Overview

This document presents technical specifications and options for entrance covering structures manufactured by Europrodotti. The products are designed for both small and large entrance coverings, with various shapes and materials options.

Materials and Finishes

• Primary structural components are made of aluminum.
• Supporting elements are available in galvanized steel or stainless steel, depending on the model.
• Surface finishes include a choice of RAL colors for coating.
• Covering panels are made from original Plexiglas, available in transparent (colorless) or smoke grey.

Product Systems

TE 25 System (Large Coverings)

• Designed for large entrance coverings.
• Supports made of galvanized steel.
• Available shapes include vault-shaped (Mod. VR) and pyramid-shaped (Mod. VE) coverings.
• Maximum dimensions vary, with widths up to 2500 mm and depths up to 1500 mm.

MOD. DEP System

• Similar to TE 25 but with stainless steel fixings.
• RAL color finish available on request.
• Covering options include transparent or smoke grey Plexiglas.

TE 20 System (Small Coverings)

• Designed for smaller entrance coverings.
• Supports made of galvanized steel.
• Available shapes include vault-shaped (Mod. VR), flat coverings (Mod. EC-F, Mod. AR-F, Mod. AL-F, Mod. TI-F), and pyramid-shaped (Mod. VE).
• Maximum dimensions generally up to 1500 mm width and 1200 mm depth.

Design Variants and Models

• Vault-shaped coverings: Models VR, EC-R, AL-R, TI-R.
• Flat coverings: Models EC-F, AR-F, AL-F, TI-F, Light-F.
• Pyramid-shaped coverings: Model VE.
• Models are differentiated by shape and size to suit various architectural needs.

Key Parameters and Limitations

• Maximum widths range from 1000 mm to 2500 mm depending on the system and model.
• Maximum depths range from 1000 mm to 1500 mm.
• Material choice affects fixing elements: galvanized steel for standard models, stainless steel for premium options.

Recommendations and Best Practices

• Selection of RAL color coating allows customization to match building aesthetics.
• Choice between transparent or smoke grey Plexiglas provides options for light transmission and privacy.
• Use stainless steel fixings for enhanced durability and corrosion resistance, especially in demanding environments.

Contact Information

Manufacturer: Europrodotti
Address: Via Argine 3 - Zona industriale 1 - CH 6930 Bedano
Phone: ++41(0)91 935 40 50
Fax: ++41(0)91 935 40 55
Website: www.europrodotti.ch
Email: [email protected]
