From Latin Revélo [rĕvēlo], rĕvēlas, revelavi, revelatum, rĕvēlāre Uncover, reveal, unveil that which was hi

SOLUTIONS FOR CONTEMPORARY LIVING We have always believed in technology that simplifies life and with this in mind we develop devices that make everyday gestures easier. To the needs of contemporary living we provide solutions designed and manufactured by us that help achieve true well-being in the home.

MADE IN ITALY MADE IN EKINEX

Would you hide a beautiful view

If you love watching your favourite series, sporting events, the news as soon as you wake up, but you only want to watch TV when needed.

Le nostre sale riunioni sono più comode. Your meeting rooms will be more functional.

Ideal solutions for the marine industry.

UNDER BED LIFT TV UP & DOWN LIFT TV We have created a series of Made in Italy lifts that help you to better arrange your space, giving you the opportunity to hide the TV when it is not in use.

UNDER BED LIFT TV In your room, a space under the bed is enough to make the TV disappear after viewing. But not only that. Lack of fitted walls or unalterable furniture can make it difficult or aesthetically disharmonious to install a TV. Furthermore, thanks to the very high definition of 4K and 8K panels, only 170 cm is needed for optimal viewing from a 48” TV. Why mount it on a wall?

UNDER BED LIFT TV VERSIONS EK-BTV-BTL TV moving device designed and engineered to move a retractable TV set (up to 55”) placed under the bed. For optimal viewing angle we recommend 43” or 48” TVs. Compatible with SKY GlassTM. More information Watch the technical vi

POSITIONING AND FIXING The fully adjustable brackets allow easy installation of the device even in situations where floor fixing is not possible (fine finishes or presence of radiant panel systems).

INTEGRATED CONTROL PANEL The EK-BTV-BL has a function control panel with integrated display for adjusting the operating parameters. The function control panel with integrated display is for the exclusive use of the installer or authorised Ekinex personnel.

PHOTOELECTRIC SENSORS Each EK-BTV-BL is equipped with three infrared laser photoelectric sensors with light/dark pulses that allow the product to stop upon detection of an obstacle that prevents it from moving horizontally.

OVERLOAD DETECTION The device also integrates anti-crushing, based on a system that detects overloading of manoeuvring motors.

UP & DOWN LIFT TV The perfect combination of aesthetics, versatility and space functionality. The Up & Down line of retractable TV lifts integrates inside your furniture, adapting to any type of residential, hotel, naval or tertiary environment. Available in two versions (standard and XL) to accommodate monitors and TVs up to 65”.

UP & DOWN LIFT TV VERSIONS EK-LTV-BL TV moving device designed and engineered to move a retractable TV set (up to 43”) placed inside a cabinet. Compatible with SKY GlassTM. EK-LTV-XL-BL TV moving device designed and engineered to move a retractable TV set (up to 65”) placed inside a cabinet. Compatible with SKY GlassTM. More information More information Watch the technical video Watch the technical vide

The BusLinkTM software (Windows) allows you to configure different parameters of the TV lift column: acceleration and deceleration ramps, virtual and current limits, stroke adjustment. To use the software, the BusLink kit is required, which contains 1 USB2Lin interface cable and 1 adapter (included in delivery). The BusLink software is for the exclusive use of the installer or authorised Ekinex personnel.

ANTI-COLLISION SOLUTIONS The EK-LTV-BL and EK-LTV-XL-BL are both equipped with the following anti-collision solutions: Desk Sensor TM that detects tilt and obstacles while running. PIEZOTM anti-collision sensor integrated in the column which reduces minimises the risk of damage in the up and down direction.

FINISHES STANDARD PAINTING UNDER BED LIFT TV Black (RAL 9005) UP&DOWN LIFT TV PAINTING ON REQUEST (coming soon)

COMPATIBILITY Compatible with A/V systems Control4, Crestron, KNX and of course also available stand-alone.

EKINEX PLANNER Through the Ekinex configurator, each element can be customised and inserted into your project up to the generation of a quotation request that is sent to the sales team together with the details of the chosen products. planner.ekinex.com
