PROFESSIONAL CATERING Water Controls for Professional Catering

delabie.com available features contacts head office & production site 18, rue du Marechal Foch 80130 Friville FRANCE delabie.com SUITABLE FOR TABLETS AND SMARTPHONES m CREATE A PERSONALISED CATALOGUE Create your own catalogue using your own product selection. You can personalise it by giving it a project name and description, by choosing the order for the products to appear and by adding lifestyle images. This catalogue will then be available in Word, PDF and Excel formats. acs Certificate of Sanitary Conformity. All DELABIE products conform to the CPDW* directive modified 29/05/1997, and the...

PRE-RINSE SPRAYS PRE-RINSE MIXERS ���������������������������������������������������������������������������������������������������������������� 4 PRE-RINSE SPARE PARTS ����������������������������������������������������������������������������������������������� 21 COMMERCIAL KITCHEN CONTROLS COMMERCIAL KITCHEN CONTROLS WITH HIGH FLOW RATES ��������� 24 COMMERCIAL KITCHEN CONTROLS ���������������������������������������������������������������������� 34 NON-CONTACT CONTROLS ELECTRONIC CONTROLS ������������������������������������������������������������������������������������������������...

PRE-RINSE SPRAYS Pre-rinse mixers and taps with flexible hose and hand spray PRE-RINSE MIXERS PRE-RINSE SPARE PARTS Pre-rinse sprays

/ Pre-rinse sprays for intensive, professional use SPECIFICALLY DESIGNED FOR INTENSIVE, PROFESSIONAL USE Subject to intensive use in professional kitchens, the catering industry and for fish preparation, etc�, pre-rinse sprays must be robust and reliable� Specifically designed to withstand high stress loads, DELABIE’s pre-rinse sprays are also functional, easy to handle, and ensure effective filling and cleaning� Long Life valve head with an ergonomic ball lever Full flow rate within the first 90° Hand spray - rain effect Hand spray - concentrated jet Increased durability and endurance All DELABIE’s...

PRE-RINSE SPRAYS PVC SHEATH Superior endurance ANTI-TORSION ROTATING NUT Reliable ADJUSTABLE HEIGHT STAINLESS STEEL SPRING GUIDE Increased durability SPRING SUPPORT Easy to install HAND SPRAY WITH ADJUSTABLE JET Easy to use WALL-MOUNTED BRACKET (adjustable length) RAPID-FILL SPOUT CHROME-PLATED SOLID BRASS COLUMN Robust LONG LIFE VALVE HEAD Increased resistance and endurance (for more details see page 24) Displayed model: single hole pre-rinse set with mixer (ref. 5632)

Single hole pre-rinse set with mixer 5625

Pre-rinse sprays Deck-mounted single hole mixers / DELABIE Pre-rinse sprays Deck-mounted single hole mixers / DELABIE • Complete pre-rinse set with %” brass column. • Deck-mounted single hole mixer with slimline control lever. Supplied with F%" flexible connectors and non-return valves. • Bib tap with: - Swivelling, tubular spout L. 200mm. - 16 lpm full flow rate achieved within the first 90°. - Valve head with reinforced mechanism and ergonomic control lever. • Black, scale-resistant M^” hand spray with adjustable jet. • Black, reinforced, food-grade flexible hose L. 0.95m. • Adjustable wall...

PRE-RINSE SPRAYS Pre-rinse sprays Deck-mounted single hole mixer / Short single hole pre-rinse set with mixer • Complete pre-rinse set with column and swivelling retaining hook� • Deck-mounted single hole mixer with slimline lever� Supplied with F⅜" flexible connectors� • Hand spray with adjustable jet. • Black, food-grade flexible hose L� 0�95m� • Stainless steel spring guide� • 10-year warranty� Provisional availability: 1st half 2022. Please contact sales office to check availability. Short single hole pre-rinse set with mixer Options: hand sprays, flexible hoses and spouts (see pages

Single hole pre-rinse set with mixer 5632 - Floor-standing janitorial unit 180140 - Mixer with retracting hand spray 2211

Pre-rinse sprays Deck-mounted single hole mixers / DELABIE Single hole pre-rinse set with mixer Tubular spout • Complete pre-rinse set with %" brass column. • Deck-mounted single hole mixer with: - Valve heads with reinforced mechanisms and ergonomic control levers. - F%" flexible connectors and non-return valves. - Reinforced fixing via 2 threaded rods and back-nuts. • Bib tap with: - Swivelling, tubular spout L. 200mm. - 20 lpm full flow rate achieved within the first 90°. - Valve head with reinforced mechanism and ergonomic control lever. • Black, scale-resistant M^"hand spray with adjustable...

• Complete pre-rinse set with %" brass column. • Deck-mounted twin hole mixer with 150mm centres with: - Valve heads with reinforced mechanisms and ergonomic control levers. - Offset inlet connections with M'A" tails. • Bib tap with: - Swivelling, tubular spout L. 200mm. - 25 lpm full flow rate achieved within the first 90°. - Valve head with reinforced mechanism and ergonomic control lever. • Black, scale-resistant M^" hand spray with adjustable jet. • Black, reinforced, food-grade flexible hose L. 0.95m. • Adjustable wall bracket. • Stainless steel spring guide. • 10-year warranty. These pre-rinse...

Pre-rinse sprays Wall-mounted mixers / DELABIE Wall-mounted pre-rinse set with mixer Tubular spout • Complete pre-rinse set with %" brass column. • Wall-mounted mixer, F%" with adjustable centres with: - Valve heads with reinforced mechanisms and ergonomic control levers. - Offset connectors M'A" M%" (see page 79). - Non-return valves integrated in the mixer. • Bib tap with: - Swivelling, tubular spout L. 200mm. - 25 lpm full flow rate achieved within the first 90°. - Valve head with reinforced mechanism and ergonomic control lever. • Black, scale-resistant M%" hand spray with adjustable jet....

/ Pre-rinse sprays for professional use SPECIFICALLY DESIGNED FOR PROFESSIONAL USE Water-free valve head with control knob Full flow rate in ½ turn Hand spray - rain effect Increased durability and endurance All DELABIE’s pre-rinse sprays are quality-controlled and tested under extreme conditions to ensure their durability under stress. Water-free valve head Thanks to its exclusive quality features, DELABIE’s water-free valve head, that is fitted to the Commercial Kitchen range, provides the mechanism with enhanced durability and a smooth operation: no sign of wear after 200,000 operations (see...
