Specifications:
DAN-doors fire sliding doors are certified to BS 60 according to DS 1052-2, ensuring a 60-minute fire resistance. They are available in 1- and 2-leaf configurations, with options for manual or automatic operation. The doors have a thickness of 65 mm and can be custom-made up to a maximum size of 4800 mm width by 3600 mm height. The insulation is made from non-organic materials with excellent properties.

Materials and Construction:
The door leaf is constructed from plastisol-coated galvanized steel or stainless steel, available in polished, circle polished, or rigidised finishes, ensuring easy cleaning and compliance with hygiene standards. The frame is made from 1.0 mm stainless steel, insulated with non-organic material, and includes installation holes with plastic caps. The sliding rail and rollers are made from stainless steel AISI 304.

Features:
Handles are designed for ease of use, with a bow handle outside and a bowl-shaped handle inside. The bottom guide and fittings are also made from stainless steel AISI 304. A counterweight box allows the door to close from any position, with an optional eddy-current brake for larger doors. Safety features include a fusible link for 70°C or a magnetic hold.

Additional Equipment:
Optional features include tooth belt automation, sliding rail protection, padlock fittings with or without emergency opening devices, eddy-current brakes, ABDL central with smoke detectors and control unit, emergency hatches, and kick plates.

Compliance and Quality:
The doors meet the strictest demands of the food industry and comply with the Foodstuffs Hygiene Directive 93/43/EEC. They are designed to combine quality materials, precision engineering, and elegant design.

Contact Information:
DAN-doors a-s, Industrivej 19, Stilling, DK-8660 Skanderborg, Tel. +45 87 93 87 00, Fax +45 86 57 32 90, Email: [email protected]
Website: www.dan-doors.com

Note: Technical improvements may be made as of June 2010.
