Gearmotor C720 24V

Gearmotor C720 24V

Product catalog summary

Overview: The C720 is a 24V gearmotor designed for sliding gates, offering high mechanical efficiency and reduced vibration and noise. It features a patented speed reduction principle and is suitable for residential use.

Key Specifications:

Mechanical Efficiency: >80%
Gate Speed: Max 24 m/min
Operating Temperature: -20°C to +55°C
Weight: 8 kg
Protection Class: IP 44
Dimensions: 300 x 180 x 280 mm
Power Supply: 230 Vac 50 Hz
Motor Supply: 24 Vdc
Power: 170 W
Current: 7 A
Electric Motor Speed: 3200 rpm
Max Torque: 18 Nm
Thrust: 320 N

Features:

Integrated control board with anti-crushing system and virtual encoder for obstacle detection.
Magnetic limit switches for precise operation.
Compatible with FAAC transmitters and receivers (XF433 MHz, XF868 MHz).
Easy configuration via LCD display with high programmability.
Supports both traditional and Bus photocells.
Offers 12 operating logics for versatile use.

Additional Components:

Emergency kit XBAT 24V with NiMH battery.
Pinion Z28 M 4 for effective gate movement.

Contact Information: FAAC SpA and its subsidiaries are located worldwide, including in Italy, Switzerland, France, Germany, UAE, Spain, UK, Australia, India, Poland, Belgium, Austria, USA, Sweden, and China. For more details, visit their respective websites.

Catalog excerpts

24V Gearmotor for sliding gates >

Open the catalog to page 1

Օ High mechanical effi ciency: >80% (+50% compared to traditional gearboxes). > Vibration and noise reduction: the impellers are 180հ out of phase, making the gearbox perfectly symmetrical and balanced. > Robustness and reliability: the load is distributed to many contact points. >

Open the catalog to page 2

Power supply230 Vac 50 HzMotor supply 24 Vdc Power170 WCurrent7 A Electric motor3200 rpmMax torque18 Nm Thrust320 N PinionZ28 M 4 >

Open the catalog to page 3

HEADQUARTERS FAAC SpAVia Benini, 1 40069 Zola Predosa (BO) ֖ Italy Tel. +39 05161724 Fax +39 051 758518 www.faacgroup.com [email protected] FAAC SUBSIDIARIES FAAC AGTel. +41 52 3461721 Fax +41 52 3461723 Illnau, Switzerlandwww.faac.ch FAAC FRANCETel. +33 472218700 Fax +33 472218701Corbas, Francewww.faac.frFAAC GMBHTel. +49 8654 49810Fax +49 8654 498125 Freilassing, Germanywww.faac.de FAAC MIDDLE EASTDubai, Emirati [email protected] F.A.A.C. SATel. +34 91 6613112Fax +34 91 6610050Madrid, Espaֱawww.faac.esFAAC UK LTD.Tel. +44 1256 318100Fax +44 1256 318101Basingstoke Hampshire, UKwww.faac.co.uk...

Open the catalog to page 4
