AA Akkreditierung Austria (www.akkreditierung-austria.gv.at) °C Degrees Celsius °F Degrees Fahrenheit BEV Bundesamt fur Eich- und Vermessungswesen (www.bev.gv.at/) BIPM Bureau International des Poids et Mesures (www.bipm.org) CIPM Comite International des Poids et Mesures (www.bipm.org/en/committees/ci/cipm) CMC Calibration and Measurement Capabilities DI Designated Institute (www.bev.gv.at/en/Topics/Metrology-Service/Designated-Institutes.html) GUM Guide to Expression of the Uncertainty of Measurement in Calibration hPa Hecto Pascal (1 hPa = 1 millibar) ILAC International Laboratory Accreditation...

Accredited Calibration Laboratory National Metrological Institute / Designated Institute National Metrological Institutes (NMIs) or Designated Institutes (DIs) maintain the highest national standards and ensure that the measurements correspond to the international system of units (SI). NMIs and DIs participate in international comparative measurements with other NMIs and cooperate in technical committees to ensure that they are the top reference for measurement variables. As highest measurement authority in the country, the NMI/DI owns highest level of expertise with respect to specific physical...

Air Velocity At the level of NMI / DI (BEV/E+E) Accredited according to DIN EN ISO/IEC 17025 Carbon Dioxide At the level of NMI / DI (BEV/E+E) Accredited according to DIN EN ISO/IEC 17025 Dew Point At the level of NMI / DI (BEV/E+E) Accredited according to DIN EN ISO/IEC 17025 The air velocity measurement devices are calibrated by comparison with a laser Doppler anemometer in a homogeneous, reproducible flow (wind tunnel). The E+E accredited calibration laboratory operates two tunnels for the air velocity range up 40 m/s and up to 2 m/s respectively. E+E calibration laboratory performs also calibration...

Dew Point The E+E accredited laboratory performs calibrations for CO2 concentration in the range 5 ... 300,000 pmol/ mol for all common CO2 measuring devices such as sensors, handhelds, data loggers, spectrometers and for reference gases. The calibration is performed as comparative measurement with a constant, free selectable CO2 reference concentration generated according to the Austrian national standard. Due to the operation principle of the generator, the CO2 reference concentration can be traced back to length, temperature and mass, which are fundamental physical quantities of the International...

Humidity The E+E accredited calibration bench is unique in Europe and offers flow and volumetric flow calibrations for inline and immersion flow meters at standard conditions in the range from 0.6 to 2,300 m3/h in pipes from DN15 to DN80 (1/2 to 3"). The pressure in the calibration bench can be set between 0.1 and 1 MPa, which allows for highly accurate calibration under the real conditions in compressed air networks. The E+E calibration laboratory is accredited for relative humidity calibrations in the temperature range -70 °C to 200 °C. The reference is a high-end, sophisticated dual pressure...

Temperature E+E accredited laboratory performs calibrations of measuring devices for absolute, for positive and negative gauge pressure as well as for differential pressure:The E+E accredited laboratory performs calibrations of temperature measuring devices in air for the range -80 to 200 °C as well as in dry block calibrators for the range -45 to 425 °C. 0.01...10.1 MPa 0.09...10 MPa 0.03.0.9 MPa Absolute pressure: Relative pressure: Differential pressure:Scope of Accreditation E+E Calibration LaboratoryScope of Accreditation E+E Calibration Laboratory Calibration * For calibration of temperature...

Calibration Procedure E+E Elektronik - Your Partner in Sensor Technology Together with the calibration order, and prior to shipping the device to be calibrated to the E+E laboratory, E+E Elektronik GmbH, with headquarters in Engerwitzdorf, Austria, has been established the customer must complete the online form “Accompanying Document” (scan the QR code to access the in 1979 and is part of Dr. Johannes Heidenhain GmbH group. online form). Upon receipt, the device to be calibrated (specimen) undergoes an initial calibration according to customer‘s specification. The calibration results are documented...
