrano for right opening left opening zebrano sand white - right beige / only sand white beige black black / only dx beige - bianco - nero - rosso cuoio - sabbia - rovere moro - zebrano - vano dx - vano sx - blu ultramarina - rovere sbiancato - pietraluce - solo per finiture legno / rovere moro - bianco - blu ultramarina - nero - rosso cuoio - sabbia - beige - rovere sbiancato - zebrano - pietraluce - finiture legno /...
