NOTES This novelties broschure is intended to be used together with our complete catalogue as a working basis for business. > This novelties broschure provides details of new products, product improvements and additions to the existing range.You can get a comprehensive overview of the ESYLUX range from our full catalogue.ESYLUX products are exclusively distributed to specialist electrical companies via electricalwholesalers.For any technical questions or to order promotional material, please contact your wholesaler or contact the ESYLUX sales department directly. No responsibility is accepted...

RCi series with ERF radio technology 4 - 5 For indoor installation, ceiling mounting PDC 360i/24 KNX 6 - 9 For indoor installation, ceiling mounting PD/PDE DIM series 8 - 11 Automatic floodlights AF series 12 - 15 Twilight switches CDSi-A/N 16 - 17 PROTECTOR K smoke detector 18 - 19 PROTECTOR Mi smoke detector 20 - 23 Portable spotlight SL P 24 - 25 POWERLINE EPL system 26 - 29 > Brochure and catalogue ordering 30 ESYLUX full range overview 31 >

Motion detectors NEW: Radio transmitter module in mounting base (accessory) for transmitting switching commands to the ER-Receiver/5A. Simply replace the standard mounting base with the radio base. > Easy installation Service remote control Radio transmitter module in mounting baseERF-Transmitter/RC Radio receiver module ERF-Receiver/5A RCi Motion detector LightsJunction boxes Օ NEW:Radio receiver module (accessory) for retrofitting in lights and junction boxes. Flexible installation thanks to compact design > 868 MHz Automatic recognition of radio components > Motion detectors ESYLUX RCi series...

Motion detectors Radio transmitter module in mounting base for transmitting switching commands to the ERF-Receiver/5A. Easy installation Օ For ESYLUX motion detectors RC 130i, RC 230i and RC 280i > 868 MHz Mains voltage: 230 V AC 50 Hz Օ Housing material: UV stabilized polycarbonate Frequency: 868 MHz Օ Colour: white, similar to RAL 9010 Transmitting power: < 10 mW Օ Transmission mode: unidirectional > Radio receiver module for retrofitting in lights and junction boxes Օ Flexible installation thanks to compact design > 868 MHz Mains voltage: 230 V AC 50 Hz Օ Approx. measurements: height 26 mm...

NEW: Presence detectors for intelligent and energy saving illumination control plus presence activated control of heating, ventilation or air conditioning > Can be used everywhere Model/Colours Cover set Plug-in terminals Օ Especially suited to use in office and hotel hallways, classrooms, board rooms etc. and passageways with natural lighting > Range approx. 24 m diameterColour: white, similar to RAL 9010 Ceiling mounting Additional switch contact for light/HVAC, e.g. additional panel light or air-conditioning control > Field of detection Օ Possible to connect a switch for manual dimming or...

Presence detector with 360հfield of detection for ceiling mounting With 1 - 10 V DC interface for demand-responsive adjustment to a constant brightness level depending on presence and daylight Օ Default settings ensure immediate operability Mains voltage: 230 V AC 50 Hz Օ Light value: approx. 5 - 2000 Lux > Presence detectors Field of detection: 360հ Slave input: yes Օ Range: approx. 24 m diameter, at an installation height of 3 m Interface: 1 - 10 V DC Օ Control output: 1 - 10 V DC/100 mA Setting options: mechanically by adjusting controller, electronically by infrared Mobil-PDi/DIMplus and...

AF S series Time saving, one-handedtrouble-free mounting without motion detectors > through plug-base installation For 60 - 500 watt illuminantsColours: Two entry fittings, white, black and stainlees steel appearance optionally from the top, bottom or rear(selfsealing diaphagm) Motion detector with > Remote control (for AFi series) Mobil-RCi-M for controlling continuous lighting ON/OFFfor max. 12 hours, storing the current twilight value and enabling continuous OFF The moving ball and socket joints enable optimal alignment of the floodlight and motion detector >

Halogenfloodlight 300 Watt Օ Mains voltage: 230 V AC 50 Hz Installation type: Wall mounting, mounting on inner andouter corners possible with accessories Օ For iluminants: 150 - 300 W/R7s/114,2 mm length (not included) Approx. measurements: height 159,3 mm x width 212,4 mm x length 177 mm Օ Protection type: IP 44 Protection class: I Օ Colour: white, similar to RAL 9010, black, similar to RAL 9005, stainless steel appearance Test symbol: T՜V Sd > Halogenfloodlight 500 Watt 압 Mains voltage: 230 V AC 50 Hz Installation type: Wall mounting, mounting on inner andouter corners possible with accessories...

NEW: Programmable by remote control Mobil-RCi-M (accessory): - Input of the current light value as a switch-on value- Lamps/Illuminants testing via ON/OFF function- Switching continuous lighting ON/OFF for max. 12 hours > Twilight switches Changing the switching threshold LED setting aid compatible with old and new models via jumper through changeable module Օ Switching capacity 16 AX (all loads) Automatic light switching depending on brightness value Օ Ideal for new installation > for adjusting the light value For upgrading existing iluminations > IR Օ Futher convincing benefits: - floating...

Tested in accordance with: Networkability PROTECTORK 230 V AC Signal volume DIN EN 14604, VdS, T՜V up to 30 signalling devices per wire with integrated relay driver approx. 85 dB/3 m > Smoke detectors LED indicator Test button for function test > indicates operability with battery testing and electronic smoke chamber testing > Bedroom 2 Bedroom 2 Bedroom 1Staircaise Bedroom 1Staircaise KitchenLiving room BasementKitchenLiving room Basement Single-room securing Cross-linkage With this solution the smoke detectors are not interconnected.In the event of fire, All smoke detectors can be connected...

Bedroom 2 Bedroom 2 Bedroom 1Staircaise Bedroom 1Staircaise Living room Living room BasementKitchen Basement Bedroom 1 StaircaiseBedroom 2 Living room Kitchen Basement Kitchen Smoke detectors Photoelectric smoke detector with multi-sensor and long-life battery Օ Stainless steel insect screen, smoke chamber in antistatic plastic Modular add-ons with radio module ERF-Transceiver-Card and/or 230 V AC power box Օ Plug-in terminals, removable Battery operation: 9 V Block battery (included) Օ Automatic adjustment of trigger threshold: depending on dirt level in the smoke chamber Tested in accordance...
