DAISALUX GENERAL CATALOGUE
185Pages

A day in Daisalux3New technological developments15 Central TMA16Centralized DaisaTest System18 Daisa program Versin 3.522General Catalogue25Emergency Luminaires > Nova Series 26 Single Argos Series 34 Double Argos Series 42 Built-in Argos Series 50 Hydra Series 58 Myra Series 66 Norma Series 74 Iris Series 82 Sol Series 90 Luna Series 98 Explosion Proof Series 106 Sealed fluorescent screens 166Emergency Spotlights Zenit Series 114 Zenit PL Series 122Signalling luminaires Vir Series 130Beacon lighting Lyra Series 136 Aqua Series 144 PBL units for supplying beacon models: (Lyra-Aqua)152...

Model OperationNumber of units Central TMA-300Test equipment and remote control which communicates via a two-wire BUS with the DaisaluxTCA series self-contained luminaires. Not connected to a computer. Has a parallel port to printer. 300Central TMA-500Test equipment and remote control which communicates via a two-wire BUS with the DaisaluxTCA series self-contained luminairesThe installation is controlled from a local or remote computer. 500Central TMA-1000Test equipment and remote control which communicates via a two-wire BUS with the DaisaluxTCA series self-contained luminaires. The...

- The TCA series emergency luminaires are capable of running functional and autonomy tests and ofcommunicating with a Central TMA. This TCA Series extends to all Daisalux equipment models and emergencyluminaires. - The Central TMA-1000 is the technological centre of the DaisaTest System. It communicates over twowires (Bus-Tam) with emergency luminaires and equipment to instruct them to run the tests and collectthe results. Via a standard RS232 connection it informs the control computer of these results andreceives the user's instructions. - DaisaTest Software is responsible for enabling...

21 Centralized DaisaTest System > The main function of the DaisaTest System is to provide an emergency lighting system with reliabilityand economic maintenance. For this purpose the DaisaTest System will have to check that all theluminaires work properly and inform on the status of the installation. This information is obtainedthrough the computer screen, printed reports and the unit LEDs.It performs the following checks:-Keeps a permanent check that the luminaires are connected to the mains, that communication is correct(between luminaires, central and computer), that the battery receives...

1. Importing plans / layer management The Daisa program Version 3.5 supports importing DXF filesso that the user does not need to draw the plans.ՕIt recognises the layers and their features in the DXFfile.It allows the relevant layers for calculation to be changedto obstacles. 2. Evacuation routes / Creating safety points Օ The evacuation routes can be defined. After performing the calculation, the lighting obtained ineach route can be viewed by selecting it.Օ All the defined routes are included in the printed report. It allows the user to declare safety points and test points,assigning...

5. Installing luminaires It is possible to select one or several luminaires.Օ It is possible to replace the references of the selected luminaires. Once the luminaire is selected, both its reference and its locationare shown on the right-hand side of the screen.Օ Other actions that can be performed with the luminaries includemoving, deleting, copying, changing position, adding sign, etc. 6. Calculation Daisa program Version 3.5 makes it possible to configure the calculationby setting the resolution and the Isolux curves to be calculated.Օ While the calculation is being made, a progress bar...

Daisalux has developed its environmental policy under the Eco-design perspective. The objectiveis to minimize the environmental impact in the life cycles of the product searching developmentswhich integrate ecologic designs.This implies the implementation of a methodology that involves all departments and areas of thecompany, in order to be able to offer more quality products. For that matter Daisalux introducethe following improvements:-Environmental improvements: we have searched a non-contaminant alternative to the Ni-Cd (nickelcadmium) batteries, through the adoption of a NI-MH (nickel...

Construction details: Built to EN 60598-2-22 (IEC 60598-2-22) standard / Conforming to Community Electromagnetic Compatibility,Low Voltage and RoHS Directives 93/68/EC, 89/336/EC, 73/23/EC and 2002/95/EC / Self extinguishing plastic materials, 850Cto EN 60598-1 (IEC 60598-1) and EN 60695-2-1 (IEC 60695-2-1), according to models / Battery protected against excessivedischarges and polarity reversal / Stand-by setting by remote control / Remote control circuit protected against connection errors / Testing by remote control when mains voltage is present / Electric shock protection: Class II /...

Surface Nova > 67 Base, reflector and diffuser made of polycarbonate. Colours: white as standard,black optional. > 95 330 NOVA NOVA + KEB NOVA NOVA + KBO NOVA NOVA + KBO NOVA+ KEB NOVA NOVA + KES NOVA > 360 125102 Recessed Nova > 58 With ABS recessingaccessory. Colours: whiteor black. > 338 16 Hole required: 338 mm. x 102 mm. Biplane Nova > 33095 Blended or opal diffuser,made of polycarbonate. > 110 Recessed Biplane Nova > 338125102 With ABS recessing box. > 58 Hole required: 338 mm. x 102 mm. Sealed Nova > 364 81 Box made of polycarbonatewith three M20 inputs,stainless steel nuts and...

It represented a revolution in emergency lighting; a single luminaire provided with a variety of accessoriescapable of achieving different applications (Recessed Nova, Surface Nova, Recessed Biplane Nova, Surface BiplaneNova, Sealed Nova), as if it were a case of different emergency luminaires. A Daisalux classic, which continuesto blend into the latest architectural environments on account of its low cost, its functional capability and its timeless character. ChargingModelAutonomyLumensEmerg. lampmonitor Non maintained: NOVA N11 h 70FL 6 WWhite LEDNOVA N21 h 95FL 8 WWhite LEDNOVA N31...

Construction details: Built to EN 60598-2-22 (IEC 60598-2-22) standard / Conforming to Community Electromagnetic Compatibility,Low Voltage and IP 32 IK 04 RoHS Directives 93/68/EC, 89/336/EC, 73/23/EC and 2002/95/EC / Self extinguishing plastic materials, 850Cto EN 60598-1 (IEC 60598-1) and EN 60695-2-1 (IEC 60695-2-1), according to models / Battery protected against excessivedischarges and polarity reversal / Setting on stand-by by remote control / Testing by remote control when mains voltage is present / Protection against electric shocks: Class II / Luminaire suitable for fitting on...
