Above: Local government building in Altenkirchen Contractor: Metallbau Sturm GmbH, Altenkirchen Fieger Louvre Windows – FLW ... are double-glazed, louvre windows with thermally-broken extruded aluminium frames. The horizontal louvres rotate on pivot bearings, linked to a rack and pinion system, which ensures smooth, synchronized operation. Visual enhancement: when closed, the glass louvres form a flush surface with the outside of the window frame resulting in a markedly uniform appearance. Optimal ventilation With a maximum opening angle of 90 degrees, Fieger louvre windows provide a large free...

3 A choice of drives Our louvre windows can be operated in a variety of ways, e.g. directly on the unit by means of a hand lever, an electric motor or pneumatic cylinder. They can also be operated by a remote drive with a traction rod or with a crank handle. Windows which do not exceed 3 square metres usually require only one drive to operate the louvres. High quality materials – thermally-broken aluminium frames Fieger louvre windows are produced with thermally-broken aluminium frames, a recent development in window technology. The fact that the extruded frames are a single piece means they...

Thermal protection with double glazing Our standard double glazing has a total thickness of 24 mm (FLW 24 ) or 28 mm (FLW 28) and a U-value of 1.1/DIN EN 673. Sheet metal panels of an appropriate thickness can also be used. We can, of course, supply other combinations with sun-screening, sound-proofing, safety glass, etc. The units are sealed with continuous EPDM profiles. Design and colour – available according to your specifications Fieger louvre windows can be anodised, powder-coated or spray-painted in all standard RAL colours. Various types of fixed panels are also available. Unusual solutions,...

Above: Pathology Freiburg Contractor: Fensterbau Anthonj GmbH, Rheingau Above: Volkswagen Arena, Wolfsburg Contractor: BSS Metallbau-Schiffsausbau GMBH & Co. KG, Lemgo Above: A-R-S Vertrieb Neu Anspach Architect: Hartmann Planung GmbH, Hanau Contractor: Sommer Fassadensysteme-Stahlbau- Sicherheitstechnik GmbH & Co. KG, Döhlau

Illustrations of Fieger Louvre Windows Cross-sections and Elevation Scale = 1:4

Above: Ticona, Kelsterbach Architect: Planungsbüro Numrich + Albrecht GmbH, Berlin Contractor: Trumpf Metallbau GmbH Above: Spreepalais Berlin Architect: NHT & Partner GbR, Frankfurt Contractor: High Tech Metallbau GmbH, Berlin Above: Nurses’ Residence, Munich-Grünwald Architect: BMBW München Architekten BDA + Partner Contractor: Schneider GmbH & Co. KG, Stimpfach

Horizontal cross-section Thermal break Glazing frame Glazing seal Outside 20 2 40 24 (28) 34 (38) Pivot bearing 65 20 2 60 2 20 Rack and pinion Side frame Inside Outside Centre mullion (if needed) Inside Scale = 1:1 8

Head frame Brush seal Corner bracket Glazing frame Glazing 24 mm / 28 mm Glazing seal Bottom gasket Cill frame Inside Scale = 1:1 Outside 65 43 43 34 (38) 24 43 Vertical cross-section 9 Illustrations of Fieger Louvre Windows

10 Drive options Examples of available actuators Hand lever Traction rod with cover Hand lever Scale = 1:3

1111 Above: Conservatory Above: Nursery Augsburg Above: Altötting Contractor: Delta Immo Tec

12 Scale = 1:3 Gear mechanism Electric drive Crank handle (fixed or detachable) Pneumatic cylinder & ram

13 Drive options Scale = 1:4 Motor drive for a double unit. Above: Airport Münster-Osnabrück Architect: Planungsgemeinschaft Schulze-Wörmann- Spiekermann, Ostbevern Contractor: Feldhaus Fenster + Fassaden GmbH & Co., Emsdetten Scheffer Fassadentechnik GmbH & Co. KG, Sassenberg

14 Fieger Louvre Windows - always pre-assembled and ready for installation Scale = 1:2 Installation in window frame and other glazing systems Adaptor profile 30 x 42 mm (also available in 30 x 44 and 30 x 48) Installation into curtain-walling system: Standard adaptor: aluminium square section 20 x 20 mm in the same colour as window + neoprene insulation (available for all mounting thicknesses from 24 to 40 mm) 20 24 to 40 30 42 8

1515 Above: Apart Hirschberg Contractor: Goldbeck Bau GmbH Below: Festo AG Esslingen Architect: Architekturbüro Jaschek, Stuttgart Contractor: Helmut Fischer GmbH, Talheim

16 Application Scale = 1:2 Installation into a Profilit system Installation into masonry Window cill connector profile 30 x 37 made of white plastic Assembly with masonry clip 30

17 Fieger Louvre Windows – FLW 24 and FLW 28 Systems Thermally broken aluminium frames. Flush-fitting frame and louvres on the outside. Frame depth is 65 mm, visible frame width is 40 mm vertically and 20 mm horizontally. Visible width of glazing frame is 20 mm. Louvres are fully adjustable by means of a maintenance free rack and pinion drive. Mechanical parts are concealed. Units are glazed, adjusted, tested for function and ready for installation. Items: Frame dimensions: width height Colour: (optional) Anodised E6-EV1 Powder-coated in RAL colour, or specified colour Number of louvres: (optional)...

18 Fieger SmoTec Louvre Windows – FLW SmoTec Certified in accordance with EN 12101-2. For natural smoke and heat exhaust ventilation Systems, NSHEVs. In addition to general ventilation applications we can also supply units for specialist smoke control use. The new SmoTec System has been fully tested and certified to EN 12101-2. System FLW SmoTec with electric motor 24V Model D + H LDF 100/60 Dimensions: (L x W x D) 425 x 26 x 25 mm Shear force: approx. 800 N Power consumption: approx. 0.85 A Housing: stainless steel (other colours avail. on request) System FLW SmoTec with electric motor 24V Model...

19 Fieger Louvre Windows – FLW System – SmoTec (NSHEV) Certified according to EN 12101-2. Thermally broken aluminium frames. Flush-fitting frame and louvres on the outside. Frame depth is 65 mm, visible frame width is 40 mm vertically and 20 mm horizontally. Visible width of glazing frame is 20 mm. Louvres are fully adjustable by means of a maintenance free rack and pinion drive. Mechanical parts are concealed. Units are glazed, adjusted, tested for function and ready for installation. Items: Frame dimensions: width height Colour: (optional) Anodised E6-EV1 Powder-coated in RAL colour, or specified...
