12 SERIES Time switches 16 A Mechanical time switches - Daily time setting* - Weekly time setting** Type 12.01 - Daily - 1 CO 16 A - 35.8 mm wide - 35 mm rail mount Type 12.11 - Daily - 1 NO 16 A - 17.5 mm wide - 35 mm rail mount Type 12.31-0000 - Daily - 1 CO 16 A - 72 x 72 mm - Front panel mount Type 12.31-0007 - Weekly - 1 CO 16 A - 72 x 72 mm - Front panel mount • Minimum time interval setting: 1 h (12.31-0007) 30 min (12.01) 15 min (12.11 - 12.31-0000) * Same program every day ** Different program possible for each of the 7 days of the week For outline drawing see page 15 Contact specification...

• Digital time switch • 1 CO 16 A Type 12.51 Digital (analogue-style) time switch, daily/weekly programming - Can be programmed in “Classic” mode via the joystick, or “Smart” mode via smartphones with NFC communication - Minimum time interval setting - 30 minutes - Easily configurable for daily or weekly programming Type 12.81 Digital Astro-switch - Can be programmed in “Classic” mode via the joystick, or “Smart” mode via smartphones with NFC communication - Astro program: calculation of sunrise and sunset times through date, time and location coordinates - Option for Astro ON period override,...

Digital time switch, weekly programming - Can be programmed in "Classic" mode via the joystick, or "Smart" mode via smartphones with NFC communication Type 12.61 - 1 CO 16 A Type 12.62 - 2 CO 16 A • Functions: Switch ON, Switch OFF Pulse: 1s...59 min • Minimum time interval setting - 1 minute • Summer/Winter European, Australian, Brazilian time • LCD status indication, set-up and programming • Lock with a 4-digit PIN • Back-light display • Internal battery for set-up and programming without supply, easily replaceable from the front • Protective separation between supply and contacts • 35 mm wide...

• Weekly programming • 1 CO 16 A • Switch ON, Switch OFF, Pulse Weekly Astro time switch - Can be programmed in “Classic” mode via the joystick, or “Smart” mode via smartphones with NFC communication - "Astro" program: calculation of sunrise and sunset times through date, time and location coordinates Type 12.A1 - 1 CO 16 A Type 12.A2 - 2 CO 16 A Type 12.B2 - 2 CO 16 A • Functions: "Astro" ON, "Astro" OFF Switch ON, Switch OFF Pulse: 1s…59 min • Location coordinates easily settable for most European countries through Post codes • Offest function: allows programming of switching times offset from...

Weekly Astro time switch - Suitable for applications where a variable light level is required - programmable via smartphone with NFC communications - Compatible with power supply/ballasts with 0-10V or PWM inputs Type 12.A4 - 1 analog output: 0-10V or PWM • Functions: "Astro" ON, "Astro" OFF, ON/OFF • Location coordinates easily settable for most European countries through Post codes • Offest function: allows programming of switching times offset from the astronomic time (by up to 90 min, in 1 min step) • Minimum time interval setting - 1 minute • 50 storable programs • Summer/Winter European,...

12 SERIES Time switches 16 A U0 finder Electronic digital time switches - 1 Weekly time setting Type 12.71 - 1 CO 16 A - 17.8 mm wide • Minimum time interval setting - 1 minute • Internal battery for set-up without supply • Pulse output function: 1 s...59:59(mm:ss) • Automatic adjustment for daylight saving • 35 mm rail (EN 60715) mount Digital weekly time switch 1 CO 16 A 17.8 mm wide For outline drawing see page 15 * Switching times in memory may be used more than once i.e. when selected for different days.

Ordering information Example: 12 series digital (analogue style) time switch, 1 CO 16 A contact, (110...230)V AC/DC supply Series Type 0 = Daily, 35.8 mm wide 1 = Daily, 17.5 mm wide 3 = Daily or Weekly, 72 x 72 mm 5 = Digital (analogue style), NFC programming, 35 mm wide 6 = Weekly, NFC programming, 35 mm wide 7 = Weekly, 17.5 mm wide 8 = Astro-switch, NFC programming, 35 mm wide A = Weekly "Astro” NFC programming, 35 mm wide B = Yearly Astro, Bluetooth 5 and NFC, 35 mm wide No. of poles- 1 = 1 CO (SPDT), 16 A 1 = 1 NO (SPST-NO), 16 A 2 = 2 CO (DPDT), 16 A 4 = Analog output: 0-10V or PWM Option...

12 SERIES Time switches 16 A finder Technical data Insulation Dielectric strength between supply and contacts Dielectric strength between open contacts Rated impulse voltage (between supply and contacts) Rated impulse voltage (between open contacts) L 12 - Rated current v ambient temperature

12 SERIES Time switches 16 A Type 12.11 Selector switch: = Permanently OFF = Automatic I = Permanently ON Type 12.01 Selector switch: = Permanently OFF AUTO = Automatic I = Permanently ON L

12 SERIES Time switches 16 A POWER SUPPLY OR O ALIMENTATORE BALLAST BALLAST POWER SUPPLY OR O ALIMENTATORE BALLAST BALLAST Type 12.A4 NB: All the outputs follow the same programm

12 SERIES Time switches 16 A Wiring diagrams Type 12.A4 with 15.11 Application example with slave dimmer Type 15.11 Using the maximum number of expansions, you can make up to 6 outputs and 8 inputs out of it In this application you can use a range extender (Type 1Y.E8) to reach the most distant devices.

Different programming modes for type 12.51, 12.61, 12.62, 12.81, 12.A1, 12.A2, 12.A4, 12.B2"Smart” "Classic” Mode via the joystick Bluetooth programming (Type 12.B2 only) Finder Toolbox for programming Finder Toolbox for reference Once the App FINDER Toolbox is downloaded and installed, you can read an existing program, Finder Toolbox provides all or program your device with maximum flexibility, changing the smallest details and saving your technical data sheets and news program directly to your smartphone. from Finder Toolbox. At this point you simply touch the time switch with the smartphone...
